Maruyama Parts for Brushcutter BC320
Fix Your Brushcutter Maruyama BC320(2009.01). All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Maruyama Parts for Brushcutter BC320
Fix Your Brushcutter Maruyama BC320(2009.01). All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following tables, look for the spare part and its respective code.
| Maruyama Brushcutter BC320(2009.01) Spare Parts Pag.1 |
||
| # | Part Num. | Description |
| 1-2 | 817002 | Bolt |
| 1-3 | 215512 | Clutch Case Ass'y |
| 1-4 | 214592 | Bearing Case |
| 1-5 | 214161 | Bearing |
| 1-6 | 054676 | Snap Ring |
| 1-7 | 214162 | Buffer |
| 1-8 | 214163 | Washer |
| 1-10 | 214593 | Driveshaft Tube Adapter |
| 1-12 | 054677 | Clutch Drum |
| 1-13 | 219268 | Driveshaft Ass'y |
| 1-14 | 224122 | Driveshaft Tube |
| 1-15 | 229001 | Throttle Trigger |
| 1-16 | 054691 | Hanging Bracket Ass'y |
| 1-19 | 223188 | Label |
| 1-20 | 228043 | Label |
| 1-21 | 220533 | Hanging Strap Ass'y |
| 1-22 | 222454 | Loop Handle Ass'y |
| 1-25 | 222142 | Screw |
| 1-26 | 081027 | Nut |
| 1-27 | 228302 | Safety Cover Ass'y |
| 1-28 | 227822 | Bracket |
| 1-31 | 228301 | Code Cutter Ass'y |
| 1-32 | 227823 | Code Cutter |
| 1-33 | 817002 | Bolt |
| 1-34 | 228325 | Nut |
| Pag.2 | ||
| 2-1 | 228403 | Gearcase Ass'y |
| 2-4 | 227990 | Bearing |
| 2-5 | 228416 | Gear Set |
| 2-7 | 227991 | Bearing |
| 2-8 | 055185 | Snap Ring |
| 2-9 | 227992 | Bearing |
| 2-10 | 227993 | Bearing |
| 2-11 | 228477 | Snap Ring |
| 2-12 | 140270 | Snap Ring |
| 2-14 | 212986 | Boss Adapter |
| 2-15 | 140275 | Clamping Washer |
| 2-16 | 215547 | Stabilizer |
| 2-17 | 215610 | Bolt |
| Pag.3 | ||
| 3-2 | 261360 | Cylinder |
| 3-3 | 261528 | Gasket |
| 3-4 | 261250 | Cap Screw |
| 3-5 | 261938 | Insulator |
| 3-6 | 261364 | Air Duct |
| 3-7 | 261171 | Gasket |
| 3-9 | 280619 | Muffler |
| 3-10 | 267561 | Label |
| 3-12 | 261833 | Gasket |
| 3-13 | 261607 | Cap Screw |
| 3-14 | 261257 | Cap Screw |
| 3-16 | 265304 | Top Cover Ass'y |
| 3-17 | 265305 | Top Cover |
| 3-18 | 261018 | Knob |
| 3-19 | 261020 | Spacer |
| 3-20 | 261734 | Snap Ring |
| 3-21 | 265694 | Label |
| 3-23 | 261384 | Bearing |
| 3-24 | 261385 | Oil Seal |
| 3-25 | 261386 | Oil Seal |
| 3-26 | 016732 | Snap Ring |
| 3-28 | 266980 | Piston |
| 3-29 | 261390 | Piston Ring |
| 3-30 | 261555 | Piston Pin |
| 3-31 | 261392 | Bearing,Needle |
| 3-32 | 261393 | Clip,Piston Pin |
| 3-33 | 261395 | Crankshaft/Conn.Rod Ass'y |
| 3-34 | 264503 | Clutch Ass'y |
| 3-36 | 263614 | Spring,Clutch |
| 3-37 | 261189 | Washer |
| 3-38 | 261777 | Wave Washer |
| 3-39 | 264505 | Bolt |
| 3-40 | 281325 | Fan Cover |
| 3-42 | 261356 | Rotor/Fan |
| 3-43 | 267400 | Ignition Coil Ass'y |
| 3-48 | 261075 | Connector |
| 3-49 | 261072 | Cap |
| 3-51 | 261250 | Cap Screw |
| 3-52 | 261417 | Nut,Rotor |
| 3-56 | 267492 | Lead |
| 3-57 | 261202 | Grommet |
| 3-58 | 261419 | Recoil Starter Ass'y |
| 3-59 | 261420 | Recoil Ass'y |
| 3-61 | 261725 | Starter Grip |
| 3-63 | 261721 | Spiral Spring |
| 3-66 | 263475 | Starter Pawl Ass'y |
| 3-67 | 263477 | Pawl |
| 3-68 | 261728 | Return Spring |
| 3-69 | 263476 | Pawl Case |
| 3-71 | 261076 | Woodruff Key |
| Pag.4 | ||
| 4-1 | 284085 | Carburetor Ass'y |
| 4-4 | 262995 | Gasket |
| 4-5 | 262994 | Diaphragm,Fuel Pump |
| 4-7 | 262993 | Gasket |
| 4-8 | 261873 | Diaphragm,Metering |
| 4-9 | 262991 | Purge Body |
| 4-10 | 261874 | Primer Bulb |
| 4-11 | 262992 | Cover Plate |
| 4-13 | 261876 | EXRing |
| 4-15 | 261657 | Packing |
| 4-16 | 261658 | Swivel |
| 4-17 | 261875 | Screw |
| 4-19 | 261117 | Clip |
| 4-20 | 261118 | Pad |
| 4-21 | 261119 | Pad |
| 4-22 | 261864 | Gasket |
| 4-24 | 262902 | Air Filter Ass'y |
| 4-25 | 263005 | Housing |
| 4-26 | 262998 | Cover |
| 4-27 | 263006 | Element |
| 4-32 | 268141 | Fuel Tank Ass'y |
| 4-33 | 261965 | Fuel Tank |
| 4-34 | 262726 | Fuel Tank Cap Ass'y |
| 4-35 | 261105 | Gasket |
| 4-36 | 261696 | Breather Ass'y |
| 4-37 | 265752 | Fuel Pipe PickXup Ass'y |
| 4-38 | 264031 | Fuel Pipe Ass'y |
| 4-39 | 261115 | Grommet |
| 4-42 | 264653 | Filter Ass'y |
| 4-43 | 261117 | Clip |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Maruyama websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Maruyama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
