Metabo Spare Parts for Cordless Hammer KHA 36 LTX
€174.44
Tax included
Metabo Spare Parts for Cordless Hammer KHA 36 LTX
METABO Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Cordless Hammer KHA 36 LTX - 00795000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Cordless Hammer KHA 36 LTX
METABO Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Cordless HammerKHA 36 LTX - 00795000.
In the following table, look for the model of the Hammer and the respective parts of the code.
| Cordless Hammer KHA 36 LTX/00795000 | ||
| # | Part Num. | Description |
| 1 | 31400138 | Support handle compl. |
| 2 | 34151163 | Depth stop |
| 4 | 33812175 | Warning Label serial 40x14 |
| 7 | 31800158 | Gear-box compl. |
| 8 | 31800137 | KHA 36 |
| 10 | 31605183 | Brush holder assy. |
| 11 | 31606716 | Ball bearing set |
| 12 | 14311536 | Ball bearing,12X 28X 8 |
| 13 | 34100605 | Spacer sleeve |
| 14 | 14111613 | Self-tap. fill. h. screw |
| 24 | 31605404 | Wartungsset |
| 29 | 34409885 | SEAL |
| 30 | 14112164 | Fill. head screw(DIN 7985) |
| 31 | 34105952 | Striker |
| 32 | 34105962 | Exciter sleeve |
| 33 | 34407067 | Felt seal |
| 34 | 14319535 | O-ring |
| 35 | 14311579 | BALL BEARING, 15x32x9 |
| 36 | 34200279 | Pressure spring |
| 37 | 34154014 | shift bolt |
| 38 | 31604791 | Shift element compl. |
| 41 | 34339954 | Retaining ring |
| 42 | 34200349 | Pressure spring,34,7x38,3x1,8x27,7 |
| 43 | 14115559 | Supporting disc |
| 44 | 14115654 | Circlip |
| 45 | 14311469 | Needle sleeve |
| 46 | 14319534 | Shaft sealing ring |
| 48 | 31604734 | Control knob compl. |
| 49 | 34337675 | Seal |
| 50 | 31001270 | Armature compl.,36V |
| 51 | 31101176 | Field coil |
| 52 | 34308310 | Electronic switch compl. |
| 53 | 34343209 | Switch slide,R+L |
| 54 | 31501347 | Motor housing |
| 56 | 33900736 | Fixed bearing cover |
| 57 | 14112007 | Fill. head screw |
| 58 | 34343210 | Baffle |
| 59 | 14111602 | Self-tap fill h screw |
| 60 | 14112400 | Fillister head screw |
| 61 | 34121028 | Bearing bolt |
| 64 | 34343007 | Housing in the front |
| 65 | 34343008 | Housing rear |
| 66 | 34343208 | Handle |
| 67 | 34409879 | Damping ring |
| 68 | 34409892 | Bellows |
| 69 | 34409940 | Gummipuffer |
| 70 | 31604735 | Adaptor SDS -PLUS |
| 75 | 31510493 | Gear housing rear |
| 80 | 31604996 | Gear housing cpl. |
| 81 | 31605402 | Pinion shaft compl. |
| 82 | 31604994 | Drill driving sleeve compl. |
| 83 | 31605002 | Bearing ring compl. |
| 84 | 31604790 | Intermediate gear cpl. |
| 85 | 31604884 | Spring-locked connecting pin compl. |
| 90 | 33805814 | Rating plate |
| 880 | 34413080 | Grease FG 126 |
| 885 | 13601209 | Grease |
| 1001 | 33850579 | Diagram |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
