Michelin Spare Parts for Pressure Washer MPX 100
€22.82
Tax included
Michelin Spare Parts for Pressure Washer MPX 100
Distribution and Sale at attractive prices of MICHELIN Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Pressure Washer MPX 100 – 12890 - MPX 100 – 13973.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Michelin Spare Parts for Pressure Washer MPX 100
Distribution and Sale at attractive prices of MICHELIN Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Pressure Washer MPX 100 – 12890 - MPX 100 – 13973.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| Pressure Washer MPX 100 – 12890 - MPX 100 – 13973 | ||
| Casing MPX 100 – 12890 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 3080580 | Cable Clamp |
| 2 | 3082820 | Blue Casing |
| 3 | 3082130 | Water Connection Kit |
| 4 | 50940 | Cable |
| 5 | 50953 | Pre-Assembly Electric Pump |
| 6 | 3082670 | Stopper |
| 7 | 3082770 | Switch |
| 8 | 50942 | Accessory Cases |
| 9 | 3080880 | Stopper |
| 10 | 50944 | Basis |
| 11 | 50947 | Accessory Cases |
| 12 | 3082350 | TSS Kit |
| 13 | 3081270 | Kit + Piston Seals |
| 14 | 3081290 | Valve Kit + Seals |
| 15 | 3082570 | Motor Brush Kit |
| Accessories MPX 100 – 12890 Pag.2 | ||
| 1 | 3082281 | Gun |
| 2 | 50955 | Lancia + Head |
| 3 | 50954 | Tank |
| 4 | 3081300 | High Pressure Tube |
| Bonnet MPX 100 – 13973 Pag.3 | ||
| 1 | 3080580 | Cable Clamp |
| 2 | 3082820 | Blue Bonnet |
| 3 | 3082130 | Water Connection Kit |
| 4 | 50940 | Cable |
| 5 | 50953 | Pre-Assembly Electric Pump |
| 6 | 3082670 | Stopper |
| 7 | 3082770 | Switch |
| 8 | 50942 | Accessory Cases |
| 9 | 3080880 | Stopper |
| 10 | 50944 | Basis |
| 11 | 50947 | Accessory Cases |
| 12 | 3082350 | TSS Kit |
| 13 | 3081270 | Kit + Piston Seals |
| 14 | 3081290 | Valve Kit + Seals |
| 15 | 3082570 | Motor Brush Kit |
| Accessories MPX 100 – 13973 Pag.4 | ||
| 1 | 3082281 | Gun |
| 2 | 50955 | Lancia + Head |
| 3 | 50954 | Tank |
| 4 | 3081300 | High Pressure Tube |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi&Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi&Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Michelin MPX 100 12890 – 13973
5 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
