Metabo original spare parts for replacing damaged parts or fix broken and worn parts of the Angle Grinder WP 9-115 Quick - 00380000.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.![]()
| Angle Grinder WP 9-115 Quick/00380000 | ||
| # | Part Num. | Description |
| 1 | 31001092 | Armature compl., 230V |
| 2 | 31101193 | Field coil w.field coil,230 V |
| 3 | 34341025 | Switch 2-pole,X2 |
| 4 | 34410097 | Cable sleeve |
| 5 | 34449318 | Cable with plug |
| 6 | 34336249 | Cable clip |
| 7 | 31501358 | Motor housing |
| 8 | 33915119 | Baffle |
| 9 | 33915120 | Baffle |
| 11 | 14311517 | Ball bearing,6x19x6 |
| 12 | 34409787 | Rubber bushing |
| 13 | 33913306 | Washer,8,05x17x0,4 |
| 14 | 14311518 | Ball bearing,8x22x7 |
| 15 | 33900639 | Washer,7,05x19,5x0,2 |
| 16 | 34110094 | Hexagon nut w.recess |
| 17 | 31605396 | Shift lever compl. |
| 18 | 34343394 | Motor cap 2 parts black |
| 19 | 34410140 | Foam rubber self-adhesive,20 x 8 x 6,35 |
| 21 | 34103116 | Clamping flange |
| 23 | 33920449 | Wheel guard,D115 |
| 24 | 31604659 | Side support handle compl. |
| 26 | 34202204 | Spring clip |
| 30 | 33901197 | Gasket |
| 31 | 14112164 | Fill. head screw(DIN 7985) |
| 32 | 14111698 | Self-tap. fill. h. screw |
| 33 | 14111698 | Self-tap. fill. h. screw |
| 34 | 33805982 | Rating plate |
| 40 | 34160442 | Spindle M14 |
| 41 | 31605535 | Clamping nut compl.,M14 |
| 42 | 14115112 | Washer 10,2 X 14,8X 0,2 |
| 43 | 14115230 | Washer 10,2 X 14,8X 0,1 |
| 44 | 14115392 | Washer 10,2 X 14,8X 0,5 |
| 49 | 14111706 | Self-tap. fill. h. screw |
| 50 | 34343328 | Flange compl. |
| 51 | 34110246 | Nut |
| 52 | 31605497 | Bevel gear w.pinion |
| 53 | 31605508 | Friction washer set compl. |
| 54 | 31605510 | Gear housing compl. |
| 55 | 31605422 | Safety clutch w.pinion |
| 56 | 31605523 | Brush holder compl. |
| 57 | 31605485 | Fan w. dust guard |
| 58 | 31605519 | Carbon brush set cut-off |
| 59 | 31605511 | Clamping lever compl. |
| 62 | 14319365 | O-ring |
| 63 | 34200339 | Pressure spring |
| 64 | 34343313 | Push button |
| 65 | 34151564 | Bolt |
| 75 | 14319249 | O-ring |
| 92 | 14319564 | O-ring |
| 880 | 34413092 | Grease 100G |
| 885 | 34413056 | Grease SF 011 50Gr 1,8oz |
