Alpina Spare Parts for Petrol Hedge Trimmer AHT 60
€6.54
Tax included
Alpina Spare Parts for Petrol Hedge Trimmer AHT 60
We have the original ALPINA parts and tool repair help you need to get your tools running like new again.Fix Your Petrol Hedge Trimmer AHT 60/252961004/A20-2020. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Petrol Hedge Trimmer AHT 60
Fix Your Petrol Hedge Trimmer AHT 60/252961004/A20-2020. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Open file PDF in this page for to choose position spare parts for Hedge Trimmer Alpina AHT 60.
| Petrol Hedge Trimmer AHT 60/252961004/A20-2020 | ||
| Engine A Pag.1 | ||
| # | Part Num. | Description |
| 2 | 123878109/0 | Screw |
| 3 | 183082003/0 | Starter Cup Assembly |
| 7 | 118802744/0 | Flywheel |
| 8 | 123878081/0 | Screw |
| 9 | 123657017/0 | Washer |
| 10 | 123657013/0 | Washer |
| 11 | 119035164/0 | Oil Seal |
| 13 | 123685020/0 | Crankcase |
| 14 | 114215222/0 | Ball bearing |
| 15 | 123020033/1 | Crankshaft |
| 17 | 123280077/0 | Crankcase Gasket |
| 19 | 119035165/0 | Oil Seal |
| 21 | 123445268/0 | Clutch hub |
| 23 | 183215010/0 | Clutch assembly |
| 25 | 123878111/0 | Screw |
| 26 | 123065045/0 | Spark plug cable |
| 27 | 123878081/0 | Screw |
| 28 | 123657013/0 | Washer |
| 29 | 123657017/0 | Washer |
| 30 | 118802743/0 | Ignition coil assy |
| 31 | 123160063/0 | Spacer |
| 32 | 123652505/0 | Washer |
| 33 | 123235008/0 | Needle Bearing |
| 34 | 183590007/0 | Piston assembly |
| 37 | 123204016/0 | Piston ring |
| 38 | 123280078/0 | Cylinder gasket |
| 39 | 123878081/0 | Screw |
| 40 | 118802742/0 | Muffler |
| 42 | 123600078/0 | Heat Guard |
| 43 | 3210024 | Spark plug |
| 44 | 123071023/0 | Cylinder |
| 45 | 123280080/0 | Intake Manifold Gasket |
| 47 | 118801419/0 | Intake manifold |
| 48 | 112789195/0 | Screw |
| 49 | 118801420/0 | Spark plug cover |
| 50 | 123600080/0 | Cylinder cover |
| 51 | 118801421/0 | Carburetor gasket |
| 52 | 118801422/0 | Carburetor |
| 53 | 118801423/0 | Air Filter Base |
| 54 | 123878114/0 | Screw |
| 55 | 118801424/0 | Air filter |
| 56 | 118805223/0 | Air Filter Cover, Gray |
| 57 | 118802164/0 | Air lever, black |
| 58 | 118804984/0 | Engine Short Block |
| 59 | 118804985/0 | Cylinder/Piston Assembly |
| Engine B Pag.2 | ||
| 1 | 123300014/0 | Front handle |
| 2 | 123878121/0 | Screw |
| 3 | 118805224/0 | Muffler cover grey |
| 4 | 123430606/0 | Spring |
| 6 | 123657017/0 | Washer |
| 8 | 123784008/0 | Handle support case |
| 9 | 123430607/0 | Spring |
| 10 | 123790023/0 | Spring Cap, Black |
| 11 | 123878121/0 | Lives |
| 13 | 118801432/0 | Knob |
| 14 | 123700065/0 | Left Handle |
| 15 | 118801433/0 | Spring |
| 16 | 123315099/0 | Lock lever |
| 17 | 118801434/0 | Safety Lever, Black |
| 18 | 123430609/0 | Spring |
| 19 | 118801436/0 | Throttle lever |
| 20 | 123700066/0 | Right handle |
| 21 | 123303007/0 | Switch |
| 22 | 123202008/0 | Lock handle |
| 23 | 123878115/0 | Screw |
| 24 | 123657023/0 | Rubber |
| 25 | 123044223/0 | Bush |
| 26 | 123878124/0 | Screw |
| 27 | 118801438/1 | Fuel Tank |
| 28 | 123275031/0 | Rubber |
| 29 | 118801439/0 | Fuel Tank cap |
| 36 | 183520009/0 | Intake Filter |
| 37 | 123867028/0 | Fuel Pipe |
| 38 | 1232940080 | Wire guide platte |
| 40 | 123867029/0 | Fuel Pipe |
| 41 | 123275032/0 | Rubber pipe Grommet |
| 42 | 118801440/0 | Starting handle |
| 43 | 123234007/0 | Starting rope |
| 45 | 118805225/1 | Recoil Starter Assembly Grey |
| 46 | 123430610/0 | Starter spring |
| 47 | 123604013/0 | Starter Pulley |
| 48 | 112728445/0 | Screw |
| 49 | 118801443/0 | Cylinder cover grey |
| 49 | 118805287/0 | Cylinder cover black |
| 50 | 112735654/0 | Screw |
| 51 | 118801446/0 | Engine cover grey |
| 51 | 118805288/0 | Engine cover black |
| 53 | 118801447/0 | Throttle cable |
| 54 | 118801448/0 | Cable clamp |
| 55 | 112726389/0 | Screw |
| 56 | 118804986/0 | Handle assembly |
| 57 | 118804987/0 | Fuel tank assembly black |
| 57 | 118804987/1 | Fuel tank assembly black |
| 57 | 118805247/0 | Fuel tank assembly white |
| Blade Pag.3 | ||
| 1 | 123050010/0 | Clutch drum |
| 2 | 123657013/0 | Washer |
| 3 | 123657017/0 | Washer |
| 5 | 123685022/0 | Upper Carter |
| 6 | 123657013/0 | Washer |
| 7 | 123657017/0 | Washer |
| 8 | 123878081/0 | Screw |
| 9 | 123280082/0 | Crankcase Gasket |
| 11 | 112379520/0 | Greaser nipple |
| 12 | 114215222/0 | Ball bearing |
| 15 | 123570052/0 | Pinion |
| 16 | 114215223/0 | Bearing |
| 17 | 123664000/0 | Sprocket |
| 18 | 123041502/0 | Connecting rod |
| 21 | 123685023/0 | Lower Carter |
| 22 | 123878081/0 | Screw |
| 24 | 123878118/0 | Screw |
| 26 | 123878110/0 | Screw |
| 27 | 123878113/0 | Screw |
| 28 | 123294006/0 | Lower Blade guide |
| 29 | 123044222/0 | Bush |
| 30 | 123305004/0 | Blade |
| 31 | 123120014/0 | Nut |
| 32 | 123600081/0 | Blade protection guard |
| 33 | 123294007/0 | Upper blade guide |
| 35 | 123085002/0 | Blade cover |
| 36 | 118804982/0 | Engine Support Assembly |
| 37 | 118804983/0 | Blade assembly |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AHT60 - 252961004/A20-2020
5 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
