Makita Trimmer EH760 Parts
€25.82
Tax included
Makita Spare Parts for Hedge Trimmer EH760
We have the original Spares MAKITA Spare Parts for Hedge Trimmer EH760 the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Hedge Trimmer EH760. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Hedge Trimmer EH760
Fix Your Hedge Trimmer EH760. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Trimmer and the respective parts of the code.
| Hedge Trimmer EH760 Parts | ||
| # | Part Num. | Description |
| Pag.1 | ||
| 11 | 1361410000 | DRUM CPL HT2256D-HT2276E |
| 12 | 0301080000 | REINFORCEMENT PLATE HT2256D- |
| 13 | 162050000K | NUT M5 X HT2256D-HT2276E |
| 14 | 164060000K | HEX NUT M6 HT2256D |
| 15 | 326100002A | UPPER CASING |
| 16 | 055001000R | NUT M6 X HT2256D-HT2276E |
| 17 | 351006080K | BALL BEARING 608Z HT2256 |
| 18 | 354060010K | BALL BEARING HT2256D |
| 19 | 1361420000 | PINION GEAR HT2256D- |
| 20 | 054060150K | BOLT M6X15 X HT2256D-HT2276 |
| 21 | 1360030000 | CONNECTING ROD GEAR HT2256D - |
| 22 | 011050200K | SCREW M5X20 HT2276E |
| 23 | XOC0000018 | CONNECTING ROD HTR5600 |
| 24 | 283026000K | RETAINING RING HT2256D - |
| 25 | 028109009A | HEDGE CUTTER BLADE COVER |
| 26 | 010030050K | SCREW M3X5 X HT2256D-HT2276E |
| 27 | 0301100000 | CONNECTING ROD PLATE HT2256D-HT2276E |
| 28 | 351006080K | BALL BEARING 608Z HT2256 |
| 29 | 1181010000 | FELT X HT2256D-HT2276E |
| 30 | 1181040000 | LOWER CASE HT2256D |
| 31 | 054050160K | BOLT M5X16 X HT2256D-HT2276 |
| 32 | 054050200K | BOLT M5X20 X HT2256D-HT2276 |
| 33 | 055060202K | BOLT M5X20 X HT2276E |
| 34 | 207060130K | WASHER HT2276E |
| 35 | 0083450000 | HANDLE X HT2276E |
| 36 | 1361900000 | RH HANDLE HT2276E |
| 37 | 1361160000 | GUIDE PLATE HT2276E |
| 38 | 6018505200 | UPPER BLADE HT2276E/EH760 |
| 39 | 6018505301 | LOWER BLADE HT2276E/EH760 |
| 40 | 0082480000 | BLADE SCREW X HT2256D-HT2276E |
| 41 | 0082490000 | BLADE SCREW (L=29) HT2276E |
| 42 | 0082500000 | WASHER X BLADE SCREW HT2256D- |
| 43 | 0082470000 | BLADE SCREW X HT2256D-HT2276E |
| 44 | 0271450000 | HT2276E SUPPORT |
| 45 | 0566079970 | CLAMP X RBC520 |
| 101 | 034001300R | KNOB COMPL. EH620 |
| 102 | 1361490000 | LEFT HANDLE HT2276E |
| 103 | 035002100R | SPRING X HT2276E |
| 104 | 040050301K | M5X30 BOLT HT2276E |
| 105 | 1361030000 | HANDLE LOCK HT2276E |
| 106 | 1361000000 | HANDLE LOCK HT2276E |
| 107 | 150050000K | M5 NUT X HT2276E |
| 108 | 1361010000 | PIN X HT2276E |
| 109 | 1361020000 | ANTI-VIBRATION X HT2276E |
| 110 | 1361040000 | RUBBER WASHER X HT2276E |
| 111 | 054060350K | M6X35 BOLT HT2276E |
| 112 | 1361910000 | BLADE PROTECTION X HT |
| 113 | 229060000K | SPRING WASHER X HT2256D |
| Pag.2 | ||
| 53 | 5251003000 | CRANKCASE CPL X HT2256D |
| 54 | 424447-8 | CASE GASKET RBC2510 |
| 55 | 0140059500 | SCREW M5X25 X RBC225-255 |
| 56 | 5252002002 | ECCENTRIC SHAFT |
| 57 | 5212500700 | PISTON X RBC221-225 |
| 58 | 5982500000 | PISTON RING X RBC221-225 |
| 59 | 5212500801 | PIN X RBC221-225 |
| 60 | 233976-8-4 | PIN RING EBH252L (4pcs) |
| 61 | 442171-1 | CYLINDER GASKET RBC2510 |
| 63 | 0119059730 | BOLT X RBC 260/230/225/255 |
| 64 | 5253500200 | INSULATING GASKET X HT2256D |
| 65 | 141056-5 | INSULATOR |
| 66 | 0140059500 | SCREW M5X25 X RBC225-255 |
| 67 | 5253500102 | EXHAUST GASKET X HT2256D |
| 68 | 5253010001 | MUFFLER X HT2256D-HT2276E |
| 69 | 0031005000 | WASHER X RBC230/410/RBK410 |
| 70 | 0119059660 | BOLT X RBC350-RBC420 - |
| 71 | 5257001010 | POLE WHEEL X HT2256D |
| 72 | 5257001020 | COIL X HT2256D-HT2276E |
| 73 | 0140049920 | SCREW M4X20 X RBC225-255 |
| 74 | 5257500300 | RUBBER X HT2256D-HT2276E |
| 75 | 324891-8 | SPRING SPARK PLUG CAP EBH341 |
| 76 | 5237503301 | SPRING CAP XRBC225-255 |
| 77 | 0650149721-10 | SPRING X RBK250 (pack of 10) |
| 78 | 5238500500 | CLUTCH SPRING X RBC225-255 |
| 79 | 6252500801 | CLUTCH SHOES X RBC225-255 |
| 80 | 267429-5 | WASHER 6 |
| 81 | 267817-6 | WASHER 8 EBH252L |
| 82 | 266457-7 | SCREW M6X25 EBH252L |
| 83 | 6202500000 | SUPPORT X HT2256D-HT2276E |
| 84 | 5253500500 | MUFFLER CAP X HT2256D |
| 85 | 0043705160 | SCREW COMPLETE X HT2256D-HT2276E |
| 86 | 5255001000 | STARTER COMPLETE HT2256D |
| 87 | 5255001020 | SCREW X HT2256D-HT2276E |
| 88 | 5505001030 | CLUTCH PLATE X RBC 310/RBC520 |
| 89 | 5105015050 | CLUTCH SPRING X RBC 310/520 |
| 90 | 5105015020 | STARTER PAWL X RBC 310/RBC520 |
| 91 | 5105015060 | RETURN SPRING X RBC310/RBC520 |
| 92 | 5025001010 | STARTER SPOOL X RBC 310 |
| 93 | 5235024022 | STARTER ROPE X RBK250-RBC225-2 |
| 94 | 232257-7 | SPIRAL SPRING EBH341U |
| 95 | 5225004020 | STARTER KNOB HT2256D |
| 96 | 911218-7 | CYLINDER HEAD SCREW M5X14 |
| 97 | 0200070010 | WASHER X HT2256D-HT2276E |
| 98 | 5255500301 | CYLINDER COVER EH561 |
| 99 | 5503503001 | SPACER X HT2256D-HT2276E |
| 100 | 0140059490 | SCREW X HT2256D-HT2276E |
| 101 | 0031206000 | WASHER G.24/35-RBC225-255 |
| 102 | 0011306160 | BOLT X RBC230/260/225/255 |
| 103 | 5215500300 | DEFLECTOR PLATE X HT2256D |
| 104 | 5255500001 | POLAR WHEEL HOUSING HT2256D |
| 105 | 0043505160 | SCREW COMPLETE X HT2556D-HT2276E |
| 106 | 5256012001 | TUBE COMPLETE HT2256D-HT2276E |
| 107 | 5256002000 | TANK PLATE COMPLETE HT2256D |
| 108 | 163447-0 | FUEL FILTER X DCS230T |
| 109 | 0043705160 | SCREW COMPLETE X HT2256D-HT2276E |
| 110 | 5256025000 | TANK COMPLETE X HT2256D-HT2276 |
| 111 | 452920-8 | TANK CAP |
| 112 | 1181240000 | SPACER X HT2256D-HT2276E |
| 113 | 0140059450 | SCREW M5X18 X RBK250-RBC225/25 |
| 114 | 6202006000 | BOLT X RBC310 |
| 115 | 6165500200 | GROUND CABLE X HT2276E |
| 116 | 140436-2 | DISK EBH341U |
| Pag.3 | ||
| 116 | 5256007000 | CARBURETOR X HT2256D-HT2276E |
| 116N | 5256032000 | CARBURETOR X HT2256D-HT2276E |
| 117 | 5253020010 | FILTER COVER RBC201 |
| 118 | 5203004010 | AIR FILTER X HT2256D |
| 119 | 0043305650 | SCREW CPL XHT2256D-HT2276E |
| 120 | 5253003020 | FILTER HOUSING COMPL. RBC201 |
| 121 | 5256501100 | RING X HT2256D-HT2276E |
| 122 | 5256501200 | GASKET X HT2256D-HT2276E |
| 123 | 5256500100 | CABLE SUPPORT HT2256D-HT2276E |
| 124 | 5236018040 | ACC. CABLE XRBC230-260-310-225- |
| 125 | 266581-6 | SCREW M3X8 EBH341U |
| 126 | 5256032010 | CARBURETOR VALVE X RBL250- |
| 127 | 5316005120 | RING X RBC 260/230/310/225/2 |
| 128 | 5246001010 | GASKET X RBC 260/230/310/ |
| 129 | 5026004010 | NOZZLE X HT2256D-HT2276E |
| 130 | 5246001030 | GASKET PUMP RBC260-230-310- |
| 131 | WJ00009599 | DIAPHRAGM PUMP X DCS230T |
| 132 | 5016004010 | CONNECTOR X RBC 260/230/310/225 |
| 133 | 5256007010 | COMPLETE PUMP BODY X HT2256D |
| 134 | 442154-1 | GASKET DIAPHRAGM EBH341U |
| 135 | 168574-8 | COMPLETE DIAPHRAGM EBH341U |
| 136 | 5236046060 | COMPLETE AIR FILTER BODY RBC350 |
| 137 | 424314-7 | PRIMING PUMP EBH341 |
| 138 | 5236046050 | PUMP COVER FOR RBC350-RBC42 |
| 139 | 266582-4 | SCREW 3X24 EBH341U |
| 140 | 442177-9 | GASKET |
| 141 | 5216008010 | SCREW CABLE REGULATOR ACC.XRBC260 310 |
| 142 | 5316005450 | NUT REGULATOR STOP RBC260/310 |
| Pag.4 | ||
| 16 | 034000110R | COVER FOR EH760 HT2276E |
| 17 | 034000120R | COVER TO EH760 HT2276E |
| 18 | 034000130R | LEVER X EH760 HT2276E |
| 19 | 034000140R | LEVER X EH760 HT2276E |
| 20 | 034000150R | KEY X EH760 HT2276E |
| 21 | 6415011060 | CLAMP X EH760 HT2276E |
| 22 | 200541005H | CABLE SET FOR EH760 HT2276E |
| 23 | 6415011110 | SPRING X EH760 HT2276E |
| 24 | 6415011120 | SPRING X EH760 HT2276E |
| 25 | 6415011130 | SCREW FOR EH760 HT2276E |
| 26 | 6415011140 | NUT X EH760 HT2276E |
| 27 | 6415011150 | SCREW FOR EH760 HT2276E |
| 28 | 6415011160 | NUT X EH760 HT2276E |
| 29 | 6415011210 | CLOSING SCREW X EH760 HT2276E |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
