Milwaukee AG8-125 Parts

AG8-125 DMS ANGLE GRINDER IN2 4933442930 - AG8-125 - 4000442931
#	Part Num.	Description
4	4931624121	CONNECTION CABLE
5	4931206687	CABLE ENTRY SLEEVE
6	4931442933	RATING PLATE
100	4931403002	MOTOR HOUSING
101	4931403011	HOUSING CAP
105	4931442708	ELECTRIC FIELD
106	4931442636	ARMATURE
107	4931368347	FAN Discontinued
108	4931902888	BALL BEARING
110	4931385658	INSULATING DISC
116	4931368332	AIR DEFLECTOR RING
118	4931368633	BRUSH HOLDER
119	4931381347	SLIDER
120	4931368333	GUIDE PIECE
121	4931623590	SEAL RING
123	4931368374	RUBBER SLEEVE
124	4931256500	CABLE COLLAR
131	4931392612	CARBON BRUSH SET
135	4931391034	SWITCH
140	4931391182	CAPACITOR
220	4931345965	SPRING WASHER
400	4931412069	GEAR BOX
402	4931358685	LOCK COMPLETE
406	4931624662	BALL BEARING
407	4931803914	SEALING WASHER 21,8X15,8X0,2
408	4931613683	LOCKING RING D 472 22X1
410	4931358682	DRIVE GEAR Discontinueed
411	4931409808	SPINDLE
412	4931385262	WHEEL Discontinued
413	4931378310	BEARING END PLATE
414	4931623590	SEAL RING
415	4931385261	PINION discontinued
417	4931623480	DISC
418	4931808473	DISC N874237 12,2X22X0,1
419	4931925940	DISC N874237 12,2X22X0,2
420	4931624256	DISC
600	4931407642	GUARD CAP
701	4932409546	HANDLE
703	4932367712	PIN SPANNER 115-230/WP/WSAP1 A/M
704	4932449324	CLAMPING FLANGE WS115-230 P1 A/M
705	4932345628	FLANGE NUT M14 3MM P1 A/M
1000	4931358683	BOLT SET
