Metabo Mitre Saw KGSV 216 MC Parts
€10.42
Tax included
Metabo Spare Parts for Mitre Saw KGSV 216 MC
Metabo original spare parts for to replace broken parts for to fix Mitre Saw KGSV 216 MC - 15216000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Mitre Saw KGSV 216 MC
Metabo original spare parts for to replace broken parts for to fix Mitre Saw KGSV 216 MC - 15216000.In the following table, look for the model of the Mitre Saw and the respective parts of the code.
| KGSV 216 MC - 15216000 | ||
| # | Part Num | Description |
| 1 | 316088210 | Carbon brush holder compl. |
| 2 | 316088220 | Motor cover compl. |
| 3 | 316060610 | Flange compl. |
| 4 | 316088230 | Carbon brush compl. |
| 5 | 316088240 | LED compl. |
| 6 | 343093650 | Electronic unit compl. |
| 7 | 310014580 | Stator |
| 8 | 310014590 | Armature |
| 9 | 316088250 | Gear housing |
| 10 | 343254900 | Condenser |
| 11 | 316088260 | Carry handle comp. |
| 12 | 343413080 | Switch |
| 13 | 343090190 | Power supply |
| 14 | 316088270 | Turning table comp. |
| 15 | 316073870 | base cpl. |
| 16 | 316088280 | Moving guard comp. |
| 17 | 316088290 | Foot compl. |
| 18 | 316088300 | strain relieve compl. |
| 19 | 316088310 | Wheel guard cpl. |
| 20 | 316075410 | Switch trigger compl. |
| 23 | 316088320 | Chop arm compl. |
| 24 | 316088330 | Tilting arm cpl. |
| 25 | 316088340 | Handle compl. |
| 26 | 316075420 | Detent cpl. |
| 27 | 316073960 | Handle compl. |
| 28 | 315421110 | Table side extension right |
| 29 | 315421090 | Table side extension left |
| 30 | 316088350 | Motor housing compl. |
| 31 | 316075690 | Workpiece holder compl. |
| 32 | 343457630 | Clamping lever |
| 33 | 316088360 | Stop compl. |
| 34 | 316088370 | Stabilizer cpl. |
| 35 | 343457320 | Table insert |
| 37 | 316088380 | Dust etraction kit compl. |
| 38 | 343435780 | Cover dust collector |
| 39 | 343436260 | Extraction funnel |
| 40 | 343457490 | Cable Holder |
| 41 | 316088390 | Spindle lock comp. |
| 42 | 316075470 | Saw head lock comp. |
| 43 | 316088400 | Depth stop compl. |
| 44 | 316088410 | tipping axis compl. |
| 46 | 344113030 | Plug in buffer |
| 48 | 316056820 | Set screw compl. |
| 49 | 316088420 | Scale set compl. |
| 50 | 316088430 | Motor compl. |
| 52 | 316075550 | End stop cpl. |
| 53 | 316075520 | Bevel clamping comp. |
| 55 | 341722210 | Stop screw |
| 57 | 344113040 | Rubber bushing |
| 58 | 316075510 | Tool holder col. |
| 61 | 338084780 | Rating plate 15216000 KGSV 216 MC |
| 62 | 341113050 | Star grip screw |
| 63 | 343457560 | Clamping cap |
| 65 | 320054870 | Ball bearing |
| 66 | 320054880 | Ball bearing |
| 67 | 339146080 | Sliding sheet |
| 68 | 316088440 | Screw set |
| 880 | 344130970 | Grease 50Gr 1,8oz |
| 1001 | 338511350 | Diagram |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo KGSV 216 MC - 15216000
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
