Milwaukee AG21-230E Parts
€23.12
Tax included
Milwaukee AG21-230E Angle Grinder Spare Parts
Fix Your Milwaukee AG21-230E 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Milwaukee AG21-230E Angle Grinder Spare Parts
Fix Your Milwaukee AG21-230E 230 mm. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Drill Driver and their spare part.
| Milwaukee ANGLE GRINDER AG21-230E Spare Parts IN2 4933402515 - AG21-230E - 4000402516 Pag.1 |
||
| # | Part Num. | Description |
| 4 | 4931455392 | CONNECTION CABLE |
| 5 | 4931387206 | PROTECTING COVER |
| 6 | 4931622765 | SCREW N874101-1 SHR C-K5X45/20 KOMBITORX |
| 10 | 4931402518 | RATING PLATE |
| 100 | 4931402172 | MOTOR HOUSING |
| 103 | 4931455338 | SWITCH HANDLE |
| 105 | 4931426289 | ELECTRIC FIELD |
| 106 | 4931442690 | ARMATURE |
| 107 | 4931334394 | FAN |
| 108 | 4931341741 | BALL BEARING |
| 109 | 4931329086 | RUBBER SLEEVE |
| 110 | 4931329084 | SEAL RING |
| 114 | 4931402271 | AIR DEFLECTOR RING |
| 116 | 4931381694 | BRUSH HOLDER |
| 117 | 4931402169 | COVER |
| 118 | 4931624538 | SCREW |
| 119 | 4931331734 | SCREW |
| 121 | 4931619992 | SPRING WASHER D 137 B 4 |
| 126 | 4931624537 | SCREW |
| 131 | 4931369479 | CARBON BRUSH SET |
| 135 | 4931476614 | SWITCH |
| 141 | 4931329273 | CABLE COLLAR |
| 144 | 4931618253 | SCREW |
| 147 | 4931402013 | DUST SEAL |
| 156 | 4931402286 | DUST SEAL |
| 200 | 4931402161 | GEAR BOX |
| 201 | 4931621981 | SLEEVE |
| 202 | 4931621629 | DISC N874237 22,5X35X0,3 |
| 204 | 4931624305 | BALL BEARING |
| 205 | 4931622897 | DISC |
| 206 | 4931334400 | LOCKING RING |
| 209 | 4931402166 | LOCKING BOLT |
| 210 | 4931329173 | PRESSURE SPRING |
| 212 | 4931622764 | O-RING |
| 216 | 4931402546 | DRIVE GEAR |
| 218 | 4931407540 | GEAR ENDPLATE |
| 219 | 4931624672 | SEAL RING |
| 220 | 9170316990 | BEARING |
| 223 | 4931402150 | BEARING COVER |
| 224 | 4931624147 | SCREW D 7500 M 3X12 |
| 225 | 4931279734 | RUBBER SLEEVE |
| 226 | 4931329178 | GREASE RETAIN.DISC |
| 227 | 4931329494 | NUT |
| 228 | 4931409592 | BEVEL GEAR PAIR |
| 232 | 4931409816 | SPINDLE |
| 235 | 4931623312 | WASHER N874237 |
| 236 | 4931624701 | DISC |
| 237 | 4931622747 | COMPENSATING WASHER |
| 238 | 4931624591 | WASHER |
| 239 | 4931941094 | DISC N874237 18X27,9X0,5 |
| 242 | 4931329150 | GASKET |
| 600 | 4931426625 | GUARD CAP |
| 601 | 201256002 | CATCH LEVER |
| 602 | 4931402063 | FLANGE |
| 603 | 4931402089 | PRESSURE SPRING |
| 604 | 4931624491 | SCREW |
| Accessori Pag.2 | ||
| 702 | 4932367712 | PIN SPANNER 115-230/WP/WSAP1 A/M |
| 703 | 4931433531 | HANDLE 180-230/WP/WSA P1A/M |
| 710 | 4932449324 | CLAMPING FLANGE WS115-230 P1 A/M |
| 711 | 4932345628 | FLANGE NUT M14 3MM P1 A/M |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Milwaukee websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Milwaukee brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Milwaukee AG21-230E
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK AEG S/N:
- AEG S/N START WITH (4) or (5) AND HAVE 10 DIGITS
