Metabo Spare Parts for Angle Grinder W 750-115 - 01230001
We are METABO original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 750-115 - 01230001.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Angle Grinder W 750-115 - 01230001
We are METABO original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 750-115 - 01230001.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Metabo W 750-115 / 01230001 / EU 230V Spare Parts | ||
| # | Part Num. | Description |
| 1 | 31400054 | Handle cpl. |
| 2 | 31604061 | SPINDLE STOP COMPL |
| 3 | 31606364 | Gear Housing compl. |
| 4 | 34110094 | HEXAGON NUT W.RECESS |
| 5 | 31605781 | BEVEL GEAR AND PINION |
| 6 | 14111046 | FILLISTER HEAD SCREW |
| 7 | 14311542 | Ball Bearing 8x 22x 7 |
| 8 | 31541749 | Fixed bearing cover |
| 9 | 34339274 | SEALING WASHER |
| 10 | 14311587 | Ball Bearing 6x 19x 6 |
| 11 | 31001198 | Armature, Complete 230V |
| 12 | 34409526 | Rubber bushing |
| 13 | 34339943 | Baffle |
| 14 | 34339945 | Cover |
| 15 | 14111602 | SELF-TAP FILL H SCREW |
| 16 | 14319592 | O-ring |
| 17 | 34116115 | SPINDLE M14 |
| 18 | 14319254 | O-ring |
| 19 | 31606378 | Flange compl. |
| 20 | 14112007 | FILL. HEAD SCREW |
| 21 | 34110690 | FLANGE NUT |
| 22 | 34103116 | CLAMPING FLANGE |
| 23 | 14112406 | FILLISTER HEAD SCREW |
| 24 | 33920366 | WHEEL GUARD COMPL. Ø115 |
| 25 | 33812216 | Metabo label, 08 52x22 |
| 26 | 34341051 | SWITCH SLIDE RED |
| 27 | 34339917 | SWITCH ROD |
| 28 | 34336249 | CABLE CLIP |
| 29 | 31101277 | Field Coil, 230V |
| 30 | 33806578 | RATING PLATE 01230000 W 750-115 |
| 31 | 34344483 | MOTOR HOUSING |
| 32 | 33812254 | METABO PLATE |
| 33 | 31605277 | CARBON BRUSH COMPL. |
| 35 | 34301295 | Brush holder |
| 36 | 34325503 | Capacitor |
| 37 | 34341188 | HY-28 SWITCH (230V+RSP) |
| 38 | 34409736 | CABLE SLEEVE |
| 39 | 34449954 | Cable with CEE plug |
| 40 | 34416392 | PIN SPANNER |
| 41 | 33906016 | Shim washer |
| 42 | 33900779 | Washer |
| 880 | 34413091 | GREASE TUBE 100G |
| 1001 | 33850447 | DIAGRAM |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo W750-115 - 01230001
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
