We are MICHELIN original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Piston Air Compressors VCX 100.
In the following table, look for the type of the air compressor and the respective parts of the code.![]()
| VCX 100-3 validity date - from 09/11/2007 to 03/11/2011 | ||
| # | Part Num. | Description |
| 1 | 5011970008 | Bracket |
| 2 | 7370050000 | V-belt A 43 |
| 3 | 7381390000 | SINGLE PHASE MOTOR |
| 4 | 7011100000 | Screw M8X25 UNI-5739 |
| 5 | 7030030000 | Washer Ø8 UNI-6592 |
| 6 | 7408140000 | Pulley op 90 F 19 A |
| 7 | 7360020000 | rubber Ø16 |
| 8 | 7030030000 | Washer Ø8 UNI-6592 |
| 9 | 7020070000 | Nut M8 UNI-5587 |
| 10 | 7030040000 | Washer Ø10 UNI-6592 |
| 11 | 7011140000 | Screw M10x20 UNI-5739 |
| 12 | 7100550000 | Pressure reducer |
| 13 | 7090030000 | Cap M1 / 2 " |
| 14 | 7020100000 | Nut M12 UNI-5588 |
| 15 | 7030140000 | Washer Ø12 UNI-6592 |
| 16 | 7240480000 | Belt Guard RT 51 VB 50/350 |
| 17 | 7260110000 | Wheel pivot Ø80X21 |
| 18 | 7011230000 | Screw M12X80 UNI-5739 |
| 19 | 7030200000 | Washer Ø12X36X2,5 UNI-6593 |
| 20 | 7330010000 | wheel spacer |
| 21 | 7260060000 | Wheel Ø175X45 F20 |
| 22 | 7030140000 | Washer Ø12 UNI-6592 |
| 23 | 7020100000 | Nut M12 UNI-5588 |
| 24 | 7130160000 | Drain Valve M3/8" |
| 25 | 7459410000 | Belt Guard bracket |
| 26 | 7234140000 | tube feeding |
| 27 | 7190090000 | Check valve MM 1/2 "-DX |
| 28 | 7192090000 | Safety Valve 3/8 "10,4BAR |
| 29 | 7088060000 | Fitting MM 3 / 8-1 / 4 CIL 3/8 |
| 30 | 7110060000 | Pressure gauge |
| 31 | 7250740000 | pressure Switch |
| 32 | 7328690000 | Cable Pressure / Motor |
| 33 | 7329070000 | power cable |
| 34 | 7090070000 | Cap M1 / 4 " |
| 35 | 7196340000 | Drain valve M1/8 |
| 36 | 5154700008 | tank 150lt |
| 37 | 7422160000 | Pump unit AB17 |
| 38 | 7023050000 | Nut 3/8 " |
| 39 | 7011110000 | Screw M8x30 UNI-5739 |
| * | 7310860000 | CAPACITOR MF.55 450V HP.3-CIMA-- |
