Maktec Percussion Drill MT811 Parts
€21.70
Tax included
Maktec Percussion Drill MT811 Spare Parts
Maktec original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of Percussion Drill MT811.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Maktec Percussion Drill MT811 Spare Parts
Maktec original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of Percussion Drill MT811.
In the following table, look for the model of Drill and the respective parts of the code.
| Maktec Drill MT811 Parts | ||
| # | Part. Num. | Description |
| 1 | 763161-4 | DRILL CHUCK S13 |
| 1-1 | 763232-7 | DRILL CHUCK S13 |
| 2 | 417822-5 | GRIP BASE |
| 3-1 | 153503-4 | GRIP 36 COMPLETE |
| 4 | 265495-6 | HEX. BOLT M8X110 |
| 5 | 266326-2 | TAPPING SCREW 4X18 |
| 6 | 418393-5 | GEAR HOUSING |
| 7 | 324223-9 | SPINDLE MT811 - 327376-3 |
| 8 | 233330-6 | COMPRESSION SPRING 16 |
| 9 | 211241-5 | BALL BEARING 6202DDW |
| 9-1 | 210241-2 | BALL BEARING 6202DDW |
| 10 | 962153-2 | RETAINING RING R-35 |
| 11 | 257246-1 | RING 19 |
| 12 | 226554-1 | HELICAL GEAR 39 |
| 12-1 | 226586-8 | HELICAL GEAR 37 |
| 13 | 961052-5 | RETAINING RING (EXT) S-12 |
| 14 | 153299-7 | CAM COMPLETE |
| 15 | 216001-0 | STEEL BALL 3.5 |
| 16 | 256251-5 | PIN 4 |
| 17 | 345228-6 | CHANGE PLATE |
| 18 | 417819-4 | CHANGE LEVER |
| 19 | 417820-9 | LEVER CASE |
| 20 | 317553-5 | INNER HOUSING |
| 21 | 266326-2 | TAPPING SCREW 4X18 |
| 22 | 210029-0 | BALL BEARING 608ZZ |
| 23 | 267240-5 | FLAT WASHER 8 |
| 25 | 619088-5 | ARMATURE 230-240V |
| D10 | INC. 22,23,26,27 | INC. 22,23,26,27 |
| 26 | 681662-9 | INSULATION WASHER |
| 27 | 210030-5 | BALL BEARING 627ZZ |
| 29 | 417821-7 | BAFFLE PLATE |
| 30 | 266327-0 | TAPPING SCREW 3X40 |
| 31 | 529083-6 | FIELD ASS'Y 230-240V |
| C1 | 654228-8 | RECEPTACLE |
| 32 | 183702-4 | MOTOR HOUSING |
| D10 | 417817-8 | INC. 44 |
| 34 | INC. 44 | HANDLE COVER |
| 35 | 266326-2 | TAPPING SCREW 4X18 |
| 36 | 643562-1 | BRUSH HOLDER 5X8 |
| 36-1 | 643552-4 | BRUSH HOLDER 5-8 |
| 37 | 191998-3 | CARBON BRUSH CB-85 |
| 37-1 | 194973-8 | CARBON BRUSH SET CB-85 |
| 38 | 646148-0 | CHOKE COIL |
| 39 | 645195-8 | NOISE SUPPRESSOR |
| 40 | 646147-2 | CHOKE COIL |
| 41 | 650555-1 | SWITCH FA1-3/2BEZ-3 |
| 42 | 266326-2 | TAPPING SCREW 4X18 |
| 43 | 687124-5 | STRAIN RELIEF |
| 44 | 819126-5 | MAKTEC LOGO LABEL |
| 46 | 682569-2 | CORD GUARD 8-85 |
| 47 | 665984-5 | POWER SUPPLY CORD 1.0-2- 2.0 |
| 47-1 | 665383-1 | POWER SUPPLY CORD 1.0-2- 2.0 |
| 47-2 | 695556-2 | POWER SUPPLY CORD 1.0-2- 2.0 |
| 47-3 | 665383-1 | POWER SUPPLY CORD 1.0-2- 2.0 |
| 48 | 257245-3 | RING 12 |
| 48-1 | 257173-2 | RING 12 5604R |
| A1 | 763441-8 | CHUCK KEY S13 |
| A1-1 | 763235-1 | CHUCK KEY S13 |
| A2 | 418163-2 | KEY HOLDER 10 |
| F2 | 191998-3 | CARBON BRUSH CB-85 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase.All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Maktec MT811
