Milwaukee K500S Demolition Hammer Parts
€20.90
Tax included
Milwaukee K500S Demolition Hammer Spare Parts
Fix Your Milwaukee K500S Demolition Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Milwaukee K500S Demolition Hammer Spare Parts
Fix Your Milwaukee K500S Demolition Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill Driver and their spare part.
| Milwaukee K500S CHIPPING HAMMER IN2 Spare Parts 4933398220 - K500S - 4000398258 Pag.1 |
||
| # | Part Num. | Description |
| 4 | 4931624585 | CONNECTION CABLE |
| 8 | 4931398270 | RATING PLATE - Discontinued |
| 12 | 4931398272 | STRIP-BAND |
| 14 | 4931398238 | HANDLE COMPL. |
| 71 | 4931398276 | INSERT |
| 100 | 4931398203 | MOTOR HOUSING |
| 105 | 4931442747 | ELECTRIC FIELD |
| 106 | 4931442685 | ARMATURE |
| 107 | 4931398185 | FAN |
| 110 | 4931398508 | DUST SEAL |
| 111 | 4931426441 | BEARING END PLATE |
| 112 | 4931624541 | SCREW |
| 114 | 4931890311 | LOCKING RING |
| 115 | 4931398198 | SEAL RING |
| 116 | 4931405703 | AIR DEFLECTOR RING |
| 118 | 4931398204 | MOTOR CAP |
| 119 | 4931624542 | SCREW D7500-1CE M6x60 T30 TAPT 2000 A2F |
| 120 | 4931398208 | PAIR HANDLE SHELLS |
| 121 | 4931339996 | SCREW |
| 122 | 4931398206 | GEAR BOX INSULATION |
| 123 | 4931624263 | WIRE |
| 124 | 4931624538 | SCREW |
| 125 | 4931256500 | CABLE COLLAR |
| 128 | 4931398131 | SLIDER |
| 129 | 4931624517 | SCREW N874101-1 SHR H-K4X22 T15 |
| 130 | 4931381694 | BRUSH HOLDER |
| 131 | 4931624504 | SCREW |
| 132 | 4931409100 | ELECT.CIRCUIT BOARD |
| 133 | 4931398114 | LIGHT PIPE |
| 135 | 4931375458 | SWITCH |
| 156 | 4931398095 | BEARING |
| 158 | 4931398746 | BEARING BOLT |
| 200 | 4931409532 | GEAR BOX |
| 212 | 4931426453 | GEAR BOX COVER |
| 214 | 4931624555 | SCREW |
| 236 | 4931409600 | CRANK WHEEL |
| 237 | 4931398026 | SPINDLE |
| 238 | 4931417457 | SPINDLE SLEEVE |
| 239 | 4931398031 | BACK-PRESSURE RING |
| 241 | 4931398032 | DISC |
| 246 | 4931455433 | PERCUSSION BODY |
| 258 | 4931398747 | PISTON COMPL. |
| 268 | 4931398078 | SET COLLAR |
| 270 | 4931621847 | NEEDLE BEARING |
| 273 | 4931398154 | ADJUSTING PIECE |
| 274 | 4931398075 | LOCKING PLATE |
| 275 | 4931398626 | SWITCH |
| 282 | 4931624479 | RING |
| 288 | 4931398091 | THRUST COLLAR |
| 290 | 4931624499 | DISC |
| 291 | 4931398658 | LATCH PLATE |
| 292 | 4931624236 | SCREW |
| 293 | 4931398097 | THRUST PIECE |
| 295 | 4931398099 | PRESSURE SPRING |
| 297 | 4931624535 | DISC |
| 305 | 4931398216 | SLEEVE |
| 306 | 4931426248 | INTERLOCK SLEAVE |
| 309 | 4931398856 | PRESSURE SPRING |
| 310 | 4931426013 | PROTECTIVE CAP |
| 406 | 4931449971 | ARMATURE |
| 700 | 4931455774 | CARRYING CASE |
| 1200 | 4931398232 | MAINTENANCE SET |
| 1201 | 4931398132 | CARBON BRUSH SET |
| 1204 | 4931622166 | O-RING N874701 26X3 |
| 1205 | 4931393422 | PROTECTING COVER |
| 1207 | 4931398748 | DAMPING ELEMENT |
| 1208 | 4931398101 | SEALING SLEEVE |
| 1209 | 4931398085 | RUBBER SLEEVE |
| 1210 | 4931624440 | SEAL RING |
| 1212 | 4931398578 | SNAP DIE |
| 1213 | 4931398297 | O-RING (FKM) |
| 1216 | 4931398539 | SEAL |
| 1219 | 4931398105 | DAMPING ELEMENT |
| 1220 | 4931398033 | CORE LIFTER RING |
| 1221 | 4931398073 | RING |
| 1222 | 9170319040 | SPRING RING |
| 1223 | 4931398068 | INTERLOCK ELEMENT - Discontinued |
| 1224 | 4931398034 | SEAL RETAINER |
| 1225 | 4931398080 | INTERLOCK DISC |
| 1226 | 4931624495 | SEAL RING |
| 1227 | 4931398064 | RUBBER CAP |
| 1228 | 4931409768 | HOLDING-DOWN DEVICE |
| 1230 | 4931426013 | INTERLOCK ELEMENT |
| 1231 | 4931398298 | WASHER |
| 1234 | 4931398189 | GROOVED BALL BEAR. |
| 1235 | 4931341741 | BALL BEARING |
| 1236 | 4931426570 | MAGNETIC DISC |
| 1238 | 4931409781 | STOP WASHER |
| Accessories Pag.2 | ||
| 1500 | 4932343740 | SDS-Max Gouge 300 x 26 |
| 1501 | 4932451354 | SDS-Max ground rod driver 13.3 mm |
| 1502 | 4932343739 | SDS-Max Flat 600 x 25 |
| 1503 | 4932343734 | SDS-Max Pointed 280 mm |
| 1504 | 4932343747 | SDS-Max Spade 400 x 110 |
| 1505 | 4932352918 | SDS-Max Surface treatment / bushing tool 50 mm |
| 1506 | 4932399234 | SDS-Max Tile Removal 300 x 80 |
| 1507 | 4932343743 | SDS-Max Wide 400 x 50 |
| 1508 | 4932343771 | SDS-Max Universal Taper Shank 300 mm |
| 1509 | 9170086960 | Dust guard cap |
| 1510 | 4932399128 | Drill Connect |
| 1511 | 4932359490 | SDS-Max - SDS-Plus |
