Makita Spare Parts for Trimmer RT0700CX3
€42.06
Tax included
Makita Spare Parts for Trimmer RT0700CX3
We supply original Makita spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Trimmer RT0700CX3.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Trimmer RT0700CX3
We supply original Makita spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Trimmer RT0700CX3.
In the following table, look for the model of Power Trimmer and the respective parts of the code.
| Trimmer RT0700CX3 | ||
| # | Part Num. | Description |
| 1 | 452465-6 | TOP COVER RT007CX3 |
| 3 | 620040-8 | REGULATOR RT00CX3 |
| 4 | 266326-2 | SCREW 4x18 X MT601 |
| 5 | 687124-5 | Cable tie CLAMP MT953 |
| 6 | 654542-2 | TERMINAL 2P X 4157KB |
| 8 | 682569-2 | CABLE SLEEVE MT601 |
| 9 | 645200-1 | CAPACITOR |
| 10 | 646133-3 | COIL X HP2050 |
| 11 | 643550-8 | TAP. BRUSH |
| 12 | 191940-4 | CARBON BRUSHE Set CB-411 X EX 422/421 |
| 13 | 140736-0 | HOUSING MOTOR RT0700CX3 |
| 14 | 651527-9 | SWITCH X BO4555 |
| 15 | 633769-7 | STATOR FIELD RT0700CX3 |
| 16 | 266340-8 | SCREW 4X65 GA5010 |
| 17 | 259039-2 | LOCKING 6 X 9566CV |
| 18 | 688174-3 | MAGNETIC WASHER RT0700CX3 |
| 19 | 267756-0 | WAVY WASHER X BO6040 |
| 20 | 253332-6 | FLAT WASHER 6 |
| 21 | 210023-2 | BEARING 9910/11 |
| 22 | 681668-7 | INSULATOR RT0700C |
| 23 | 515844-0 | ARMATURE RT0700CX3 |
| 24 | 240125-0 | FAN 55 RT0700CX3 |
| 25 | 961057-5 | RETAINING RING S17 |
| 26 | 210301-0 | BEARING 6003DDW RT0700C |
| 27 | 253906-3 | WAVY WASHER 26 |
| 28 | 140735-2 | CASING EXTERNAL RT0700CX3 |
| 29 | 266560-4 | SCREW 4x40 HS300D |
| 30 | 452468-0 | KEY RT0700CX3 |
| 31 | 233127-3 | SPRING 7-9527PB 9528PB |
| 32 | 256437-1 | PIN 4 X 9521NB |
| 33 | 763636-3 | CLAMP 6MM x3620 |
| 34 | 763615-1 | DADO X 3608B |
| 35 | 265763-7 | SCREW M6X25 RT0700C |
| 36 | 942151-2 | WASHER 6 4101R |
| 37 | 941151-9 | WASHER 6 X HM1303 |
| 38 | 142403-3 | HOUSING BASE |
| 39 | 941151-9 | WASHER 6 X HM1303 |
| 40 | 265792-0 | SCREW M5x35 RT0700CX3 |
| 41 | 227262-7 | GEAR 16 RT0700CX3 |
| 42 | 346392-6 | PLATE RT0700CX3 |
| 43 | 163524-8 | LEVER LOCK RT0700CX3 |
| 44 | 424396-9 | HOOD RUBBER RT0700CX3 |
| 45 | 941101-4 | FLAT WASHER 5 |
| 46 | 252103-8 | NUT X JR3020 |
| 47 | 454842-8 | BASE RT0700CX3 |
| 48 | 912112-6 | COUNTERSUNK HEAD SCREW M4X10 |
