Metabo Spare Parts for Band Saw BAS 316 G WNB
€1.57
Tax included
Metabo Spare Parts for Band Saw BAS 316 G WNB - 0090431609 10
Metabo original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Band SawBAS 316 G WNB - 0090431609 10 - EU 230V.Fix Your Band Saw BAS 316 G WNB. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Band Saw BAS 316 G WNB - 0090431609 10
Fix Your Band SawBAS 316 G WNB - 0090431609 10 - EU 230V. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Band Saw and the respective parts of the code.
| BAS 316 G WNB - 0090431609 10 - EU 230V | ||
| # | Part Num. | Description |
| 1. | 6301000292 | SPRING LOCK WASHER B 16 VERZ. (86301000292) |
| 2. | 6442084635 | SPACER SLEEVE RD 11/8,5X40 VERZ. (86442084635) |
| 3. | 1382421333 | TENSION BRACKET FL 25X5X175 (81382421333) |
| 4. | 1382051390 | ROLLER GUIDE BL 2,99X128X165 (81382051390) |
| 5. | 6500087283 | PARALLEL PIN 10 h11X100 (86500087283) |
| 6. | 7016050711 | STARLOCK (87016050711) |
| 7. | 1485051453 | BEARING SHAFT RD 21X75 ET (81485051453) |
| 8. | 7100047254 | DEEP GROOVE BALL BEARING 17X40X12 6203-2 (87100047254) |
| 9. | 1380421360 | BANDSAW WHEEL, UPPER (81380421360) |
| 10. | 7232055833 | BANDSAW TYRE 310X2,5X20 70 +/-5 SHORE old cod 7232055833 (344101930) |
| 11. | 6400047357 | RETAINING RING FOR SHAFTS 17X1 (86400047357) |
| 13. | 1009003955 | SWITCH WN WN (81009003955) |
| 14. | 7052215689 | LEAF SPRING (87052215689) |
| 15. | 1383666364 | DOOR ET (81383666364) |
| 16. | 1381666359 | Welding Hinge |
| 17. | 1381666332 | WELDING HINGE ET (81381666332) |
| 18. | 1381666340 | WELDING HINGE ET (81381666340) |
| 19. | 7014666391 | Latch Actuator Assembly |
| 20. | 6200050477 | HEXAGON NUT M 16X1,5 VERZ. (86200050477) |
| 21. | 6209110995 | Flange nut (6209110995) |
| 22. | 6103001178 | Hex head screw (86103001178) |
| 23. | 1381144590 | LAMELLAR PLUG 100X60X3,2 VL SCHWARZ (81381144590) |
| 24. | 6241133255 | KNURLED THUMB NUT RD 62,5 M 8 (86241133255) |
| 25. | 1009010820 | BLADE TENSIONER (81009010820) |
| 26. | 1009010323 | Tension Bracket |
| 27. | 7005135529 | Thumb-nut (87005135529) |
| 28. | 7001047374 | STARKNOB SCREW M 8X65 (DIN 558) VERZINKT (87001047374) |
| 29. | 7000028937 | STARKNOB NUT M 8 (DIN 934) VERZINKT (87000028937) |
| 30. | 6103001127 | Hex head screw (86103001127) |
| 31. | 6209114230 | Flange nut (86209114230) |
| 32. | 1382421260 | GUIDE BRACKET BL 1,50X25,0X135,0 (81382421260) |
| 33. | 6103015675 | Hex head screw (86103015675) |
| 34. | 7014140071 | LATCH SCHMAL (87014140071) |
| 35. | 6302085941 | WAVE SPRING WASHER B 12 VERZ. (86302085941) |
| 36. | 6103041013 | HEXAGON HEAD SCREW M 6X10 VERZ.FLECKBESC (86103041013) |
| 37. | 6110082701 | CUP SQUARE NECK SCREW M 8X100 VERZ. (86110082701) |
| 38. | 9132081414 | BRUSH STRIP (89132081414) |
| 39. | 6442084643 | SPACER SLEEVE RD 10,7/8,5X50 VERZ. (86442084643) |
| 40. | 6103001135 | Hex head screw (86103001135) |
| 41. | 6300016365 | Washer (86300016365) |
| 42. | 6110017942 | Truss head screw (86110017942) |
| 43. | 1383421370 | BLADE GUIDE TUBE EXTRUSION 360 MM (81383421370) |
| 44. | 1382083667 | BOLT GUIDE BL 1,5X22X60 (81382083667) |
| 45. | 1482071003 | PIN GUIDE SEAT FL 20X5X44 (81482071003) |
| 46. | 1382421341 | GUIDE PLATE BL 2X16X53,5 (81382421341) |
| 47. | 1381421259 | LATERAL SLIDE 45X95 (81381421259) |
| 48. | 2380113662 | PIPE ADAPTOR (82380113662) |
| 49. | 6172001830 | Fillister head screw (86172001830) |
| 50. | 6202002291 | HEXAGON NUT, PREV. TORQUE TYPE (86202002291) |
| 51. | 1009018022 | THREE-ROLLER GUIDE SCHIEBEROHRPROFIL (81009018022) |
| 52. | 1009010935 | THRUST BEARING ET (81009010935) |
| 53. | 1009010951 | THRUST BEARING, HEAVY-DUTY DREIROLLENF. (81009010951) |
| 54. | 7006072385 | Clamping lever (87006072385) |
| 55. | 1381053489 | CONNECTOR RD 100 SPA 1000 (81381053489) |
| 56. | 1381404400 | TABLE INSERT RD 70X5 SCHMALER SCHLITZ (81381404400) |
| 57. | 1381404419 | TABLE INSERT RD 70X5 BREITER SCHLITZ (81381404419) |
| 58. | 1380421212 | BANDSAW TABLE 400X548 ET (81380421212) |
| 59. | 1141086363 | ADHESIVE LABEL WHITE/BLACK 270X195 SKALA (81141086363) |
| 60. | 1383421388 | GUIDE EXTRUSION 548 MM (81383421388) |
| 61. | 6304001745 | Serrated lock washer (86304001745) |
| 62. | 6150421509 | THUMB SCREW RED M 8X18 (86150421509) |
| 63. | 2380414310 | TABLE TRUNNION, UPPER F?R MONTAGE M. SK (82380414310) |
| 64. | 6300016322 | Washer (86300016322) |
| 65. | 6103001186 | HEXAGON HEAD SCREW M 8X20 VERZ. (86103001186) |
| 66. | 1393005307 | FENCE EXTRUSION 450 MM (81393005307) |
| 67. | 6110000616 | CUP SQUARE NECK SCREW M 6X40 VERZ. (86110000616) |
| 68. | 1380081896 | FENCE GUIDE 145X130X98 L?NGS (81380081896) |
| 69. | 6305002087 | Washer (86305002087) |
| 70. | 6241125058 | Knurled nut (86241125058) |
| 71. | 7001087775 | STARKNOB SCREW RD40/M6X28 (DIN 933) VERZ (87001087775) |
| 72. | 6110080245 | CUP SQUARE NECK SCREW M 8X50 VERZ. (86110080245) |
| 73. | 6103001208 | HEXAGON HEAD SCREW M 8X35 VERZ. (86103001208) |
| 74. | 1381092115 | GLIDE SEGMENT 20,5X20,5X8 TISCHVERSTELLU (81381092115) |
| 75. | 2380414301 | TABLE TRUNNION, LOWER F?R MONTAGE M. SK (82380414301) |
| 76. | 6172028215 | Fillister head screw (86172028215) |
| 77. | 1142414291 | Angle Scale |
| 78. | 1381666324 | CHIP CASE ET (81381666324) |
| 79. | 1485400172 | SLIDING BOLT RD 30X47 (81485400172) |
| 80. | 7100086764 | DEEP GROOVE BALL BEARING 12X28X8 6001-2Z (87100086764) |
| 81. | 1485400180 | TENSION ROLLER RD 35X28 (81485400180) |
| 82. | 6400009935 | RETAINING RING FOR SHAFTS (86400009935) |
| 83. | 1382666301 | SAFETY LEVER ET (81382666301) |
| 84. | 6307128940 | WASHER R 6,6 VERZ. (86307128940) |
| 86. | 1485051518 | BEARING SHAFT RD 25X124 UNTEN (81485051518) |
| 87. | 1382052818 | PILOT PIN 6,9X5,9X35 (81382052818) |
| 88. | 6143071144 | KNURLED THUMB SCREW M 6X25 VERZ. (86143071144) |
| 89. | 1009003602 | MOTOR, BANDSAW BAS 0,74 WNB 1X230 V (81009003602) |
| 90. | 6161050910 | HEX. SOCKET SET SCREW, FLAT PT M 6X12 VE (86161050910) |
| 91. | 1380044990 | GUIDE SUPPORT (81380044990) |
| 92. | 1009009570 | PILOT PIN GUIDE (81009009570) |
| 93. | 1382666387 | SAWBAND GUARD ET (81382666387) |
| 94. | 6205084779 | HEXAGON THIN NUT (86205084779) |
| 95. | 1482666317 | SPANNER SCHAFT ET (81482666317) |
| 96. | 7000074122 | STARKNOB NUT M 10 / RD 63 VERZINKT (87000074122) |
| 97. | 6300016349 | MEDIUM WASHER (86300016349) |
| 99. | 6200046208 | HEXAGON NUT M 20X1,5 VERZ. (86200046208) |
| 100. | 6304084047 | Serrated lock washer (86304084047) |
| 101. | 1380421352 | BANDSAW WHEEL, LOWER (81380421352) |
| 102. | 7240419429 | POLY-RIB PULLEY 4JX62 / RDA 62X47,5 RDI (87240419429) |
| 103. | 7233190017 | POLY-RIB BELT 4 PJ 610 (87233190017) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
