Makita Spare Parts for Jig Saw 4301BV
€22.27
Tax included
Makita Spare Parts for Jig Saw 4301BV
Makita original spare parts for to replace broken parts or to fix 65mm Jigsaw 4301BV.Fix Your Jigsaw 4301BV. All Spares are Available at Discounted Prices. Our spares are original parts and come with a full warranty.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Jig Saw 4301BV
Fix Your Jigsaw 4301BV. All Spares are Available at Discounted Prices. Our spares are original parts and come with a full warranty.Open PDF Diagram, check your spare part number position and then select it in the following table.
| Jig Saw 4301BV | ||
| # | Part Num. | Description |
| 1 | 911136-9 | P.H. SCREW M4*20 WITH W, M931 |
| 4 | 157219-3 | GEAR HOUSING COVER |
| 5 | 231314-8 | COMPRESSION SPRING 4 |
| 6 | 342688-3 | SLIDE PLATE |
| 8 | 331237-1 | SLIDER |
| 9 | 251387-5 | COUNTERSUNK HEAD SCREW M4 X12 |
| 10 | 342685-9 | SLIDER PLATE |
| 11 | 212010-7 | NEEDLE BEARING 607 |
| 12 | 961004-6 | RETAINING RING S-8 |
| 13 | 911223-4 | PAN HEAD SCREW M5*16, JR3070T |
| 14 | 152243-1 | CRANK COMPLETE |
| 15 | 253122-7 | FLAT WASHER 26 |
| 19 | 253880-5 | FLAT WASHER 35 |
| 20 | 342684-1 | PUSH PLATE |
| 21 | 253879-0 | FLAT WASHER 35 |
| 23 | 212043-2 | NEEDLE BEARING HK 0810, 9523NB |
| 24 | 212043-2 | NEEDLE BEARING HK 0810, 9523NB |
| 25 | 253192-6 | FLAT WASHER 14, 4100NH |
| 26 | 211033-2 | BALL BEARING 608LB, 4100NH |
| 27 | 681613-2 | INSULATION WASHER |
| 28 | 253758-2 | FLAT WASHER 10 |
| 29 | 512808-5 | ARMATURE ASS Y 220V |
| 30 | 241518-4 | FAN 68 |
| 31 | 253878-2 | FLAT WASHER 10 |
| 32 | 211033-2 | BALL BEARING 608LB, 4100NH |
| 33 | 410199-7 | BAFFLE PLATE |
| 34 | 252014-7 | HEX LOCK NUT M6*10, N5900B |
| 35 | 157220-8 | GEAR HOUSING |
| 36 | 253077-6 | FLAT WASHER 6 |
| 37 | 961011-9 | STOP RING, HR2450 |
| 39 | 321647-0 | GEAR SHAFT |
| 43 | 911116-5 | PAN HEAD SCREW M4*12, 9035 |
| 44 | 911106-8 | PAN HEAD SCREW M4X8, 5007NB |
| 45 | 342686-7 | HOLDER |
| 46 | 911113-1 | PAN HEAD SCREW M4*10 WR, LS1040 |
| 47 | 410215-5 | PROTECTOR |
| 48 | 961017-7 | STOP RING E-3, 4304Z |
| 49 | 961017-7 | STOP RING E-3, 4304Z |
| 50 | 151364-6 | RETAINER COMPLETE |
| 51 | 256639-9 | PIN 4 X 4301BV |
| 52 | 268074-9 | PIN 4 FOR 4304 |
| 54 | 164861-3 | ROD |
| 55 | 265894-2 | HEX. SOCKET HEAD BOLT M6X |
| 56 | 922117-8 | HEX. SOCKET HEAD BOLT M4X |
| 57 | 164927-9 | BASE |
| 58 | 315643-8 | CLAMP PLATE |
| 59 | 942051-6 | SPRING WASHER 4 |
| 60 | 922136-4 | HEX. SOCKET HEAD BOLT M4X |
| 61 | 181150-1 | HANDLE SET |
| 62 | 911223-4 | PAN HEAD SCREW M5*16, JR3070T |
| 64 | 682504-0 | CORD GUARD 10-85, 5606B |
| 65 | 911133-5 | PAN HEAD SCREW M4X8 WITH WR, 438 |
| 66 | 687001-1 | STRAIN RELIEF B04510 |
| 67 | 645253-0 | CAPACITOR, 6410 |
| 68 | 685700-9 | SPONGE SHEET X M802/HR3850B |
| 69 | 651256-4 | SWITCH, JR3000V |
| 70 | 911265-8 | PAN HEAD SCREW M5X40 |
| 71 | 961011-9 | STOP RING, HR2450 |
| 74 | 157819-9 | MOTOR HOUSING |
| 75 | 181021-2 | CARBON BRUSH CB-51 |
| 76 | 643550-8 | CARBON BRUSH HOLDER CAP 5-8, 6300L |
| 77 | 911223-4 | PAN HEAD SCREW M5*16, JR3070T |
| 78 | 263014-2 | RUBBER PIN 4, 3703 |
| 80 | 911153-9 | PAN HEAD SCREW M4X28 |
| 81 | 263002-9 | RUBBER PIN 4, 5704R |
| 82 | 216008-6 | STEEL BALL, 6827 |
| 83 | 231314-8 | COMPRESSION SPRING 4 |
| 84 | 272217-7 | LEVER 23 |
| 85 | 911546-0 | PAN HEAD SCREW M4X25 |
| 86 | 321648-8 | GUIDE PIN |
| 87 | 253877-4 | FLAT WASHER 8 |
| 88 | 410199-7 | BAFFLE PLATE |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
