Makita Spare Parts for Reciprocatng Saw JR3020
€4.26
Tax included
Makita Spare Parts for Reciprocatng Saw JR3020
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3020.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Reciprocatng Saw JR3020
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3020.
In the following table, look for the model of Saw and the respective parts of the code.
| Makita JR3020 Reciprocating Replacement Tool Parts | ||
| # | Part Num. | Description |
| 1 | 256654-3 | PIN 4 |
| 2 | 266242-8 | H.S.H. BOLT M5X45, JR3020 |
| 3 | 942101-7 | SPRING WASHER 5 |
| 4 | 344095-6 | SHOE PLATE, JR3020 |
| 5 | 961017-7 | STOP RING E-3, 4304, SH01 - 4305T |
| 6 | 252103-8 | HEX. LOCK NUT M5-8, 5007FK - JR3020 |
| 7 | 344096-4 | SHOE SUPPORTER, JR3020 |
| 9 | 232165-2 | LEAF SPRING. JR3020 |
| 10 | 313075-3 | BLADE CLAMP X JR3020 |
| 11 | 266090-5 | H.S.H.SCREW M5X15, JR3000V-T2 |
| 12 | 421451-8 | INSULATION COVER, JR3020 |
| 13 | 159614-3 | GEAR HOUSING COVER, JR3020 |
| 14 | 961012-7 | STOP RING E6 |
| 15 | 961012-7 | STOP RING E6 |
| 16 | 213171-6 | DUST SEAL 12.7, JR3020 |
| 17 | 316765-7 | SLIDER SUPPORT, JR3020 |
| 18 | 231342-3 | COMPRESSION SPRING 4 X JR3020 |
| 19 | 214167-0 | PLANE BEARING 12.7, JR3000V,T2 |
| 20 | 168281-3 | SLIDER NEW TYPE JR3020 |
| 21 | 214167-0 | PLANE BEARING 12.7, JR3020,T2 |
| 22 | 266086-6 | H.S.H.BOLT M5X16,DA4031 JR3020 |
| 23 | 343980-0 | PLATE B X JR3020 |
| 24 | 343983-4 | ARM X JR3020 |
| 25 | 265011-4 | BINDING HEAD SCREW M5, JR3020 |
| 26 | 343981-8 | PLATE C X JR3020 |
| 27 | 251969-3 | C.H. BOLT M5X12, JR3020 |
| 28 | 266086-6 | H.S.H.BOLT M5X16,DA4031 JR3020 |
| 29 | 341462-6 | PLATE X JR3000 / V |
| 30 | 212308-2 | T.N. BEARING 2035, 6920B |
| 31 | 153218-3 | GEAR CPL X JR3020 |
| 32 | 211519-6 | BALL BEARING 6808 X JR3020 |
| 34 | 251969-3 | C.H. BOLT M5X12, JR3020 |
| 35 | 268012-1 | PIN 7 JR3020 |
| 36 | 272228-2 | LEVER 20 JR3020 |
| 37 | 231249-3 | COMPRESSION SPRING 5 8419B2 / HP2010 / N |
| 38 | 415173-0 | STOPPER JR3020 |
| 39 | 257106-7 | RING 8 X DA390DW |
| 40 | 343982-6 | LEVER PLATE JR3020 |
| 41 | 921432-7 | HEX BOLT M8X20, 5177B |
| 42 | 272235-5 | LEVER 50 JR3020 |
| 43 | 922201-9 | H.S. BOLT M5X8, 4110C |
| 44 | 212038-5 | NEEDLE BEARING 710, JR3020 |
| 46 | 212115-3 | N. BEARING 1216, JR3000V |
| 47 | 321263-8 | GEAR SHAFT, JR3000V |
| 48 | 316464-1 | GEAR HOUSING, JR3020 |
| 49 | 922241-7 | P.H. SCREW M5X25, GA7911 |
| 50 | 911223-4 | PAN HEAD SCREW M5X16, JR3020 |
| 51 | 911211-1 | SCREW M5X12 |
| 52 | 961052-5 | RETAINING RING S12 |
| 53 | 211131-2 | BALL BEARING 6001DD |
| 54 | 285675-8 | BEARING RETAINER, JR3020 |
| 55 | 241863-7 | FAN 70 |
| 56 | 516168-7 | ARMATURE ASS'Y 220V. X JR3020 |
| 57 | 681625-5 | INSULATING WASHER HK1810 |
| 58 | 210005-4 | BALL BEARING 608 DDW |
| 59 | 415174-8 | SPEED CONTROL KNOB X JR3020 |
| 60 | 182578-6 | HANDLE SET JR 3020 |
| 61 | 159546-4 | MOTOR HOUSING |
| 62 | 194547-5 | CARBON BRUSH CB-253, JR3020 251/250 |
| 63 | 643750-0 | BRUSH HOLDER CAP |
| 65 | 632461-2 | SUPPORT COMPLETE JR3020 |
| 66 | 634168-6 | FIELD ASS'Y, JR3020 |
| 68 | 415157-8 | BAFFLE PLATE, JR3020 |
| 69 | 911251-9 | P.H. SCREW M5X30, 2030S |
| 70 | 421447-9 | RUBBER BLOCK (B), JR3020 |
| 71 | 263002-9 | RUBBER PIN 4 |
| 72 | 256221-4 | PIN 3 X JR3020 |
| 73 | 233024-3 | COMPRESSION SPRING 4, 6702DW |
| 74 | 415160-9 | LOCK BUTTON X JR3020 |
| 75 | 651921-5 | SWITCH SGE110CV X JR3020 |
| 76 | 256221-4 | PIN 3 X JR3020 |
| 77 | 415158-6 | SWITCH LEVER X JR3020 |
| 78 | 421446-1 | RUBBER BLOCK (A), JR3020 |
| 80 | 911156-3 | P.H. SCREW M4X30, 9045B |
| 81 | 631149-1 | TRIAC COMPL. X JR3020 |
| 82 | 415156-0 | CONTROLLER CASE JR3020 |
| 83 | 421448-7 | RUBBER BAND X JR3020 |
| 84 | 645209-3 | CAPACITOR |
| 85 | 421452-6 | RUBBER PLATE X JR3020 |
| 86 | 265995-6 | TAPPING SCREW 4X18, BO4556K |
| 87 | 687124-5 | STRAIN RELIEF, 4323K |
| 88 | 682505-8 | CORD GUARD 10/90, 9005B |
