Makita Spare Parts for Rotary Hammer HR5210C
€3.28
Tax included
Makita Spare Parts for Rotary Hammer HR5210C
We supply MAKITA original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer, SDS-MAX HR5210C.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR5210C
We supply MAKITA original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer, SDS-MAX HR5210C.
In the following table, look for the model of jackhammers and the respective parts of the code.
| HR5210C ROTARY HAMMER 52MM SDS-MAX | ||
| # | Part Num. | Description |
| 1 | 286285-4 | TOOL HOLDER CAP, HR4001C / 4010C |
| 2 | 233948-3 | RING SPRING 25, HR5210C HR5201C |
| 3 | 257280-1 | RING 28 X HR5201C |
| 4 | 419002-9 | SPACER X HR4001C / HR4010C |
| 5 | 233948-3 | RING SPRING 25, HR5210C HR5201C |
| 6 | 324752-2 | CHUCK RING, HR5210C HR5201C |
| 7 | 419778-8 | CHACK COVER, HR5210C HR5201C P03 |
| 8 | 419779-6 | RELEASE COVER, HR5210C HR5201C |
| 9 | 310178-4 | TOOL RETAINER, HR5210C HR5201C |
| 10 | 345804-6 | SPRING GUIDE, HR5210C HR5201C |
| 11 | 233496-2 | COMPRESSION SPRING 49, HR5210C HR5201C |
| 12 | 213766-5 | O-RING 78, HR5210C HR5201C |
| 13 | 158175-0 | BARREL CPL., HR5210C HR5201C |
| 14 | 158179-2 | BARREL COVER CPL., HR5210C HR5201C |
| 15 | 922456-6 | H.S.H. BOLT M8X35, 2107F |
| 16 | 213492-6 | O-RING 32, HR5210C HR5201C |
| 17 | 324740-9 | TOOL HOLDER A, HR5210C HR5201C |
| 18 | 345804-6 | SPRING GUIDE, HR5210C HR5201C |
| 19 | 419791-6 | GEAR HOUSING COVER, HR5210C HR5201C |
| 20 | 922148-7 | H.S.H. BOLT M4X25, 6922NB HR5201C |
| 21 | 213274-6 | O RING 18, HR3000C |
| 22 | 213392-0 | FLUORIDE RING 25, HR4000C |
| 23 | 213317-4 | O RING 20, HR4000C |
| 24 | 324753-0 | IMPACT BOLT, HR5210C HR5201C |
| 25 | 324756-4 | RING 20 X HR5201C |
| 26 | 424000-0 | RUBBER RING 24 X HR5201C |
| 27 | 324757-2 | COLLAR SLEEVE 20, HR5210C HR5201C |
| 28 | 233949-1 | RING SPRING 44, HR5210C HR5201C |
| 29 | 257282-7 | RING 47 X HR5201C |
| 30 | 267287-9 | FLAT WASHER 57, HR5210C HR5201C |
| 31 | 262122-6 | URETHAN RING 57 X HR5201C |
| 32 | 267287-9 | FLAT WASHER 57, HR5210C HR5201C |
| 33 | 256265-4 | PIN 10, HR5001C HR5001C |
| 34 | 324741-7 | TOOL HOLDER B, HR5210C HR5201C |
| 35 | 419776-2 | LOCK SLEEVE, HR5210C HR5201C |
| 36 | 213654-6 | O RING 60, HR3851 HR3850B / HM0810 |
| 37 | 165459-9 | RINK ARM, HR5210C HR5201C |
| 38 | 419775-4 | LINK ARM GUIDE, HR5210C HR5201C |
| 39 | 424024-6 | SEAL PLATE, HR5210C |
| 40 | 313138-5 | DRIVING SLEEVE, HR5210C HR5201C |
| 41 | 419780-1 | SLIDE SLEEVE, HR5210C HR5201C |
| 42 | 451516-2 | CONNECTING ROD HR5201C |
| 43 | 213460-9 | O RING 35, HM1500 HK / HR1800 / HM12 |
| 44 | 419771-2 | PISTON X HR5201C |
| 45 | 268121-6 | PIN 12 X HR5201C |
| 46 | 213296-6 | O-RING 34 HR5201C |
| 47 | 213510-0 | O-RING 36 HR2010 |
| 48 | 331748-6 | CYLINDER 40 X HR5201C |
| 49 | 213296-6 | O-RING 34 HR5201C |
| 50 | 324754-8 | STRIKER X HR5201C |
| 51 | 227511-2 | STRAIGHT BEVEL GEAR 33, HR5210C HR5201C |
| 52 | 233498-8 | COMPRESSION SPRING 46 X HR5201C |
| 53 | 257281-9 | RING 45 X HR5201C |
| 54 | 213118-0 | O-RING 12 X HR5210C |
| 55 | 318124-1 | PIPE HOLDER, HR5210C |
| 56 | 213118-0 | O-RING 12 X HR5210C |
| 57 | 419773-8 | SPRING GUIDE HR5210C |
| 58 | 233497-0 | COMPRESSION SPRING 15 HR5210C |
| 59 | 213953-6 | O-RING 24 HR2430 |
| 60 | 331745-2 | PIPE 22 X HR5210C |
| 61 | 213953-6 | O-RING 24 HR2430 |
| 62 | 324755-6 | COUNTER WEIGHT, HR5210C |
| 63 | 233497-0 | COMPRESSION SPRING 15 HR5210C |
| 64 | 419773-8 | SPRING GUIDE HR5210C |
| 65 | 213118-0 | O-RING 12 X HR5210C |
| 66 | 318124-1 | PIPE HOLDER HR5210CP15 |
| 67 | 213118-0 | O-RING 12 X HR5210C |
| 68 | 922361-7 | H.S.H. BOLT M6X40, HM1303B HM1303 |
| 69 | 266192-7 | TAPPING SCREW 4X14, 2012NB HR4001C / HR4010C |
| 70 | 419020-7 | CHANGE LEVER, HR4001C / HR4010C |
| 71 | 233436-0 | COMPRESSION SPRING 3 X HR4001C / HR4010C |
| 72 | 419777-0 | LOCK BUTTON, HR5210C HR5201C |
| 73 | 450687-2 | CRANK LEVER, HR5210C HR5201C |
| 74 | 213534-6 | O-RING 36 X HR5201C |
| 75 | 233506-5 | TORSION SPRING 16 X HR5201C |
| 76 | 310207-3 | LINK LEVER, HR5210C HR5201C |
| 77 | 345778-1 | RETAINER PLATE HR5201C |
| 78 | 265014-8 | P.H. SCREW M4X12, AF501 |
| 79 | 318130-6 | CRANK CAP COVER, HR5210C HR5201C |
| 80 | 266192-7 | TAPPING SCREW 4X14, 2012NB HR4001C / HR4010C |
| 81 | 911133-5 | P.H. SCREW M4X18, N9501B |
| 82 | 419789-3 | CRANK CAP, HR5210C HR5201C |
| 83 | 421998-2 | SEAL RING X HR5201C |
| 84 | 345779-9 | LINK PLATE, HR5210C HR5201C |
| 85 | 419781-9 | LINK PLATE GUIDE, HR5210C HR5201C |
| 86 | 158176-8 | CRANK HOUSING CPL., HR5210C HR5210C |
| 87 | 419008-7 | FIX GUIDE, HR4001C |
| 88 | 423366-5 | CUSHION PLATE, HR5210C HR5201C |
| 89 | 324739-4 | CRANK SHAFT, HR5210C HR5201C |
| 90 | 211418-2 | BALL BEARING 6006LLU X HR4500C |
| 91 | 254229-2 | KEY 5 X HR4000C |
| 92 | 226646-6 | HELICAL GEAR 47, HR5210C HR5201C |
| 93 | 227176-0 | SPUR GEAR 24, HR5210C HR5201C |
| 94 | 961102-6 | RETAINING RING S22 |
| 95 | 253843-1 | FLAT WASHER X LC1230 |
| 96 | 421999-0 | SEAL RING X HR5201C |
| 97 | 158178-4 | GEAR HOUSING CPL X HR5201C |
| 98 | 922341-3 | H.S.H. BOLT M6X25, HM1100C |
| 99 | 125374-9 | TORQUE LIMITER ASS'Y, HR5210C HR5201C |
| 100 | 419796-6 | HANDLE COVER X HR5201C |
| 101 | 265995-6 | * TAPPING SCREW M4X18 X 6408 / 6221DW |
| 102 | 650676-9 | SWITCH TG73B-1 HR4001C |
| 103 | 154626-1 | SWITCH HOLDER HR4001C P04 |
| 104 | 419028-1 | SWITCH LEVER X HR4001C / HR4010C |
| 107 | 266041-8 | TAPPING SCREW, FLANGE 5X25, 5177B |
| 108 | 419800-1 | HANDLE X HR5210C |
| 111 | 863365-9 | NAME LABEL X HR5210C |
| 117 | 419793-2 | CRANK HOUSING COVER, HR5210C HR5210C |
| 118 | 631727-7 | CONTROLLER, HR5210C HR5201C |
| 119 | 266192-7 | TAPPING SCREW 4 X 14 X HR4001C / HR4010C |
| 120 | 638510-3 | LEAD UNIT, HR5210C HR5201C |
| 121 | 687169-3 | STRAIN RELIEF, HP1621F HP1620 |
| 122 | 266192-7 | TAPPING SCREW 4 X 14 X HR4001C / HR4010C |
| 123 | 419024-9 | CORD LAMP BASE, HR4001C HR4001C |
| 124 | 265995-6 | * TAPPING SCREW M4X18 X 6408 / 6221DW |
| 125 | 266192-7 | TAPPING SCREW 4 X 14 X HR4001C / HR4010C |
| 126 | 419774-6 | LENS HR5201C |
| 127 | 682560-0 | CORD GUARD HM1202C / 9079S P03 |
| 129 | 266041-8 | TAPPING SCREW PT 5X25 |
| 130 | 419790-8 | REAR COVER X HR5201C |
| 131 | 252178-7 | HEX NUT M 8-12 X 4112HS |
| 132 | 253165-9 | FLAT WASHER 8 |
| 133 | 240016-5 | FAN HR5001C |
| 134 | 419782-7 | FAN GIUDE HR5201C |
| 135 | 195844-2 | CARBON BRUSH SET CB-175 EX CB-171 |
| 136 | 638447-4/HR | BRUSH HOLDER UNIT, HR5210C HR5201C |
| 137 | 419795-8 | MOTOR HOUSING, HR5210C HR5201C |
| 138 | 636303-2 | FIELD HR5201C |
| 139 | 266095-5 | TAPPING SCREW 5 X 55 HR5001C |
| 140 | 210059-1 | BALL BEARING 6000 HR2010 |
| 141 | 681642-5 | INSULATION WASHER LS1013 |
| 142 | 516993-6 | ARMATURE ASS'Y HR5201C |
| 143 | 267025-9 | FLAT WASHER 15 6912D |
| 144 | 211238-4 | BALL BEARING 6202LLU |
| 145 | 331596-3 | SLEEVE 12 X HR4500C |
| 146 | 213231-4 | OIL SEAL X HR4500C |
| 147 | 419788-5 | BAFFLE PLATE, HR5210C HR5201C |
| 148 | 266192-7 | TAPPING SCREW 4 X 14 X HR4001C / HR4010C |
| 149 | 419786-9 | SWITCH BOX X HR5201C |
| 150 | 263027-3 | RUBBER PIN 4 X HM0860C |
| 151 | 651418-4 | SWITCH ST115A-40 X 9541 |
| 152 | 232209-8 | LEAF SPRING X HM0860C |
| 153 | 154635-0 | SLIDE LEVER CPL., HR4001C / HR4010C |
| 154 | 419785-1 | CONTROL PLATE, HR5210C HR5201C |
| 999 | 195191-1 | HAMMER SERVICE KIT, HR5210C |
| 1001 | 181573-3 | BIT GREASE HR2400 |
| 1002 | 135269-8 | SIDE HANDLE 82 ASS'Y, HM1203C |
| 1003 | 265726-3 | SCREW M6X14, 5177B |
| 1004 | 266163-4 | C.S.N.BOLT M8X80, HR4041C |
| 1005 | 344492-6 | PLATE, HR4002 |
| 1006 | 345780-4 | GRIP SPRING 82, HR5210C |
| 1006 | 419792-4 | SIDE GRIP BASE 82, HR5210C |
| 1007 | 931302-2 | HEX NUT M6, HR2400 |
| 1008 | 135380-6 | GRIP ASS'Y, HR5210C |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
