Compa-OMS Spare Parts for Professional Mitre Saw 300 JE
COMPA-OMS authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Professional Portable Mitre Saw 300 JE.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Professional Mitre Saw 300 JE
COMPA-OMS authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Professional Portable Mitre Saw 300 JE.In the following table, look for the model of the Cutter-Bending and their spare part.
| Professional Portable Mitre Saw 300 JE | |
| Part Num. | Description |
| 2005002 | Fork brings pressure VICE |
| 0509 | Handle Snap (KP I.40 M6x30) |
| 0521 | Holder press. vice WITH PRIGION. |
| 0508 | |
| 0510 | Press.morsa L.180 (ZS020 00001) |
| 0534 | |
| 0522 | Pressor universal vise |
| 20050011Lavorato | Support vise x 2300/250 FCT WORKED |
| 0520 | |
| 0526 | |
| 0536 | |
| 0535 | |
| 0523 | |
| 0537 | |
| 0806 | Clamp HOP9 d.40-70 |
| 0851 | Support for lots aspiration |
| 0805 | Sacco asp.C216 / G d.60 int + Hinge |
| 23020180 | Guy M5x180 Zn |
| 0912 | Fan Cover, Small Motor, Polycarbonate 250/300/2300 |
| 0913 | Fan motor small 250/300/2300 |
| 0911Lavorato | Motor cover 250 WORKED |
| 0207 | Bearing 6201 2Z (CTK) (HCH) mm.12x32x10 |
| 23020610 | Plast protection. motor 90x120 |
| 0284 | Spring 'CO.MEC 720 P.32'x brake |
| 0283 | brake pad |
| 0280 | Spacer release lever arm |
| 0277 | Return spring release lever |
| 0393 | Tested release lever |
| 0275-01 | Control Release lever |
| 0262 | handle |
| 23020450 | Spacer for mounting Switch |
| 0216 Mono | Cable VVF 3x1 + mt.2 sp.SHUKO FR |
| KIT23020140/5 | Crankshaft '90' + x rotor mod.2300 |
| 0276 | Latch / hook release arm |
| 23020430 | Nameplate danger heat |
| 0208 Quality | Bearing 6203 ZZ mm.17x40x12 |
| 0292 | Cond. 20mF V.450 2 cav.mm.250 |
| 0214 | rubber grommet |
| 0240 | Plastic Disc Cover x E/JE/BIG |
| KITMOT2300MON | Engine 2300 mono (Paccco St. + Lawyer. + Car |
| 0252 | Cable T.g. / v.1x1 cm.21 anel.d.3 |
| 0212Lavorato | Arm 300-90 / 120 WORKED |
| 0163 | Knob d.20 M6x10 (01TBP20C10) |
| 0215PULSANTE | Button 82L5 2 MORS.VERDE + PR. |
| 23010560 Lav | Bracket Left x mod.250 / 300 E / ET |
| 23010120 | Rubber foot univ.x 2300 / 1-3000 / 1-3500 |
| 0112 | Plate for batting arrest hole d.10 |
| 0148 | Auctions only arrest curved |
| 1201LAVKESKO | Lavor base. x 250/300 SIT KESKO |
| KIT016001 | Cranck bush W/Llever Ass'y |
| 0109 | Spring for eccentric bush |
| 0187 | |
| 0144-1 | |
| 0396 | |
| 0397 | |
| 0133-001 | Roller bearing d.4x22 |
| 0108-12 | |
| 0119 | Knob d.20 M6x60 (01THP20C60) |
| 0153 | Locking lever intermediate GALVANIZED |
| 0132/01 | Plate 13,5x5 stops bracket |
| 0124-8 | Millimeter DX SX mm.260x8 sp.0.5 |
| 0659 | |
| 0134 | Adhesive headset / eye / PVC gloves unified |
| 1204 | Washer Drawn x bas.to 'S' |
| 0414 | Cap x turntable x 300 |
| 23010540 Lav | Right-angle x mod.300JET ET-2300 |
| 0151 | Conveyor protection Saw |
| 0122 | |
| 0288 | Washer vent. UNI8842 screw M14 x |
| 0226 Lavorato | Washer stops saw GROUND |
| 0279 | Washer spring preload GALVANIZED |
| 0244 | Shim washer torsion spring |
| 0291 | Spring f.5,5 d.e.50,5 x arm |
| 0293 | D.30 conical knob M10x60 |
| 0278 | Pin hinged arm NEW |
| 0224LAVORATO | Spacer ring saw ADJUSTED |
| 0226LAVORATO | Washer stops saw GROUND |
| 0227 | Ring reduction saw d.17x30x3 |
| 0228 | Allen stops saw HEX SOCKET HEAD M10x25 SX Zn |
| 0118 | Washer Brass d.24x10,5x2 |
| 0222 | thrust 51100 |
| 0274 | Eccentric pin rod casing 300 |
| 0282 | Balestra release rod casing |
| 0273 | Guide rod casing NEW |
| 0286 | Disc Guard 300 NEW |
| 20020120 | Crankcase Washer Shim Sp.0.6 |
| 0285 | Guide ring crankcase NEW |
| 0115 | Wing nut (tumbler serr.CSP M6x25) |
| 0139 | Couple port terminals auctions arrest |
| 0113 | Rod diameter perforated mm.10x255 GALVANIZED |
| 0401/0402 MON | Rotating table + support arm mounted tilted x 300 |
| 0116 | Washer Teflon d.85xd.41x0,3 |
| 23010580 | |
| 23010570 | |
| 0163 | Knob d.20 M6x10 (01TBP20C10) |
| 0101LAVORATO | Base 'E' vernic. + Worked |
