Milwaukee PLH32XE Parts
€2.33
Tax included
Milwaukee PLH32XE Comby Hammer Spare Parts
Fix Your Milwaukee PLH32XE Comby Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Milwaukee PLH32XE Comby Hammer Spare Parts
Fix Your Milwaukee PLH32XE Comby Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill Driver and their spare part.
| Milwaukee PLH32XE 240V COMBI HAMMER IN2 - Spare Parts 4933400069 - PLH32XE - 4000432294 - Pag.1 |
||
| # | Part Num. | Description |
| 3 | 4931432298 | RATING PLATE |
| 4 | 4931250832 | CONNECTION CABLE |
| 5 | 4931392174 | PROTECTING COVER |
| 7 | 4931623456 | GROOVED DOWEL PIN |
| 8 | 4931623094 | WASHER |
| 9 | 4931621834 | WASHER |
| 10 | 4931360377 | GEAR BOX COVER |
| 102 | 4931379134 | COVER |
| 105 | 4931442731 | ELECTRIC FIELD |
| 116 | 4931353230 | AIR DEFLECTOR RING |
| 117 | 4931405705 | HOLDING-DOWN DEVICE |
| 120 | 4931382268 | BRUSH HOLDER |
| 122 | 4931624518 | SCREW |
| 123 | 4931342808 | CENTERING LEDGE |
| 125 | 4931256500 | CABLE COLLAR |
| 126 | 4931256500 | CABLE COLLAR |
| 127 | 4931624515 | SCREW N874101-1 SHR H-K4X18 T15 |
| 128 | 4931623541 | WIRE |
| 129 | 4931622153 | SCREW |
| 130 | 4931356869 | BEARING COVER |
| 135 | 4931384896 | SWITCH BOARD |
| 140 | 4931624270 | CAPACITOR |
| 141 | 4931624269 | WIRE |
| 200 | 4931384040 | GEAR BOX |
| 204 | 4931331685 | LOCKING RING |
| 206 | 4931382948 | GEAR BOX |
| 208 | 4931623637 | WASHER |
| 209 | 4931941082 | O-RING N874701 5X1 |
| 210 | 4931360041 | THRUST BEARING |
| 214 | 4931621983 | DISC |
| 215 | 4931379589 | PRESSURE SPRING |
| 216 | 4931379649 | COUPLING SLEEVE |
| 219 | 4931426234 | REDUCTION GEAR |
| 220 | 4931384917 | PLANET GEAR |
| 221 | 4931331769 | INTERN.GEARED WHEEL |
| 222 | 4931455430 | PERCUSSION BODY |
| 223 | 4931379587 | CYLINDER |
| 224 | 4931331623 | CYLINDRICAL BOLT |
| 225 | 4931400589 | WASHER |
| 226 | 4931331752 | SLIDER |
| 228 | 4931623081 | PIN |
| 229 | 4931331787 | LATCH PLATE |
| 232 | 4931417464 | SPINDLE SLEEVE |
| 233 | 4931379071 | CUP SPRING |
| 234 | 4931379110 | CLUTCH DISC |
| 235 | 4931392752 | SPINDLE GEAR |
| 236 | 4931384919 | SPRING RING |
| 237 | 4931623199 | WASHER |
| 238 | 4931331713 | THRUST BEARING |
| 239 | 4931343187 | LOCKING WASHER |
| 243 | 4931387328 | THRUST COLLAR |
| 248 | 4931343049 | WASHER |
| 251 | 4931219424 | NEEDLE BEARING |
| 252 | 4931382921 | SLEEVE |
| 253 | 4931409774 | RING STOP |
| 254 | 4931805437 | BALL |
| 255 | 692737001 | PRESSURE SPRING |
| 256 | 4931945764 | SPRING RING |
| 257 | 4931379739 | ADAPTER |
| 259 | 4931623200 | WASHER |
| 260 | 4931623234 | WASHER |
| 261 | 4931392506 | SWITCH HANDLE |
| 262 | 4931379108 | LATCH PLATE |
| 265 | 4931624045 | CYLINDER PULLEY |
| 266 | 4931805390 | BALL |
| 268 | 4931624096 | DISC N874237 |
| 269 | 4931379420 | SPACER |
| 270 | 4931409756 | SUPPORTING PLATE |
| 271 | 4931624098 | DISC N874237 |
| 272 | 4931624097 | DISC N874237 |
| 273 | 4931624096 | DISC N874237 |
| 275 | 4931623602 | SCREW |
| 276 | 4931379708 | SCREW |
| 401 | 4931360732 | MOTOR COVER |
| 405 | 4931384337 | MOTOR HOUSING |
| 406 | 4931449967 | ARMATURE |
| 407 | 4931342793 | FAN |
| 408 | 4931341740 | GROOVED BALL BEAR. |
| 409 | 4931624101 | BALL BEARING |
| 410 | 4931353260 | INSULATING DISC |
| 411 | 4931384561 | REPAIR KIT |
| 412 | 4931384864 | REDUCT. GEAR SHAFT |
| 413 | 4931442301 | SEAL RING |
| 414 | 4931353238 | SPACER |
| 415 | 4931384557 | BUSHING |
| 416 | 4931624264 | DISC N874237 A 10,1X18X1 |
| 418 | 4931384560 | REPAIR KIT |
| 420 | 4931432300 | PINION SHAFT |
| 426 | 4931616614 | LOCKING RING |
| 427 | 4931622564 | DISC N874237 A16,1X26X1 |
| 430 | 4931379881 | REPAIR KIT |
| 432 | 4931400216 | REPAIR KIT |
| 444 | 4931407945 | SPINDLE SLEEVE |
| 605 | 4931384434 | DEPTH GAUGE |
| 606 | 4931409790 | CHUCK ADAPTER |
| 700 | 4931415335 | CARRYING CASE |
| 1100 | 4931384324 | HANDLE COMPL. |
| 1200 | 4931384723 | MAINTENANCE SET |
| 1201 | 4931369477 | CARBON BRUSH SET |
| 1204 | 4931623124 | O-RING |
| 1205 | 4931360781 | RUBBER SLEEVE |
| 1207 | 4931331735 | GASKET |
| 1209 | 4931379705 | SEAL RING |
| 1210 | 4931624492 | SEAL RING |
| 1211 | 4931454456 | O-RING |
| 1212 | 4931623135 | O-RING |
| 1213 | 4931623232 | SEAL RING |
| 1214 | 4931379022 | SLEEVE |
| 1215 | 4931392502 | DAMPING ELEMENT |
| 1216 | 4931331549 | HOLDING-DOWN DEVICE |
| 1218 | 4931623636 | RING |
| 1219 | 4931945764 | SPRING RING |
| 1220 | 4931623521 | SCREW |
| 1221 | 4931623520 | SCREW |
| 1222 | 4931623519 | SCREW |
| 1223 | 4931379109 | SCREW |
| 1224 | 4931623293 | O-RING |
| 1225 | 4931379585 | FELT WASHER |
| Accessories Pag.2 | ||
| 702 | 4932430912 | DUST CATCHER Dust coll ring P1AM |
| 705 | 4932373725 | HANDLE PHE P1 A/M |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Milwaukee websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Milwaukee brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Milwaukee PLH32XE
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK AEG S/N:
- AEG S/N START WITH (4) or (5) AND HAVE 10 DIGITS
