Makita Spare Parts for Metal Shear JS1602
€52.30
Tax included
Makita Spare Parts for Metal Shear JS1602
Makita genuine spare parts or replacements parts for to fix Makita JS1602 Metal Shear.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Metal Shear JS1602
Makita genuine spare parts or replacements parts for to fix Makita JS1602 Metal Shear.
In the following table, look for the model of the Blenchschere and the respective parts of the code.
| Makita JS1602 Metal Shear Spare Parts JS1602 | ||
| # | Part Num. | Description |
| 1 | 266048-4 | SCREW M4 X 40 X 4334D |
| 2 | 141691-9 | GEAR BOX |
| 3 | 210030-5 | BEARING 627ZZ X MT601 |
| 4 | 253823-7 | ROND. FLAT 7 X JS1600 |
| 5 | 331151-1 | ROD X JS1600 |
| 6 | 212063-6 | ROLLER BEARING 1012 Z |
| 7 | 253758-2 | FLAT WASHER 10 |
| 8 | 141690-1 | SHAFT GEAR |
| 9 | 210033-9 | BEARING 696ZZ X 2107FK |
| 10 | 442185-0 | SEAL |
| 11 | 454076-3 | COVER GEAR BOX |
| 12 | 256110-3 | PIN 6 |
| 13 | 913427-4 | SCREW 8X16 S. |
| 14 | 346620-9 | PROTECTION |
| 15 | 922206-9 | SCREW ESAG. IN CASE. M5x10 |
| 16 | 321311-3 | AUCTION BLADE X JS1600 |
| 17 | 253334-2 | WASHER 5 X JS1600 |
| 18 | 191383-0 | PAIR OF KNIVES X JS1600 |
| 19 | 922112-8 | SCREW M4X10 BPT350 |
| 21 | 311717-3 | SHOE X JS1600 |
| 22 | 922127-5 | BOLT M4x16 |
| 23 | 251986-3 | SCREW S. 6X6 |
| 37 | 210005-4 | BALL BEARING 608 DDW |
| 38 | 240076-7 | FAN 56 X 9554NB |
| 39 | 517674-5 | ARMATURE X JS1000 |
| 40 | 681636-0 | INSULATION WASHER |
| 41 | 210062-2 | BEARING 607ZZ X MT601 |
| 42 | 421868-5 | RING RUBBER X 9554NB |
| 43 | 450796-7 | BAFFLE FOR GA4530 |
| 44 | 452073-3 | DISTANCE X JS1601 |
| 45 | 623549-9 | STATOR FOR JS1000 |
| 46 | 266004-4 | SCREW 4x70 |
| 47 | 266492-5 | SCREW M4x25-9527PB 9528PB |
| 48 | 643839-4 | BRUSH GA4530 |
| 49 | 194722-3 | CARBON BRUSHES CB 459 X GA4530 |
| 50 | 450795-9 | CASING MOTOR GA4530 |
| 51 | 418016-5 | KEY SWITCH X MT952 |
| 52 | 450797-5 | LEVER SWITCH GA4530 |
| 54 | 233121-5 | SPRING COMPRESSION 4 X 9554NB |
| 55 | 650560-8 | SWITCH DPX 2110-R 9554NB |
| 56 | 687682-1 | CLAMP Cable tie X JS1000 |
| 57 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 58 | 638739-1 | CAPACITOR X JS1000 |
| 59 | 682566-8 | PASS CABLE X HR2450 |
| 61 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 62 | 453884-9 | BACK COVER |
