Makita Spare Parts for Electric Chainsaws UC3041A
€18.71
Tax included
Makita Spare Parts for Electric Chainsaws UC3041A
We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Chainsaw for Wood UC3041A.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Electric Chainsaws UC3041A
We supply original Makita spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Chainsaw for Wood UC3041A.
In the following table, look for the model of the Electric Saws and the respective parts of the code.
| Electric Chainsaw UC3041A | ||
| # | Part Num. | Description |
| 1 | 266326-2 | SCREW 4x18 X MT601 |
| 2 | 454725-2 | BACK COVER |
| 3 | 191972-1 | CARBON BRUSHES CB-132 |
| 4 | 682211-5 | BUSH RUBBER UC3020A |
| 6 | 424600-6 | JACK FRONT |
| 7 | 266388-0 | SCREW 5X16 FOR UC3020A |
| 8 | 253807-5 | ROND.5 6012D / HD / 62/63 / 64DW |
| 9 | 142279-8 | PROTECTION FRONT |
| 10 | 231640-5 | SPRING FOR TWIST 20 UC3020A |
| 11 | 187869-0 | HOUSING |
| 12 | 650577-1 | SWITCH SD-006-AA-BB2AA |
| 13 | 650716-3 | SWITCH TGC31B |
| 14 | 233173-6 | SPRING FOR COMPR.4 UC3020A |
| 15 | 416178-3 | RESET BUTTON X UC3020A |
| 16 | 455185-1 | SWITCH |
| 17 | 645149-5 | CAPACITOR X 4350CT |
| 18 | 266326-2 | SCREW 4x18 X MT601 |
| 19 | 687124-5 | Cable tie CLAMP MT953 |
| 20 | 682540-6 | CORD GUARD JN1601 |
| 22 | 210029-0 | BEARING 608Z X MT601 |
| 23 | 681644-1 | INSULATING WASHER X 9227CB |
| 24 | 594538-0 | STATOR FOR UC3020A |
| 25 | 266389-8 | SCREW 5 X 70 FOR UC3020A |
| 26 | 513893-1 | ARMATURE |
| 28 | 419238-0 | DEFLECTOR FOR UC3020A |
| 29 | 211061-7 | BALL BEARING 6000DD 6221DW |
| 30 | 227153-2 | GEAR FOR 12 UC3020A |
| 31 | 931403-6 | HEX NUT M8 |
| 32 | 142282-9 | TANK CAP CPL |
| 34 | 454729-4 | OIL TANK |
| 37 | 424602-2 | OIL PIPE |
| 38 | 231975-4 | SPRING TUBE OIL X DCS230T |
| 39 | 416274-7 | PLUG OIL PIPE X DCS230T |
| 40 | 268238-5 | PIN 5 EBH341U |
| 41 | 158047-9 | Chain brake lever; |
| 42 | 233175-2 | SPRING COMPRESSION 9 |
| 44 | 266326-2 | SCREW 4x18 X MT601 |
| 45 | 267195-4 | WASHER 4 X DCS230T |
| 46 | 2,1E+08 | SPRING BRAKE ES-31A |
| 47 | 346739-4 | RING BRAKE |
| 48 | 231817-2 | SPRING TENSION 5 X UC3020A |
| 49 | 454720-2 | HOUSING BEARING |
| 50 | 213017-6 | RING 6 X AN621 |
| 51 | 266326-2 | SCREW 4x18 X MT601 |
| 52 | 424601-4 | CONNECTOR |
| 53 | 135615-5 | GEAR 43 |
| 55 | 210106-8 | BEARING 6001LLB |
| 56 | 961006-2 | RETAINING RING S10 |
| 57 | 210033-9 | BEARING 696ZZ X 2107FK |
| 58 | 326359-0 | LEVERAGE |
| 60 | 266326-2 | SCREW 4x18 X MT601 |
| 61 | 345651-5 | HOOK FOR UC3020A |
| 63 | 266326-2 | SCREW 4x18 X MT601 |
| 64 | 221526-1 | BOBBIN FOR UC3020A |
| 65 | 9,3E+08 | LOCKWASHER ES-31A |
| 66 | 266007-8 | SCREW M3 X10 HP2030 |
| 67 | 454727-8 | TENSION COVER |
| 68 | 454726-0 | DIAL 30 |
| 69 | 326360-5 | SHAFT |
| 70 | 227496-2 | BEVEL GEAR 14 x UC3020A |
| 71 | 227496-2 | BEVEL GEAR 14 x UC3020A |
| 72 | 324620-9 | ADJUST SCREW X UC3020A |
| 73 | 346859-4 | TENSION SLIDE |
| 74 | 424603-0 | CABLE |
| 75 | 142156-4 | OIL PUMP |
| 76 | 221427-3 | ENDLESS LIVES |
| 77 | 266326-2 | SCREW 4x18 X MT601 |
| 78 | 266427-6 | SCREW 4X12 MT923 |
| 79 | 142281-1 | SPROCKET COVER CPL |
| 80 | 454728-6 | COVER |
| 81 | 142235-8 | NUT CPL |
| 501 | 165200-0 | CHAIN BAR 30CM SP.1,3MM |
| 502 | 511492746 | CHAIN EXTRAGUARD 46 T |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
