Maktec original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of Angle Grinder MT963.
In the following table, look for the model of Angle Grinder and the respective parts of the code.![]()
| Angle Grinder Maktec MT963 | ||
| 1 | 593523-0 | STATOR X MT952 |
| 2 | 266325-4 | SCREW M 4 X 70 X MT952 |
| 3 | 421808-3 | RING RUBBER 19 MT952 |
| 4 | 210062-2 | BEARING 607ZZ X MT601 |
| 5 | 267245-5 | WASHER 7 X MT952 |
| 6 | 510173-6 | ARMATURE MT962 |
| 7 | 240059-7 | FAN 50 X MT952 |
| 8 | 285704-7 | RETAINING BEARING 69 X MT952 |
| 9 | 267256-0 | WASHER 10 X MT952 |
| 10 | 210067-2 | BEARING 6000ZZ X MT952 |
| 11 | 227451-4 | GEAR 11 X MT952 |
| 12 | 961002-0 | RETAINING RING S6 |
| 13 | 417771-6 | BUTTON X 9554NB |
| 14 | 233376-2 | SPRING COMP. 8 X MT952 |
| 15 | 266324-6 | SCREW M 4 X 22 X MT601 |
| 16 | 256486-8 | PIN Disc Lock 9554NB |
| 17 | 140433-8 | GEAR HOUSING MT962 |
| 18 | 233950-6 | RING 11 X GA5010 |
| 19 | 227452-2 | GEAR 36 X MT952 |
| 20 | 962151-6 | RETAINING RING R32 |
| 21 | 211129-9 | BALL BEARING NSK 6201DD |
| 22 | 267238-2 | WASHER 12 X 9554NB |
| 23 | 325978-9 | POST MT962 |
| 24 | 318374-8 | BEARING BOX |
| 25 | 265100-5 | SCREW M4 X 16 X MT952 |
| 27 | 123099-9 | CAP BLADE |
| 28 | 224415-9 | INTERNAL FLANGE 42 GA95010 |
| 29 | 224554-5 | EXTERNAL FLANGE 14-45 X 9541 |
| 30 | 140434-6 | HOUSING MOTOR MT962 |
| 32 | 868180-6 | LABEL MT963 |
| 33 | 418397-7 | HOLDER SWITCH MT952 |
| 34 | 651424-9 | SWITCH STL106AT X MT952 |
| 35 | 451916-6 | BACK COVER MT962 |
| 36 | 652112-1 | HEX NUT X MT952 |
| 37 | 266326-2 | SCREW 4x18 X MT601 |
| 39 | 643987-9 | PLUG BRUSH 5-8 MT952 |
| 40 | 191940-4 | CARBON BRUSHES CB-411 X EX 422/421 |
| 41 | 654588-8 | X CLAMP MT952 |
| 42 | 687124-5 | Cable tie CLAMP MT953 |
| 43 | 266326-2 | SCREW 4x18 X MT601 |
| 44 | 645190-8 | CAPACITOR X MT952 |
| 45 | 682569-2 | CABLE SLEEVE MT601 |
| 47 | 418015-7 | BAFFLE MT952 |
| 48 | 418016-5 | KEY SWITCH X MT952 |
| 49 | 418017-3 | LEVER SWITCH. X MT952 |
| 50 | 233360-7 | SPRING COMP. 4 X MT952 |
| 52 | 681636-0 | INSULATION WASHER |
