Makita Spare Parts for Reciprocatng Saw JR3060T
We are MAKITA original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3060T.
In the following table, look for the model of Saw and the respective parts of the code.
| Reciprocating Saw JR3060T | ||
| # | Part Num. | Description |
| 1 | 165396-7 | SHOE X JR3050T |
| 2 | 421898-6 | COVER INSULATION X JR3060T |
| 3 | 424147-0 | PROTECTOR |
| 4 | 257952-8 | RETAINING RING 18 BJR181SF |
| 5 | 310285-3 | SOCKET HOLDER BLADE X JR3050T |
| 6 | 268094-3 | PIN 3 X BJR240 |
| 7 | 331720-8 | SOCKET GUIDE BJR181SF |
| 8 | 417791-0 | HOLDER GUIDE X BJR240 |
| 9 | 418311-3 | SOCKET X JR3050T |
| 10 | 345214-7 | PLATE X BJR240 |
| 11 | 233025-1 | SPRING 2 X 6702DW |
| 12 | 231687-9 | SPRING TWIST 17 X JR3060T |
| 13 | 257742-9 | SOCKET 14 X JR3060T |
| 14 | 213174-0 | RING 14 JR3030 |
| 15 | 911225-0 | SCREW M5X16 X JR180D |
| 16 | 418806-6 | CAP BUTTON LOCK JR3050T |
| 17 | 961012-7 | RETAINING RING E6 |
| 18 | 154551-6 | GEAR HOUSING COVER JR3060T |
| 19 | 961012-7 | RETAINING RING E6 |
| 20 | 154502-9 | HOLDER BUSHINGS X JR3060T |
| 21 | 233038-2 | SPRING COMP. 5 X JR3060T |
| 22 | 423343-7 | SEAL PLATE X JR3060T |
| 23 | 214170-1 | BEARING 14A X JR3060T |
| 24 | 168410-8 | SLIDER X JR3060T |
| 25 | 345487-2 | SLIDE PLATE JR3060T |
| 26 | 317842-8 | GEAR BOX X JR3060T |
| 27 | 154547-7 | BUSH X JR3060T |
| 28 | 345486-4 | PLATE B X JR3060T |
| 29 | 911225-0 | SCREW M5X16 X JR180D |
| 30 | 265530-0 | SCREW M5 X 8 X JR3060T |
| 32 | 911225-0 | SCREW M5X16 X JR180D |
| 33 | 317844-4 | BOX BEARING X JR3060T |
| 34 | 211131-2 | BALL BEARING 6001DD |
| 36 | 213726-7 | RING 62 X JR3060T |
| 37 | 154549-3 | LIMITING TORQUE X JR3060T |
| 38 | 266373-3 | SCREW 5x35 FOR GA9020 |
| 39 | 265165-7 | SCREW M6X16 FOR BJR181SF |
| 40 | 345479-1 | GUIDE SHOE X JR3050T |
| 41 | 232222-6 | SPRING FLAT B X JR3050T |
| 42 | 911225-0 | SCREW M5X16 X JR180D |
| 43 | 345485-6 | PLATE X JR3060T |
| 44 | 265531-8 | SCREW M 6 X 14 X JR3060T |
| 45 | 154545-1 | ECCENTRIC X JR3060T |
| 46 | 257261-5 | RING 21B X JR3060T |
| 48 | 154546-9 | ECCENTRIC BASE X JR3060T |
| 49 | 285720-9 | RETAINING BEARING B X JR3060T |
| 50 | 211251-2 | BEARING 6003LLB X DA6301 |
| 51 | 911225-0 | SCREW M5X16 X JR180D |
| 52 | 212957-5 | NEEDLE BEARING 710 JR3060T |
| 54 | 418991-5 | STOP X JR3060T |
| 55 | 231309-1 | SPRING COMPRESSION 5 |
| 56 | 272247-8 | LEVER 20 X JR3060T |
| 57 | 213021-5 | RETAINING RING 5 X LS1013 |
| 58 | 213021-5 | RETAINING RING 5 X LS1013 |
| 59 | 413095-8 | PLATE C X JR3060T |
| 60 | 421899-4 | SEAL X JR3060T |
| 61 | 268012-1 | PIN NEW JR3020 |
| 62 | 162236-0 | BUTTON LOCK X JR3050T |
| 63 | 232221-8 | SPRING FLAT A X JR3050T |
| 64 | 256158-5 | PIN 3 X T221DW |
| 65 | 233345-3 | COMPRES OF SPRING. 6 X BJR2240 |
| 66 | 256492-3 | PIN 5 X JR3060T |
| 67 | 961052-5 | RETAINING RING S12 |
| 68 | 253744-3 | FLAT WASHER 12 24B / 12N / 14 |
| 69 | 211131-2 | BALL BEARING 6001DD |
| 70 | 253744-3 | ROND.PIANA 12 24B / 12N / 14 |
| 71 | 285719-4 | RETAINING BEARING JR3060T |
| 72 | 241863-7 | FAN 70 |
| 73 | 513609-4 | ARMATURE 240V X JR3060T |
| 74 | 681644-1 | INSULATING WASHER X 9227CB |
| 75 | 210029-0 | BEARING 608Z X MT601 |
| 76 | 266466-6 | SCREW 5x45 MT430 |
| 77 | 418817-1 | BAFFLE X JR3060T |
| 78 | 625724-3 | STATOR 240V X JR3060T |
| 79 | 154498-4 | CASING MOTOR X JR3050T |
| 80 | 650222-8 | SWITCH TG71ARS-1 JR3060T |
| 81 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 82 | 183932-7 | HANDLE POST. X JR3060T |
| 84 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 85 | 687052-4 | CLAMP CABLE X 6408 |
| 86 | 682573-1 | CABLE 10 X GA9010C |
| 87 | 645200-1 | CAPACITOR |
| 88 | 645006-7 | CAPACITOR X LS1013 |
| 89 | 646049-2 | Diode X JR3000VT |
| 90 | 646144-8 | COIL X JR3060T |
| 91 | 646145-6 | COIL X JR3060T |
| 92 | 631653-0 | CONTROLLER X JR3060T |
| 96 | 421448-7 | SEAL RUBBER X JR3020 |
| 98 | 191963-2 | CARBON BRUSHE SET CB-303 |
| 99 | 643750-0 | BRUSH HOLDER CAP |
| 100 | 125524-6 | GEAR HOUSING COVER ASSY JR3060 / 3070 |
