Makita EM2651UH Brushcutter Parts
€1.43
Tax included
Makita EM2651UH Petrol Brush Cutter 25.4cc Spare Parts
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Makita EM2651UH Petrol Brush Cutter 25.4cc.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita EM2651UH Petrol Brush Cutter 25.4cc Spare Parts
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Makita EM2651UH Petrol Brush Cutter 25.4cc.
In the following table, look for the model of Brusch Cutter and the respective parts of the code.
| EM2651UH PETROL BRUSH CUTTER | ||
| # | Part Num | Description |
| 1 | 125775-1 | CONTROL LEVER ASSEMBLY |
| 2 | 266326-2 | TAPPING SCREW 4X18 |
| 3 | 188656-0 | LEVER CASE SET |
| 3-1 | 183A10-9 | LEVER CASE SET |
| 4 | 638705-8 | LEAD UNIT |
| 5 | 451081-1 | CABLE HOLDER |
| 6 | 452005-0 | CORRUGATE TUBE |
| 7 | 168570-6 | CONTROL CABLE |
| 8 | 451083-7 | LOCK OFF LEVER |
| 9 | 233541-3 | TORSION SPRING 7 |
| 10 | 233540-5 | TORSION SPRING 11 |
| 11 | 451084-5 | THROTTLE LEVER |
| 12 | 451085-3 | SWITCH COVER |
| 12-1 | 455722-1 | SWITCH COVER |
| 13 | 451082-9 | SWITCH LEVER |
| 14 | 232251-9 | LEAF SPRING |
| 15 | 188656-0 | LEVER CASE SET |
| 15-1 | 183A10-9 | LEVER CASE SET |
| 16 | 266326-2 | TAPPING SCREW 4X18 |
| 17 | 188659-4 | GRIP SET |
| 18 | 188659-4 | GRIP SET |
| 19 | 911256-9 | PAN HEAD SCREW M5X35 |
| 20 | 331862-8 | HANDLE 19 |
| 21 | 168524-3 | KNOB 57 |
| 21-1 | 168796-0 | KNOB 57 |
| 22 | 318429-9 | HANDLE CLAMP |
| 23 | 318428-1 | HANDLE HOLDER |
| 24 | 233202-5 | COMPRESSION SPRING 20 |
| 25 | 318427-3 | PIPE HOLDER |
| 26 | 318426-5 | PIPE CLAMP |
| 27 | 922241-7 | HEX. SOCKET HEAD BOLT M5X25 |
| 28 | 195143-2 | HANGER SET |
| 29 | 911233-1 | PAN HEAD SCREW M5X20 |
| 30 | 422045-2 | CUSHION |
| 30-1 | 422167-8 | CUSHION M O |
| 31 | 140431-2 | SHAFT PIPE COMPLETE |
| 32 | 891174-6 | CAUTION LABEL |
| 33 | 819312-8 | MAKITA LOGO LABEL |
| 34 | 911256-9 | PAN HEAD SCREW M5X35 |
| 35 | 324893-4 | SHAFT |
| 35-1 | 327056-1 | SHAFT |
| 36 | 922218-2 | H.S.H.BOLT M5X14 WITH WR |
| 36-1 | 922206-9 | HEX. SOCKET HEAD BOLT M5X10 |
| 37 | 125556-3 | GEAR CASE ASSEMBLY |
| 37-1 | 123833-7 | GEAR CASE ASSEMBLY |
| 37-2 | 123833-7 | GEAR CASE ASSEMBLY |
| 40 | 210049-4 | BALL BEARING 609ZZ |
| 40-1 | 210157-1 | BALL BEARING 609ZZ |
| 41 | 961005-4 | RETAINING RING S-9 |
| 41-1 | 257986-1 | RETAINING RING (EXT) S-9 |
| 42 | 962103-7 | RETAINING RING R-24 |
| 42-1 | 257987-9 | RETAINING RING (INT)R-24 |
| 43 | 922241-7 | HEX. SOCKET HEAD BOLT M5X25 |
| 44 | 265590-2 | +HEX.BOLT M8X10 WITH R |
| 45 | 211019-6 | BALL BEARING 626 |
| 46 | 188866-9 | CUTTER SHAFT SET |
| 46-1 | 188902-1 | CUTTER SHAFT SET |
| 46-2 | 183A00-2 | CUTTER SHAFT SET |
| 46-3 | 183K10-9 | CUTTER SHAFT SET |
| 49 | 210115-7 | BALL BEARING 6001LLU |
| 50 | 962106-1 | RETAINING RING R-28 |
| 50-1 | 257407-3 | RETAINING RING (INT)R-28 |
| 51 | 331861-0 | RECEIVE WASHER |
| 51-1 | 326821-5 | RECEIVE WASHER |
| 52 | 346084-7 | CLAMP WASHER |
| 53 | 168526-9 | CUP |
| 54 | 264025-0 | HEX. NUT M10-17 |
| 55 | 452260-4 | PROTECTOR |
| 56 | 451097-6 | PROTECTOR COVER |
| 57 | 266579-3 | HEX SOCKET HEAD BOLT M6X30 |
| 57-1 | 266280-0 | HEX. SOCKET HEAD BOLT M6X25 |
| 58 | 346073-2 | PROTECTOR CLAMP |
| 58-1 | 347012-5 | PROTECTOR CLAMP 24 |
| 60 | 125746-8 | CLEANER COVER ASSEMBLY |
| 60-1 | 126202-1 | CLEANER COVER ASSEMBLY |
| 60-2 | 123499-3 | CLEANER COVER ASSEMBLY |
| 61 | 265791-2 | THUMB SCREW M4 |
| 62 | 443141-3 | AIR CLEANER ELEMENT |
| 62-1 | 443171-4 | AIR CLEANER ELEMENT S |
| 62-2 | 443171-4 | AIR CLEANER ELEMENT O |
| 63 | 443140-5 | AIR CLEANER ELEMENT |
| 63-1 | 443169-1 | AIR CLEANER ELEMENT S |
| 64 | 266601-6 | HEX. SOCKET HEAD BOLT M5X60 |
| 64-1 | 266618-9 | H.S.BUTTON HEAD BOLT M5X60 |
| 65 | 125833-3 | CLEANER PLATE ASSEMBLY |
| 65-1 | 126004-5 | CLEANER PLATE ASSEMBLY |
| C10 | 162322-7 | SEPARATOR STOPPER |
| C20 | 162325-1 | SEPARATOR GASKET |
| C30 | 352013-0 | SEPARATOR NET |
| 65-2 | 126198-6 | CLEANER PLATE ASSEMBLY |
| C10 | 266007-8 | TAPPING SCREW BIND PT 3X10 |
| 65-3 | 123501-2 | CLEANER PLATE ASSEMBLY |
| C10 | 266007-8 | TAPPING SCREW BIND PT 3X10 |
| 66 | 162300-7 | SEPARATOR PLATE |
| 66-1 | 162324-3 | SEPARATOR PLATE |
| 66-2 | 162346-3 | SEPARATOR PLATE |
| 67 | 213540-1 | O RING 15 |
| 68 | 424316-3 | CHECK VALVE |
| 68-1 | 424316-3 | CHECK VALVE |
| 69 | 422062-2 | PIPE |
| 69-1 | 422099-9 | PIPE |
| 70 | 325665-0 | JOINT PIPE |
| 71 | 442153-3 | CARBURETOR GASKET |
| 72 | 922228-9 | H.S.H.BOLT M5X18 WITH WR |
| 72-1 | 266787-6 | H.S.H.BOLT M5X18 WITH WR |
| 73 | 451825-9 | CLAMP |
| 74 | 451729-5 | INSULATOR |
| 75 | 213547-7 | O-RING 12 |
| 76 | 422055-9 | BREATHER PIPE |
| 76-1 | 422109-2 | BREATHER PIPE |
| 77 | 345918-1 | HOSE CLAMP |
| 78 | 318587-1 | ROCKER COVER OUTER |
| 78-1 | 318745-9 | ROCKER COVER OUTER |
| 79 | 266570-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 79-1 | 922222-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 80 | 451728-7 | ROCKER COVER INNER |
| 80-1 | 452795-5 | ROCKER COVER INNER |
| 80-2 | 453860-3 | ROCKER COVER INNER |
| 81 | 162304-9 | ROCKER COVER GASKET |
| 82 | 424302-4 | PLUG CAP |
| 83 | 324891-8 | PLUG CAP SPRING |
| 84 | 168534-0 | SPARK PLUG |
| 85 | 125554-7 | ROCKER ARM ASSEMBLY |
| 86 | 256200-2 | PIN 5 |
| 87 | 256865-0 | ROD 2.5 |
| 88 | 325668-4 | SPRING RETAINER |
| 89 | 451735-0 | CLUTCH CASE |
| 89-1 | 143823-4 | CLUTCH CASE COMPLETE |
| 90 | 922228-9 | H.S.H.BOLT M5X18 WITH WR |
| 91 | 450569-8 | SPACER |
| 91-1 | 450569-8 | SPACER |
| 92 | 961052-5 | RETAINING RING (EXT) S-12 |
| 93 | 210111-5 | BALL BEARING 6201LLU |
| 93-1 | 210111-5 | BALL BEARING 6201LLU |
| 94 | 962151-6 | RETAINING RING R-32 |
| 95 | 168609-5 | CLUTCH DRUM |
| 95-1 | 168809-7 | CLUTCH DRUM COMPLETE |
| 95-2 | 161588-6 | CLUTCH DRUM COMPLETE |
| 96 | 266457-7 | SHOULDER HEX. BOLT M6X25 |
| 96-1 | 266864-4 | SHOULDER HEX. BOLT M6X25 |
| 97 | 267817-6 | WASHER 8 |
| 98 | 125518-1 | CLUTCH ASSEMBLY |
| 98-1 | 126135-0 | CLUTCH ASSEMBLY |
| 99 | 168498-8 | CLUTCH SHOE |
| 99-1 | 161332-1 | CLUTCH SHOE |
| 100 | 231858-8 | TENSION SPRING 6 |
| 100-1 | 231881-3 | TENSION SPRING 7 |
| 101 | 267812-6 | WASHER 6 |
| 102 | 264039-9 | CONED DISK SPRING HEXNUT M8-13 |
| 102-1 | 264039-9 | CONED DISK SPRING HEXNUT M8-13 |
| 103 | 318569-3 | FLYWHEEL |
| 104 | 444021-6 | TUBE |
| 105 | 266602-4 | HEX. SOCKET HEAD BOLT M4X20 |
| 106 | 452049-0 | SPACER |
| 107 | 168559-4 | IGNITION COIL |
| 107-1 | 161483-0 | IGNITION COIL |
| 108 | 268238-5 | PIN 5 |
| 109 | 125552-1 | CAM GEAR ASSEMBLY |
| 110 | 313169-4 | CAM LIFTER |
| 112 | 268239-3 | PIN 4 |
| 113 | 162274-2 | CAM GEAR COVER GASKET |
| 114 | 318443-5 | CAM GEAR COVER |
| 115 | 266570-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 115-1 | 922222-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 116 | 135403-0 | CYLINDER BLOCK ASSEMBLY |
| 116-1 | 135478-9 | CYLINDER BLOCK ASSEMBLY |
| 116-2 | 135478-9 | CYLINDER BLOCK ASSEMBLY |
| 117 | 266570-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 117-1 | 922222-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 118 | 424201-0 | CHECK VALVE |
| 119 | 345916-5 | MUFFLER GASKET |
| 119-1 | 346331-6 | MUFFLER GASKET |
| 120 | 168554-4 | EXHAUST MUFFLER |
| 121 | 266440-4 | HEX SOCKET HEAD BOLT M5X40 |
| 122 | 168471-8 | PULLEY |
| 123 | 451731-8 | MUFFLER PLATE |
| 124 | 922218-2 | H.S.H.BOLT M5X14 WITH WR |
| 124-1 | 922206-9 | HEX. SOCKET HEAD BOLT M5X10 |
| 125 | 638707-4 | LEAD UNIT |
| 126 | 638708-2 | LEAD UNIT |
| 127 | 808633-3 | 4STROKE INDICATION LABEL |
| 128 | 922218-2 | H.S.H.BOLT M5X14 WITH WR |
| 128-1 | 922206-9 | HEX. SOCKET HEAD BOLT M5X10 |
| 129 | 451734-2 | CYLINDER COVER |
| 129-1 | 453266-5 | CYLINDER COVER |
| 130 | 922218-2 | H.S.H.BOLT M5X14 WITH WR |
| 130-1 | 922206-9 | HEX. SOCKET HEAD BOLT M5X10 |
| 131 | 424082-2 | BUFFER RUBBER |
| 132 | 922211-6 | H.S.H.BOLT M5X12 WITH |
| 133 | 922226-3 | HEX. SOCKET HEAD BOLT M5X18 |
| 134 | 318249-1 | PIPE HOLDER |
| 135 | 318250-6 | PIPE HOLDER |
| 136 | 424083-0 | BUFFER RUBBER |
| 137 | 424200-2 | SPACER |
| 138 | 234108-0 | COMPRESSION SPRING 9 |
| 140 | 325669-2 | EXHAUST VALVE |
| 140-1 | 326366-3 | EXHAUST VALVE |
| 143 | 325670-7 | INTAKE VALVE |
| 143-1 | 326367-1 | INTAKE VALVE |
| 144 | 257298-2 | PISTON RING (TOP) 34 |
| 144-1 | 195145-8 | PISTON RING SET |
| 145 | 257299-0 | PISTON RING (SECOND) 34 |
| 146 | 257300-1 | PISTON RING 34 |
| 147 | 318441-9 | PISTON |
| 148 | 254040-2 | WOODRUFF KEY 3 |
| 149 | 135406-4 | CRANK SHAFT ASSEMBLY |
| 149-1 | 135481-0 | CRANK SHAFT ASS'Y |
| 149-2 | 126204-7 | CRANK SHAFT ASS'Y S |
| 149-2 | 150-152 | INC. |
| 149-3 | 126359-8 | CRANK SHAFT ASSEMBLY |
| 149-4 | 123774-7 | CRANK SHAFT ASSEMBLY |
| 150 | 213148-1 | OIL SEAL 10 |
| 150-1 | 213148-1 | OIL SEAL 10 |
| 150-2 | 213769-9 | OIL SEAL 10 |
| 151 | 267400-9 | FLAT WASHER 23 |
| 151-1 | 267400-9 | FLAT WASHER 23 |
| 152 | 213147-3 | OIL SEAL 12 |
| 152-1 | 213147-3 | OIL SEAL 12 |
| 152-2 | 213089-1 | OIL SEAL 12 |
| 153 | 257781-9 | PISTON PIN |
| 154 | 233976-8 | CLIP |
| 155 | 162303-1 | OIL CASE GASKET |
| 155-1 | 162323-5 | OIL CASE GASKET |
| 155-2 | 162345-5 | OIL CASE GASKET |
| 156 | 346083-9 | LEAD VALVE |
| 157 | 318590-2 | RETAINER PLATE |
| 157-1 | 318910-0 | RETAINER PLATE |
| 158 | 266569-6 | HEX. SOCKET HEAD BOLT M4X10 |
| 158-1 | 922112-8 | HEX. SOCKET HEAD BOLT M4X10 |
| 159 | 318588-9 | OIL CASE |
| 160 | 266570-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 160-1 | 922222-1 | HEX. SOCKET HEAD BOLT M5X16 |
| 161 | 424344-8 | DAMPER |
| 162 | 346305-7 | GASKET |
| 163 | 266611-3 | HEX BOLT M6X8 |
| 164 | 213548-5 | O-RING 20 |
| 165 | 325898-7 | JOINT PIPE |
| 165-1 | 325665-0 | JOINT PIPE |
| 166 | 282020-8 | HOSE CLAMP |
| 166-1 | 282020-8 | HOSE CLAMP |
| 167 | 325666-8 | OIL WEIGHT |
| 167-1 | 325666-8 | OIL WEIGHT |
| 168 | 424301-6 | OIL TUBE |
| 168-1 | 125805-8 | OIL TUBE ASSEMBLY |
| C10 | 424301-6 | OIL TUBE |
| 169 | 452047-4 | OIL CAP |
| 170 | 424343-0 | GASKET |
| 171 | 452048-2 | OIL PIPE |
| 172 | 922218-2 | H.S.H.BOLT M5X14 WITH WR |
| 172-1 | 922206-9 | HEX. SOCKET HEAD BOLT M5X10 |
| 173 | 125728-0 | FUEL TANK CAP ASSEMBLY |
| 173-1 | 127112-5 | FUEL TANK CAP ASSEMBLY |
| 174 | 451739-2 | FUEL TANK CAP |
| 175 | 168555-2 | TUBE COMPLETE |
| 175-1 | 168755-4 | TUBE COMPLETE |
| 176 | 282020-8 | HOSE CLAMP |
| 177 | 163518-3 | GASOLINE FILTER |
| 178 | 451736-8 | FUEL TANK |
| 179 | 424080-6 | BUFFER RUBBER |
| 180 | 424081-4 | BUFFER RUBBER |
| 181 | 451737-6 | TANK GUARD |
| 182 | 922218-2 | H.S.H.BOLT M5X14 WITH WR |
| 182-1 | 922206-9 | HEX. SOCKET HEAD BOLT M5X10 |
| 183 | 195309-4 | RECOIL STARTER SET |
| 184 | 424319-7 | STARTER KNOB |
| 185 | 424359-5 | DAMPER |
| 187 | 266585-8 | TAPPING SCREW 5X12 |
| 188 | 233578-0 | DAMPER SPRING |
| 189 | 452275-1 | CAM PLATE |
| 190 | 452274-3 | REEL |
| 191 | 232258-5 | SPIRAL SPRING |
| 192 | 444024-0 | STARTER ROPE |
| 193 | 451732-6 | STARTER CASE |
| 194 | 922223-9 | H.S.H.BOLT M5X16 WITH WR |
| 196 | 816565-0 | MAKITA LOGO LABEL |
| 197 | 168591-8 | CARBURETOR |
| 197-1 | 168762-7 | CARBURETOR |
| 198 | 325922-6 | SWIVEL |
| 199 | 413140-9 | WASHER |
| 200 | 266581-6 | PAN HEAD SCREW M3X8 WITH |
| 200-1 | WJ00096364 | SCREW M3X8 WITH WASHER |
| 201 | 257964-1 | STOP RING E-3 |
| 202 | 213538-8 | O RING 2 |
| 203 | 325985-2 | JET |
| 204 | 234183-6 | CONICAL COMPRESSION SPRING 5-9 |
| 205 | 442155-9 | PUMP GASKET |
| 206 | 168575-6 | PUMP DIAPHRAGM |
| 206-1 | WJ00009599 | PUMP DIAPHRAGM |
| 207 | 140437-0 | PUMP BODY |
| 207-1 | 141737-1 | PUMP BODY |
| 208 | 352010-6 | INLET SCREEN |
| 208-1 | 352021-1 | INLET SCREEN |
| 209 | 442154-1 | METERING DIAPHRAGM GASKET |
| 210 | 168620-7 | METERING DIAPHRAGM |
| 211 | 140438-8 | AIR PURGE BODY |
| 212 | 424314-7 | PRIMER PUMP |
| 213 | 346270-0 | PRIMER PUMP COVER |
| 214 | 266582-4 | TAPPING SCREW 3X24 |
| 220 | 413143-3 | WASHER |
| 221 | 638706-6 | LEAD UNIT |
| 222 | 135398-7 | PROTECTOR EXTENSION ASSY |
| 223 | 266326-2 | TAPPING SCREW 4X18 |
| 224 | 346074-0 | CUTTER |
| 224-1 | 347050-7 | CUTTER O |
| 225 | 891177-0 | EM2651UH MODEL NO.LABEL |
| 226 | 819430-2 | CAUTION TAG |
| 227 | 810455-9 | CAUTION PLATE |
| 228 | 891985-9 | INDICATION LABEL |
| 228-1 | 800F73-7 | INDICATION LABEL |
| 229 | 941152-7 | FLAT WASHER 6 |
| 230 | 443170-6 | FELT |
| 231 | 352020-3 | SEPARATOR MESH |
| 232 | 453865-3 | SEPARATOR CASE |
| 233 | 453862-9 | OIL CASE PLATE |
| 234 | 801D19-4 | SERIAL NO. LABEL |
| 235 | 135599-7 | SHORT BLOCK ASS'Y 25.4CC |
| 235-1 | 135668-4 | SHORT BLOCK ASS'Y 25.4CC |
| A01 | 122906-3 | BAND ASSY |
| C10 | 140400-3 | HOOK COMPLETE |
| A02 | 242072-1 | OIL BOTTLE |
| A03 | 783013-3 | BOX DRIVER 16-17 |
| A04 | 783217-7 | HEX. WRENCH 5 |
| A04-1 | 783232-1 | HEX. WRENCH 5 |
| A04-2 | 783217-7 | HEX. WRENCH 5 |
| A05 | 783223-2 | HEX. WRENCH 4 |
| A05-1 | 783202-0 | HEX. WRENCH 4 |
| A06 | 831304-7 | ACCESSORY BAG |
| A07 | 451252-0 | TOOL COVER |
| A09 | 195298-3 | CUTTER BLADE SET |
| A10 | 195500-4 | OIL SET |
| A10-1 | 197007-6 | OIL SET |
| A10-2 | 191A18-9 | OIL SET |
| A10-3 | 197007-6 | OIL SET |
| E01 | 266427-6 | TAPPING SCREW 4X12 |
| E02 | 452219-1 | CHOKE PLATE |
| E03 | 452220-6 | CHOKE LEVER |
| E05 | 801P53-6 | GAS EMISSION APPROVAL LABEL |
| E05-1 | 809L93-4 | GAS EMISSION APPROVAL LABEL |
| F03 | 196129-9 | BAND ASSEMBLY SET |
| F04 | 196715-6 | Maintenance kit set |
| F08 | 198502-9 | NYLON CORD 2.4-30M SET |
| F09 | 198503-7 | NYLON CORD 2.4-120M SET |
| F10 | 198504-5 | NYLON CORD 2.4-180M SET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita EM2651UH
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- MORE INFO:
- info@bricoutensili.com
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
16 other products in the same category:
