Makita Spare Parts for Demolition Hammer SDS Max AVT HM1213C
€71.79
Tax included
Makita Spare Parts for Demolition Hammer SDS Max AVT HM1213C
MAKITA Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer SDS Max AVT HM1213C.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Demolition Hammer SDS Max AVT HM1213C
MAKITA Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer SDS Max AVT HM1213C.
In the following table, look for the model of the Hammer and the respective parts of the code.
| Demolition Hammer AVT Makita HM1213C | ||
| # | Part Num. | Description |
| 1 | 424165-8 | TOOL HOLDER CAP X HM1203C |
| 2 | 233973-4 | RING SPRING 26 X HM1203C |
| 3 | 267386-7 | WASHER 30 X HM1203C |
| 4 | 450894-7 | COVER CHUCK HM1203C |
| 5 | 262147-0 | RUBBER RING 30 X HM1203C |
| 6 | 324987-5 | CHUCK RING HM1203C |
| 7 | 450895-5 | RELEASE COVER X HM1203C |
| 8 | 310279-8 | TOOL RETAINER X HM1203C |
| 9 | 346015-6 | SPRING GUIDE HM1203C |
| 10 | 234086-4 | COMPRESSION SPRING 56 X HM1203C |
| 11 | 961232-3 | RETAINING RING |
| 12 | 450893-9 | CHANGE RING COVER X HM1203C |
| 13 | 324969-7 | CHANGE RING HM1203C |
| 14 | 324988-3 | LOCK RING HM1203C |
| 15 | 922243-3 | BOLT M5 X 25 X 2702 |
| 16 | 450902-4 | HOUSING COVER HM1203C |
| 17 | 233970-0 | RING SPRING 35 X HM1203C |
| 18 | 158858-2 | BARREL COMP. X HM1203C |
| 19 | 922456-6 | BOLT M8x35 |
| 20 | 213720-9 | O-RING 67 X HR2400 |
| 21 | 262148-8 | RUBBER RING 39 X HM1203C |
| 22 | 267387-5 | WASHER 39 X HM1203C |
| 23 | 213079-4 | RING 35,5 X HM1203C |
| 24 | 324985-9 | TOOL HOLDER X HM1203C |
| 25 | 213980-3 | O-RING 21 X HR4501C |
| 26 | 213431-6 | FLUORIDE RING 28 HM1202C/HR500 HR5001C |
| 27 | 213394-6 | RUBBER RING X HR5001C |
| 28 | 324990-6 | IMPACT BOLT HM1203C |
| 29 | 324993-0 | SHOULDER SLEEVE X HM1203C |
| 30 | 262149-6 | RUBBER RING 24 X HM1203C |
| 31 | 324993-0 | SHOULDER SLEEVE X HM1203C |
| 32 | 326002-1 | STRIKER X HM1203C |
| 33 | 213499-2 | O-RING 5.31 X HM1203C |
| 34 | 213581-7 | O-RING 44 X HM1203C |
| 35 | 450889-0 | ONEWAY VALVE GUIDE HM1203/1213 HM1203C |
| 36 | 331925-0 | CYLINDER 40 X HM1203C |
| 37 | 268121-6 | PIN 12 X HR5201C |
| 38 | 213499-2 | O-RING 5.31 X HM1203C |
| 39 | 450961-8 | PISTON X HM1203C |
| 40 | 213149-9 | O-RING 35 X HM1203C |
| 41 | 450890-5 | CONNECTING ROD HM1203C |
| 42 | 213118-0 | O-RING 12 X HR5210C |
| 43 | 318361-7 | PIPE HOLDER HM1213C |
| 44 | 213118-0 | O-RING 12 X HR5210C |
| 45 | 419773-8 | SPRING GUIDE HR5210C |
| 46 | 234085-6 | COMPRESSION SPRING 15 X HM1213C |
| 47 | 213953-6 | O-RING 24 HR2430 |
| 48 | 331745-2 | PIPE 22 X HR5210C |
| 49 | 213953-6 | O-RING 24 HR2430 |
| 50 | 324992-2 | COUNTER WEIGHT X HM1213C |
| 51 | 234085-6 | COMPRESSION SPRING 15 X HM1213C |
| 52 | 419773-8 | SPRING GUIDE HR5210C |
| 53 | 213118-0 | O-RING 12 X HR5210C |
| 54 | 318361-7 | PIPE HOLDER HM1213C |
| 55 | 213118-0 | O-RING 12 X HR5210C |
| 56 | 450899-7 | CRANK CAP COVER HM1203C |
| 57 | 911133-5 | SCREW M4X18 |
| 58 | 443127-7 | FILTER X HM1203C |
| 59 | 450898-9 | CRANK CAP HM1203C |
| 60 | 424166-6 | SEAL RING HM1203C |
| 61 | 450892-1 | PIPE X HM1213C |
| 62 | 318363-3 | CRANK HOUSING X HM1213C |
| 63 | 266482-8 | SCREW M6X40 X HM1203C |
| 64 | 419008-7 | FIX GUIDE X HR4001C |
| 65 | 423366-5 | CUSHION PLATE X HR5201C |
| 66 | 324994-8 | CRANK SHAFT HM1203C |
| 67 | 211424-7 | BALL BEARING 6206LLU X HM1203C |
| 68 | 226691-1 | GEAR 57 X HM1203C |
| 69 | 267398-0 | WASHER 12 X HM1203C |
| 70 | 424167-4 | SEAL RING HM1203C |
| 71 | 158859-0 | GEAR HOUSING COMP. X HM1203C |
| 72 | 213231-4 | OIL SEAL X HR4500C |
| 73 | 331596-3 | SLEEVE 12 X HR4500C |
| 74 | 211249-9 | BALL BEARING 6302LLU HM1203C |
| 75 | 267397-2 | WASHER 15 X HM1203C |
| 76 | 240003-4 | FAN X 2702 |
| 77 | 517818-7 | ARMATURE X HM1203C |
| 78 | 681642-5 | WASHER X LS1013 |
| 79 | 211289-7 | BALL BEARING 6000DDW |
| 80 | 450900-8 | BAFFLE PLATE HM1203C |
| 81 | 266095-5 | SCREW 5 X 55 HR5001C |
| 82 | 636303-2 | FIELD 240V FOR HR5201C |
| 83 | 450904-0 | MOTOR HOUSING X HM1203C |
| 84 | 632D00-2 | CARBON BRUSHES HOLDER HM1203C |
| 85 | 195844-2 | CARBON BRUSHE SET CB-175 |
| 86 | 450901-6 | REAR COVER HM1203C |
| 87 | 266041-8 | PT SCREW 5x25 |
| 88 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 89 | 266192-7 | SCREW 4 X 14 X HR4001C / HR4010C |
| 90 | 631871-0 | CONTROLLER HM1213C |
| 91 | 638650-7 | LEAD UNIT X HM1203C |
| 92 | 419010-0 | LENS X HR4001C / HR4010C |
| 93 | 233434-4 | COMPRESSION SPRING 11 X HR4011C |
| 94 | 266173-1 | PT SCREW 5X30 |
| 95 | 253807-5 | WASHER 5 6012D / HD / 62/63 / 64DW |
| 96 | 450905-8 | HANDLE BASE X HM1213C |
| 97 | 419783-5 | DUST COVER SUPPORT X HR5211C |
| 98 | 424001-8 | DUST COVER X HR5211C |
| 99 | 232209-8 | LEAF SPRING X HM0860C |
| 100 | 450891-3 | LEVER STOPPER X X HM1203C |
| 101 | 866631-3 | LABEL HM1213C |
| 102 | 266041-8 | PT SCREW 5x25 |
| 103 | 450896-3 | SLIDE LEVER HM1213C |
| 104 | 266041-8 | PT SCREW 5x25 |
| 105 | 313124-6 | SHOULDER SLEEVE 6 HR4011C |
| 106 | 450906-6 | HANDLE X HM1213C |
| 107 | 263027-3 | RUBBER PIN 4 X HM0860C |
| 108 | 651423-1 | SWITCH X 3706 |
| 109 | 423379-6 | SPONGE SHEET X HM1203C |
| 110 | 654531-7 | TERMINAL BLOCK 2P X 420S |
| 111 | 682560-0 | CORD GUARD X HM1202C / 9079S |
| 113 | 687169-3 | STRAIN RELIEF HP1620 |
| 114 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 115 | 450908-2 | HANDLE COVER X HM1203C |
| 116 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 117 | 265439-6 | SCREW M8X150 X HM1100C |
| 118 | 417002-3 | SIDE HANDLE CAM HM1202C |
| 119 | 318505-9 | SIDE HANDLE BASE 82A X HM1203C |
| 120 | 951166-8 | SPRING PIN 5/24 |
| 121 | 318506-7 | SIDE HANDLE BASE 82B X HM1203C |
| 122 | 417003-1 | SIDE HANDLE X HM1202C |
| 123 | 417002-3 | SIDE HANDLE CAM HM1202C |
| 124 | 252640-2 | HANDLE KNOB M8 X |
| 125 | 267164-5 | WASHER 15 HP2040-2041-2042 |
| 127 | 135269-8 | HANDLE "D" X HM1203C P28 |
| 999 | 195114-9 | SERVICE PACK HM1203C / 1213C P24 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
