Makita Cordless Chain Saw BUC121 Parts
€17.65
Tax included
Makita Spare parts for Cordless Chain Saw BUC121
Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chain Saw BUC121.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare parts for Cordless Chain Saw BUC121
Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chain Saw BUC121.
In the following table, look for the model of the Cordless Chain Saw and the respective parts of the code.
| MAKITA BUC121 CORDLESS CHAIN SAW 115MM PARTS | ||
| # | Part Num. | Description |
| 1 | 158472-4 | KNOB 60 COMPLETE |
| C10 | 816905-2 | INDICATION LABEL |
| 2 | 267004-7 | FLAT WASHER 6 |
| 3 | 158471-6 | SPROCKET COVER COMPLETE |
| 4 | 961014-3 | STOP RING E-8 |
| 5 | 221527-9 | SPROCKET 9 |
| 6 | 267732-4 | LOCK WASHER 12 |
| 7 | 232238-1 | LEAF SPRING |
| 8 | 265995-6 | TAPPING SCREW 4X18 |
| 9 | 265995-6 | TAPPING SCREW 4X18 |
| 10 | 450213-7 | BEARING HOUSING |
| 10-1 | 450213-7 | BEARING HOUSING |
| 11 | 323806-2 | SPINDLE |
| 12 | 211051-0 | BALL BEARING 609LLB |
| 13 | 226673-3 | HELICAL GEAR 50 |
| 14 | 450436-7 | CAM |
| 15 | 210033-9 | BALL BEARING 696ZZ |
| 16 | 450435-9 | CRANK |
| 17 | 213993-4 | O-RING 1.5 |
| 18 | 158571-2 | OIL PUMP COMPLETE |
| 19 | 421615-4 | CONNECTOR |
| 20-1 | 158810-0 | TANK CAP COMPLETE |
| 22 | 158634-4 | OIL TANK COMPLETE |
| 23A | 188474-6 | HANDLE SET |
| D10 | INC. 40 | |
| 23-1A | 187238-5 | HANDLE SET |
| D10 | INC. 40 | |
| 23-1C | 187238-5 | HANDLE SET |
| D10 | INC. 40 | |
| 23-2 | 187238-5 | HANDLE SET |
| D10 | INC. 40 | |
| 24 | 231470-4 | COMPRESSION SPRING 6 |
| 25 | 416178-3 | LOCK-OFF BUTTON |
| 26 | 651938-8 | SWITCH TG72B |
| 27 | 450212-9 | SWITCH LEVER |
| 28A | 643811-6 | TERMINAL |
| 28-1A | 643867-9 | TERMINAL |
| 28-1C | 643867-9 | TERMINAL |
| 29 | 257264-9 | RING 30 |
| 29-1 | 257363-7 | RING 30 |
| 30 | 265995-6 | TAPPING SCREW 4X18 |
| 31 | 619223-5 | ARMATURE |
| 32 | 638138-7 | YOKE UNIT |
| 33 | 638608-6 | ENDBELL COMPLETE |
| 34 | 188468-1 | MOTOR HOUSING SET |
| D10 | INC. 36 | |
| 35 | 864640-6 | BUC121 NAME PLATE |
| 36 | 188468-1 | MOTOR HOUSING SET |
| D10 | INC. 34 | |
| 37 | 266050-7 | TAPPING SCREW 4X30 |
| 38 | 191971-3 | CARBON BRUSH CB-430 |
| 39 | 643954-4 | BRUSH HOLDER CAP |
| 40A | 188474-6 | HANDLE SET |
| D10 | INC. 23 | |
| 40-1A | 187238-5 | HANDLE SET |
| D10 | INC. 23 | |
| 40-1C | 187238-5 | HANDLE SET |
| D10 | INC. 23 | |
| 40-2 | 187238-5 | HANDLE SET |
| D10 | INC. 23 | |
| 41 | 265995-6 | TAPPING SCREW 4X18 |
| 42 | 158620-5 | FRONT HAND GUARD COMPLETE |
| C10 | 810377-3 | CAUTION LABEL |
| 43 | 266050-7 | TAPPING SCREW 4X30 |
| 44 | 450217-9 | FRONT HANDLE |
| 45 | 266050-7 | TAPPING SCREW 4X30 |
| 46 | 265995-6 | TAPPING SCREW 4X18 |
| 47 | 259041-5 | PUSH NUT 8 |
| 48 | 443125-1 | FILTER |
| A01 | 158476-6 | GUIDE BAR COMPLETE |
| C10 | 168450-6 | GUIDE BAR |
| A02 | 416311-7 | GUIDE BAR CASE |
| A03 | 182229-1 | OIL SUPPLY 100CC |
| A04 | 744003-1 | FILE 4 |
| A05A | 791284-8 | CHAIN BLADE |
| A05-3C | 194065-3 | BATTERY BL1430 SET |
| A05-4C | 194065-3 | BATTERY BL1430 SET |
| A06C | 450128-8 | BATTERY COVER |
| A07-1C | ***DC18RC | DC18RC FAST CHARGER |
| A08-1C | 141494-1 | PLASTIC CARRYING CASE |
| C10 | 163455-1 | LATCH |
| C20 | 419360-3 | HANDLE |
| A09C | 806575-5 | BUC121RFE PLASTIC CASE LABEL |
| A10C | 791284-8 | CHAIN BLADE |
| E01 | 620098-7 | CONTROLLER |
| E01-1 | 620265-4 | CONTROLLER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
