Makita Spare Parts for Electric Chainsaws UC4051A
€28.05
Tax included
Makita Spare Parts for Corded Chainsaws UC4051A
Makita original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Corded Chainsaws UC4051A.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Corded Chainsaws UC4051A
Makita original spare parts, at discounted prices, we are a service center with after-sales service able to quickly solve the maintenance and repair any issues for Corded Chainsaws UC4051A.
In the following table, look for the model of the Electric Saws and the respective parts of the code.
| Electric Chainsaw UC4051A | ||
| # | Part Num. | Description |
| 1 | 931403-6 | HEX NUT M8 |
| 2 | 227626-5 | GEAR 12 |
| 3 | 211111-8 | BEARING 6301 X UC |
| 4 | 240003-4 | FAN X 2702 |
| 5 | 517904-4 | ARMATURE |
| 6 | 681666-1 | INSULATING WASHER UC3530A-4030 |
| 7 | 210084-2 | BEARING 629ZZ |
| 8 | 266095-5 | SCREW 5 X 55 HR5001C |
| 9 | 419410-4 | BAFFLE UC3530A-4030A |
| 10 | 636394-3 | STATOR |
| 11 | 650577-1 | SWITCH SD-006-AA-BB2AA |
| 12 | 142348-5 | HOUSING MOTOR |
| 14 | 233173-6 | SPRING FOR COMPR.4 UC3020A |
| 15 | 416178-3 | RESET BUTTON X UC3020A |
| 16 | 650717-1 | SWITCH TGC30B |
| 17 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 18 | 187901-0 | REAR HANDLE |
| 20 | 682540-6 | SLEEVE JN1601 |
| 21 | 687124-5 | Cable tie CLAMP MT953 |
| 22 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 23 | 645006-7 | CAPACITOR X LS1013 |
| 24 | 631719-6 | REGULATOR |
| 25 | 419411-2 | LEVER SWITCH UC3530A-4030 |
| 26 | 181044-0 | CARBON BRUSHES CB-153 (150/52/54) |
| 27 | 643650-4 | PLUG BRUSH |
| 29 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 30 | 142282-9 | TANK CAP CPL |
| 31 | 454822-4 | COVER GEAR BOX |
| 32 | 421959-2 | OIL TANK GASKET UC3530A-4030A |
| 33 | 454826-6 | OIL TANK |
| 34 | 424611-1 | DELIVERY PIPE |
| 35 | 424610-3 | HOSE |
| 36 | 231975-4 | SPRING TUBE OIL X DCS230T |
| 37 | 416274-7 | PLUG OIL PIPE X DCS230T |
| 38 | 454825-8 | AUCTION CHAIN BRAKE |
| 39 | 233174-4 | SPRING LOCK. X UC |
| 40 | 142341-9 | HAND GUARD |
| 41 | 158044-5 | RETAINING SPRING BRAKE X UC |
| 42 | 234005-0 | SPRING UC3530A-4030A |
| 43 | 213017-6 | RING 6 X AN621 |
| 44 | 454821-6 | GEAR BOX |
| 45 | 266041-8 | PT SCREW 5x25 |
| 46 | 210028-2 | BEARING 606ZZ |
| 47 | 961006-2 | RETAINING RING S10 |
| 48 | 221427-3 | ENDLESS LIVES |
| 49 | 142156-4 | OIL PUMP |
| 50 | 424612-9 | RUBBER |
| 51 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 52 | 227627-3 | GEAR 37 |
| 53 | 326373-6 | POST |
| 54 | 210107-6 | BEARING 6001ZZ MT690 |
| 55 | 454823-2 | THE HANDLE |
| 56 | 266041-8 | PT SCREW 5x25 |
| 57 | 345651-5 | HOOK FOR UC3020A |
| 58 | 266041-8 | PT SCREW 5x25 |
| 59 | 319091-3 | BEARING CASE |
| 60 | 266044-2 | SCREW PT.5X60 |
| 61 | 267195-4 | WASHER 4 X DCS230T |
| 62 | 266026-4 | SCREW M4 X 12 |
| 63 | 168426-3 | BRAKE DRUM UC3530A-4030A |
| 64 | 125331-7 | CLUTCH DRUM 3/8 "UC3530A |
| 65 | 253215-0 | FLAT WASHER 8 6510PBL / LVR |
| 66 | 259033-4 | LOCKWASHER X UC |
| 67 | 266427-6 | SCREW 4X12 MT923 |
| 68 | 454818-5 | PROTECTION |
| 69 | 227496-2 | STRAIGHT BEVEL GEAR 14 UC3020A |
| 70 | 326372-8 | SCREW CHAIN PULLER |
| 71 | 326310-0 | ADJUST PIN |
| 72 | 266427-6 | SCREW 4X12 MT923 |
| 73 | 142342-7 | SPROCKET COVER CPL., ES-174TLC, UC3551A/4051A |
| 74 | 183B54-5 | SPROCKET COVER SET, UC3551A/4051A |
| 75 | 263002-9 | RUBBER PIN 4 |
| 76 | 142665-3 | GEAR |
| 77 | 454819-3 | NUT COVER |
| 78 | 142235-8 | NUT CPL |
| 81 | 324685-1 | HOSE CLAMP UC3020A |
| 501 | 442040661 | SPROCKET NOSE BAR 40CM SP.1,3MM .0.50" |
| 502 | 511492756 | CHAINLOOP 3/8"-56 LINK sp.1,3 .0.50 |
