Makita Spare Parts for Circular Saw HS7611J
We have the original Spares MAKITA for Circular Saw HS7611J, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of Circular Saw and the respective parts of the code.
| Circular Saw HS7611J | ||
| # | Part Num. | Description |
| 1 | 266024-8 | SCREW M6X20 |
| 2 | 224409-4 | EXTERNAL FLANGE 35 BSS611R |
| 3 | 224593-5 | INTERNAL FLANGE 35 |
| 4 | 961155-5 | RETAINING RING S38 |
| 5 | 266034-5 | SCREW CT 4X16 |
| 6 | 271444-3 | LEVER 37 |
| 7 | 319188-8 | SAFETY COVER HS7601 |
| 8 | 231887-1 | TENSION SPRING 4 HS7601 |
| 9 | 345391-5 | THICKNESS RING MT582 |
| 10 | 326444-9 | SHAFT HS7601 |
| 11 | 911226-8 | CYLINDER HEAD SCREW. M5X18 |
| 12 | 135947-0 | BEARING BOX |
| 13 | 211129-9 | BALL BEARING 6201DD NSK |
| 14 | 285852-2 | BEARING CHAIN 19-33 |
| 15 | 257173-2 | RING 12 5604R |
| 16 | 221575-8 | GEAR 43 |
| 17 | 961052-5 | S12 RETAINING RING |
| 18 | 210137-7 | 606ZZ BEARING |
| 19 | 213560-5 | RING 44 X HK0500 |
| 20 | 265117-8 | SCREW M6X20 HS7601 / HS6601 / MT582 |
| 21 | 262556-3 | RUBBER SLEEVE 6 X MT582 |
| 22 | 144729-9 | HOUSING BLADE |
| 23 | 233117-6 | SPRING COMPRESSION 6 X GA7010C |
| 24 | 347284-2 | SHAFT LOCK |
| 25 | 211131-2 | BALL BEARING 6001DD |
| 26 | 241876-8 | FAN 76 |
| 27 | 515433-1 | ARMATURE 220V |
| 28 | 681644-1 | INSULATED WASHER X 9227CB |
| 29 | 210005-4 | BALL BEARING 608 DDW |
| 30 | 253192-6 | FLAT WASHER 14 |
| 31 | 261109-5 | RUBBER WASHER 13 |
| 32 | 458033-3 | DEFLECTOR |
| 33 | 266352-1 | SCREW 5X65 MT901 |
| 34 | 594679-2 | STATOR 220V-240V |
| 35 | 266326-2 | SCREW 4X18 X MT601 |
| 37 | 265104-7 | SCREW M5 X 40 MT240 |
| 38 | 643750-0 | BRUSH HOLDER CAP |
| 39 | 191963-2 | CARBON BRUSH CB-303 |
| 40 | 144767-1 | HOUSING MOTOR CPL |
| 41 | 682540-6 | CORD GUARD JN1601 |
| 43 | 687124-5 | CABLE CLAMP MT953 |
| 44 | 266326-2 | SCREW 4X18 X MT601 |
| 45 | 458087-0 | HANDLE COVER |
| 46 | 650245-6 | SWITCH SGE115CDY-10 |
| 47 | 654532-5 | CLAMP 1P |
| 48 | 645200-1 | CAPACITOR |
| 49 | 346311-2 | LEVER MT582 |
| 50 | 257953-6 | RING E-12 MT582 |
| 51 | 252199-9 | NUT M8X13 MT582 |
| 52 | 941201-0 | FLAT WASHER 8 |
| 53 | 161776-5 | DEPTH GUIDE |
| 54 | 266396-1 | SCREW M8X24 MT582 |
| 55 | 233376-2 | SPRING COMPRESSION 8 X MT952 |
| 56 | 346826-9 | BASE X HS7601 |
| 57 | 265118-6 | SCREW M5 MT582 |
| 58 | 256480-0 | PIN 6-7 BSS611R |
| 59 | 346827-7 | ANGULAR GUIDE X HS7601 |
| 60 | 252103-8 | LUCK NUT X JR3020 |
| 61 | 265726-3 | SCREW M6X15 |
| 62 | 317031-5 | CORNER PLATE X HS7601 |
| 63 | 941151-9 | WASHER 6 X HM1303 |
| 64 | 942151-2 | WASHER 6 4101R |
| 65 | 265708-5 | SCREW M6 X 20 X LS1040 |
| 69 | 265726-3 | SCREW M6X15 |
| 70 | 942151-2 | WASHER 6 4101R |
| 71 | 941151-9 | WASHER 6 X HM1303 |
| 72 | 265726-3 | SCREW M6X15 |
| 73 | 233376-2 | SPRING COMP. 8 X MT952 |
| 74 | 346847-1 | HS7601 SUPPORT |
| 75 | 346846-3 | PLATE X HS7601 |
| 76 | 911106-8 | SCREW M4X8 |
| 77 | 912107-9 | SCREW M4X8 |
| 78 | 912107-9 | SCREW M4X8 |
| 79 | 266436-5 | SCREW M5X8 |
| 80 | 912212-2 | SCREW 5 X 12 X LC1230 |
| 81 | 231469-9 | SPRING 4 X 6811DW |
| 82 | 453284-3 | LOCK BUTTON X HS6101 |
