Makita Spare Parts for Cordless Rivet Gun DRV150

€25.82
Tax included

Makita Spare Parts for Cordless Rivet Gun DRV150

Makita genuine spare parts or replacements parts for to fix 18V LXT® Lithium‑Ion Brushless Cordless Rivet Gun DRV150.
ITEM CODE: 319812-3
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Cordless Rivet Gun DRV150

Makita genuine spare parts or replacements parts for to fix 18V LXT® Lithium‑Ion Brushless Cordless Rivet Gun DRV150.

In the following table, look for the model of Dry Wall Screwdrivers and the respective parts of the code.
Brushless Cordless Rivet Gun DRV150
MAKITA DRV150 CORDLESS RIVET GUN Spare parts
# Part Num. Description
1 319812-3 SCREW NUT 4.8
2 213380-7 O RING 24
3 127225-2 NOSEPIECE 4.8A ASSEMBLY
3 D10 INC. 4,5
4 213011-8 O RING 7
5 256217-5 PIN 4
6 327281-4 JAW CASE
006-1 327279-1 HEAD 6.4
7 327279-1 HEAD 6.4
007-1 327281-4 JAW CASE
8 199731-7 JAW 4.8 SET (3/16")
9 127475-9 JAW PUSHER 3.6 ASSEMBLY
9 D10 INC. 49
10 232586-8 COMPRESSION SPRING 7
11 213265-7 O RING 17
12 327285-6 JOINT 4.8
13 140J44-9 FRONT HOUSING COMPLETE
14 127221-0 BALL SCREW
15 620A44-6 HALL IC CIRCUIT
16 257457-8 RING 5
17 310935-0 ROLLER SHAFT 4.8
18 140E40-7 MAGNET HOLDER COMPLETE
018-1 140T04-1 MAGNET HOLDER COMPLETE
19 911008-8 PAN HEAD SCREW M3X8
20 327284-8 TUBE 4.8
21 458772-5 TUBE GUIDE A
22 261161-3 FELT RING 8
23 458773-3 TUBE GUIDE B
24 233025-1 COMPRESSION SPRING 2
25 458774-1 SWITCH LEVER
26 632M90-9 SWITCH UNIT
27 162500-9 MANDREL CONTAINER COMPLETE
28 140J46-5 SPUR GEAR 10 COMPLETE
29 127222-8 GEAR ASSEMBLY
30 266490-9 TAPPING SCREW PT 2X6
31 632M67-4 CONTROLLER UNIT
32 629373-8 STATOR
33 619535-6 ROTOR
34 652069-6 FLAT HEAD SCREW M3X6
36 651379-8 SWITCH C3JW-1A-S
37 643874-2 TERMINAL
38 855M09-3 DRV150 SERIAL NO. LABEL
39 183L30-9 HOUSING SET
39 263005-3 RUBBER PIN 6
39 252126-6 HEX. LOCK NUT M4-7
39 931002-4 HEX. NUT M3
39 D10 INC. 46
40 265095-2 PAN HEAD SCREW M3X20
41 140J45-7 REAR HOUSING COMPLETE
42 265490-6 HEX. SOCKET HEAD BOLT M4X16
43 310908-3 GUIDE PLATE L
043-1 313297-5 GUIDE PLATE L
44 310909-1 GUIDE PLATE R
044-1 313298-3 GUIDE PLATE R
45 620549-0 LED CIRCUIT
46 183L30-9 HOUSING SET
46 263005-3 RUBBER PIN 6
46 252126-6 HEX. LOCK NUT M4-7
46 931002-4 HEX. NUT M3
46 D10 INC. 39
47 855M01-9 DRV150 NAME PLATE
48 213891-2 O RING 14.5
49 213054-0 O RING 9
A01 251314-2 + SCREW M4X12
A02 346317-0 HOOK
A03 191C04-2 ACCESSORY SET B FOR 4.0
A03 213011-8 O RING 7
A03 256217-5 PIN 4
A03 213054-0 O RING 9
A04 199728-6 ACCESSORY SET FOR 3.2
A04 213011-8 O RING 7
A04 256217-5 PIN 4
A04 213054-0 O RING 9
A05 199729-4 ACCESSORY SET FOR 2.4
A05 213011-8 O RING 7
A05 256217-5 PIN 4
A05 213054-0 O RING 9
A06 191D57-7 GREASE SET
A07B ***DC18RC DC18RC FAST CHARGER
A07B D10 COMPO-PARTS
A08B 197600-6 BATTERY BL1830B SET
A09B 450128-8 BATTERY COVER
A10B 821755-2 PLASTIC CASE
A10B 162315-4 LATCH
A11B 140977-8 HOUSING CPL DC18RC
A12B 191A24-4 BATTERY BL1830Bx1(18V3A)+DC18RC IN CARTONE
A13B 195584-2 CHARGER DC18RC RAPID LXT
A14B 197624-2 KITENERGY18VBL1840 4Ax2+DC18RC
A15B 197624-2 KITENERGY18VBL1850B5Ax2+DC18RC
A16B 198116-4 KITENERGY18VBL1860B6Ax2+DC18RC
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
