Makita Spare Parts for Concrete Planer PC5000C

€22.33
Tax included

Makita Spare Parts for Concrete Planer PC5000C

We have the Makita original Spares for Concrete Planer PC5000C, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Concrete Planer PC5000C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 140019-8
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Concrete Planer PC5000C

Fix Your Concrete Planer PC5000C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of Concrete Planer and the respective parts of the code.
Makita PC5000C

Concrete Planer Makita PC5000C
# Part Num. Description
1 266459-3 SCREW 5x25 PC5000C
2 417771-6 BUTTON X 9554NB
3 234057-1 SPRING 6 GA5021C
4 318158-4 GEAR BOX GA 5010
5 424051-3 RING RUBBER 26 GA5021C
6 264010-3 NUT M7 X GA5010
7 227520-1 GEAR 11 PER 9020
8 210059-1 BEARING 6000 HR2010
9 267352-4 WASHER 22 GA5010
10 962107-9 RETAINING RING R-30 X GA5010
11 240094-5 FAN 70 GA5010
12 513799-3 ARMATURE PC5000C
13 681660-3 INSULATING WASHER X PV7000C
14 267281-1 WASHER 8 X GA9010C
15 210044-4 BEARING 608DDW
16 421720-7 RING RUBBER 5604R
17 266325-4 SCREW M 4 X 70 X MT952
18 419961-7 BAFFLE GA5010
19 525784-4 STATOR GA5021C
20 140019-8 HOUSING MOTOR PC5000C
21 194547-5 CARBON BRUSHES CB-253 X GA5021C
22 643750-0 PLUG BRUSH HOLDER
23 866345-4 LABEL PC5000C
24 188630-8 HANDLE REAR PC5000C
25 266326-2 SCREW 4x18 X MT601
26 631799-2 REGULATOR X GA5021C
27 418518-1 SOCKET X GA9010C
28 651922-3 SWITCH TG71B
29 654575-7 CLAMP X 5704R
30 266326-2 SCREW 4x18 X MT601
31 687124-5 Cable tie CLAMP MT953
32 682574-9 CABLE SLEEVE 10-90 PC5000C
34 233117-6 SPRING COMP. 6 X GA7010C
35 418519-9 SWITCH BASE X X GA9010C
36 158401-7 LEVER SWITCH GA5021C
38 450184-8 LENS FOR PC5000C
39 213977-2 RING 7 X GA5010
40 256505-0 PIN 5 GA5010
41 263002-9 PIN RUBBER 4
42 210033-9 BEARING 696ZZ X 2107FK
43 233950-6 RING 11 X GA5010
44 227521-9 35A GEAR PC5000C
45 257171-6 RING 12 X PC5000C
46 911003-8 SCREW M3X6 X 6096DW
47 285728-3 RETAINING BEARING 39 GA5010
48 211241-5 BEARING 6202DDW X MT601
49 253853-8 WASHER 15 X HR1800
50 213624-5 RING 48 X GA5010
51 345464-4 RING DUST X 9554NB
52 325625-2 POST PC5000C
53 141021-4 CONVOGLIATORE PC5000C
54 911256-9 SCREW M5x35
55 911024-0 SCREW M3 X 14 X PC5000C
56 240114-5 FAN 85 PC5000C0
57 346045-7 SEPARATOR PC5000C
58 911115-7 SCREW M4X10 X HR4000C
59 922312-0 BOLT M6 X 12
60 424526-2 COVER ANTIPOL.ANT.PC5000C
61 424525-4 DUST COVER PC5000C
62 743341-8 BRUSH B PC5000C
63 743340-0 BRUSH A PC5000C
64 224554-5 EXTERNAL FLANGE 14-45 X 9541
65 416256-9 GRIP X PC5000C
66 922453-2 SCREW M8x30 PC5000C
67 450189-8 SPACER PC5000C
68 450190-3 DISTANCE B PC5000C
