Michelin Spare Parts for Pressure Washer MPX 150 HL
€19.96
Tax included
Michelin Spare Parts for Pressure Washer MPX 150 HL
We have the original Spares Michelin for Pressure Washer MPX 150 HL - 24332, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Michelin Spare Parts for Pressure Washer MPX 150 HL
Fix Your Pressure Washer MPX 150 HL - 24332. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| Pressure Washer MPX 150 HL - 24332 | ||
| Casing Pag.1 | ||
| # | Part Num. | Description |
| 1 | 3520090 | Casing |
| 2 | 3520520 | Foot |
| 3 | 3520260 | Gland |
| 4 | 3520230 | Wheel |
| 5 | 3520240 | Washer |
| 6 | 3520252 | Guard |
| 7 | 3520170 | Tank |
| 8 | 3520180 | Plug |
| 9 | 3520210 | Support |
| 10 | 3520080 | Black casing |
| 11 | 3520190 | Handle |
| 12 | 3520870 | Cable |
| 13 | 3523560 | Vibration damper |
| 14 | 3520200 | Support |
| Pump Pag.2 | ||
| 1 | 1344970 | O-ring |
| 2 | 3520370 | Fitting |
| 3 | 2901060 | Injector |
| 4 | 800560 | O-ring |
| 5 | 1080091 | Spring |
| 6 | 2901070 | Shutter |
| 7 | 1460430 | O-ring |
| 8 | 1344850 | Head |
| 9 | 1349055 | Valve |
| 10 | 1344770 | Spacer |
| 11 | 1465720 | O-ring |
| 12 | 1344800 | Plug |
| 13 | 1344790 | Fork |
| 14 | 850850 | Screw |
| 15 | 620301 | Plug |
| 16 | 2500280 | Elbow |
| 17 | 1342701 | Seat |
| 18 | 600180 | O-ring |
| 19 | 1460151 | Piston |
| 20 | 2021900 | Piston |
| 21 | 1080190 | O-ring |
| 22 | 600180 | O-ring |
| 23 | 1080401 | Ring |
| 24 | 820510 | O-ring |
| 25 | 740290 | O-ring |
| 26 | 1344870 | Piston guide |
| 27 | 1343450 | Wobble plate |
| 28 | 1460190 | Spring |
| 29 | 1980220 | Wobble plate |
| 30 | 2500550 | Split pin |
| 31 | 1344881 | Insert |
| 32 | 1980740 | Plug |
| 33 | 1060120 | Nut |
| 34 | 1345020 | Plug |
| 35 | 620301 | Plug |
| 36 | 1344890 | Plug |
| 37 | 2560870 | O-ring |
| 38 | 2460180 | O-ring |
| 39 | 770260 | O-ring |
| 40 | 1344750 | Piston guide |
| 41 | 1260440 | Water seal |
| 42 | 1344760 | Ring |
| 43 | 1344050 | Pump body |
| 44 | 1260050 | Bushing |
| 45 | 1040710 | O-ring |
| 46 | 1344060 | Cover |
| 47 | 1260780 | Screw |
| 48 | 880840 | O-ring |
| 49 | 1343900 | Plug |
| 50 | 880111 | Key |
| 51 | 1341070 | Bearing |
| 52 | 480890 | Ring |
| 53 | 111120 | Ring |
| 54 | 1341080 | Ring |
| 55 | 1340060 | Connecting-rod |
| 56 | 1340080 | Pin |
| 57 | 1340070 | Piston |
| 58 | 1260460 | Oil seal |
| 59 | 600180 | O-ring |
| 60 | 1341010 | Plate |
| 61 | 1342740 | Piston |
| 62 | 1341020 | Washer |
| 63 | 850670 | Screw |
| 64 | 1340170 | Shaft |
| 65 | 1120680 | O-ring |
| 66 | 600180 | O-ring |
| 67 | 2022040 | Pin |
| 68 | 2021630 | Spring |
| 69 | 2021650 | Washer |
| 70 | 1260820 | O-ring |
| 71 | 1344830 | Fitting |
| 72 | 42580 | TSS Retrofit kit |
| 73 | 1349297 | Pump assembly |
| 74 | 1349114 | Head assembly |
| 75 | 42579 | Valve kit adjustment |
| 76 | 3520360 | Fitting |
| A | 42566 | Valve kit |
| B | 2623 | Piston kit |
| C | 1876 | Oil seal kit |
| D | 42567 | Water seal kit |
| F | 42568 | Gasket kit |
| Motor Pag.3 | ||
| 1 | 1260300 | Fan |
| 2 | 1340350 | Seal |
| 3 | 1260760 | Screw |
| 4 | 1340320 | Shield |
| 5 | 1340340 | Bearing |
| 6 | 3523500 | Connector |
| 7 | 1260490 | Washer |
| 8 | 2020570 | Screw |
| 9 | 1340780 | Gasket |
| 10 | 1341831 | Box |
| 11 | 1261560 | Screw |
| 12 | 1261560 | Screw |
| 13 | 1340280 | Clamp |
| 14 | 1263520 | Capacitor |
| 15 | 1342040 | Fan cowling |
| 16 | 2029752 | TSS box assembly |
| 17 | 2022201 | Fork |
| 18 | 44534 | Motor |
| 19 | 1340660 | Gland |
| 20 | 1340640 | Ring nut |
| 21 | 1340650 | Gland |
| 22 | 1262400 | Washer |
| Boiler Pag.4 | ||
| 1 | 3520630 | Resistance |
| 2 | 3520620 | Pin |
| 3 | 3520610 | Clamp |
| 4 | 3520600 | Plate |
| 5 | 3520590 | Plate |
| 6 | 3520330 | Cover |
| 7 | 3520790 | Valve |
| 8 | 3520800 | Fan - Substituited by Kit 352080 |
| 9 | 3520320 | Box - Substituited by Kit 352080 |
| 10 | 3520810 | Boiler Motor - Substituited by Kit 352080 |
| 11 | 3520310 | Cover |
| 12 | 3523570 | Boiler |
| 13 | 3520860 | Transformer |
| 14 | 3520770 | Cable |
| 15 | 3520650 | Gasket |
| 16 | 3520660 | Element |
| 17 | 3520670 | Support |
| 18 | 3520680 | Nozzle |
| 19 | 3520690 | Flange |
| 20 | 3520710 | Plate |
| 21 | 3520700 | Electrode |
| 22 | 3520820 | Cover |
| Fuel Circuit Pag.5 | ||
| 1 | 3522760 | Pump |
| 2 | 3520730 | Hose tail |
| 3 | 3520740 | Clamp |
| 4 | 3520750 | Pipe |
| 5 | 3520760 | Filter |
| 6 | 3520750 | Pipe |
| Water Circuit Pag.6 | ||
| 1 | 3521470 | Pipe |
| 2 | 3520490 | Fork |
| 3 | 3520420 | Fitting |
| 4 | 3520430 | Piston |
| 5 | 3520440 | Spring |
| 6 | 3520450 | Bushing |
| 7 | 3520460 | O-ring |
| 8 | 3520510 | Fork |
| 9 | 3520480 | Plug |
| 10 | 3520500 | O-ring |
| 11 | 3520540 | Ring |
| 12 | 3520240 | Washer |
| 13 | 3520410 | O-ring |
| 14 | 3520530 | Fitting |
| 15 | 3520580 | Washer |
| 16 | 3520570 | Screw |
| 17 | 3520930 | Thermostat |
| 18 | 3520470 | O-ring |
| Electric Circuit Pag.7 | ||
| 1 | 3520270 | Knob |
| 2 | 3520280 | Shim |
| 3 | 3520300 | Element |
| 4 | 3520290 | O-ring |
| 5 | 3520340 | O-ring |
| 6 | 3520350 | Fuse holder |
| 7 | 3520850 | Switch |
| 8 | 3520840 | Board |
| Standard Accossories Pag.8 | ||
| 1 | 41047 | Gun |
| 2 | 50690 | Lance |
| 3 | 3104 | Nozzle |
| 4 | 40320 | Tank |
| 5 | 3520550 | High pressure hose |
