Makita Spare Parts for Brusch Cutter EM4350LH
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Brusch Cutter EM4350LH.
In the following table, look for the model of Brusch Cutter and the respective parts of the code.
| Petrol Brushcutter EM4350LH 43CC 4T MAKITA pag.1 | ||
| # | Part Num. | Description |
| 1 | 961057-5 | RETAINING RING S17 |
| 2 | 922331-6 | CAP HD SCREW M6X20 HM1800/181 |
| 3 | 318421-5 | CLUTCH case EBH341U |
| 4 | 451157-4 | SPACER EBH341U |
| 5 | 210138-5 | BALL BEARING 6003LLU |
| 6 | 962153-2 | RETAINING RING R-35 HP1631/41 |
| 7 | 168742-3 | CLUTCH DRUM X EM4350UH |
| 10 | 961151-3 | RETAINING RING S-32 EBH341U |
| 11 | 424204-4 | DAMPER EBH341U |
| 12 | 318453-2 | PIPE RETAINER EBH341U |
| 13 | 922231-0 | HEX. SOCKET HEAD BOLT M5X20 |
| 14 | 318454-0 | PIPE BRACKET EBH341U |
| 15 | 922331-6 | CAP HD SCREW M6X20 HM1800/181 |
| 16 | 922201-9 | HEX. SOCKET HEAD BOLT M5X8 |
| 17 | 443146-3 | FELT RING 8 EBH341U |
| 18 | 195251-9 | LOOP HANDLE SET MS335.4C |
| 19 | 911253-5 | PA HD SCREW M 5 X 30 W/CP WASHER JR3030T |
| 20 | 451596-8 | LOOP HANDLE 28 MS335.4C |
| 21 | 451597-6 | HANDLE CLAMP 28 MS335.4C |
| 22 | 451600-3 | SPACER 28 MS335.4C |
| 44 | 140042-3 | SHAFT PIPE COMP EBH341U |
| 45 | 325675-7 | SHAFT EBH341U |
| 46 | 413143-3 | WASHER MS335.4C |
| 47 | 452259-9 | PROTECTOR EBH341U |
| 48 | 266326-2 | TAPPING SCREW M4X18 EBH253/EB3 MT601 |
| 49 | 347050-7 | CUTTER |
| 50 | 135753-3 | PROTECTOR EXTENSION ASSY EM251 |
| 51 | 346072-4 | PROTECTOR CLAMP EBH341U |
| 52 | 451090-0 | PROTECTOR COVEREBH341U |
| 53 | 266280-0 | HEX SOCKET HD BOLT M6X25 |
| 54 | 266865-2 | H.S.H.Bolt M5X14 With Wr Em4350/4351Uh |
| 55 | 123835-3 | Gear Case Assy Ebh341U |
| 56 | 213459-4 | O Ring 32 Da4031/4157Kb/5903R 2400B HR3850B |
| 57 | 183K07-8 | Cutter Shaft set |
| 58 | 210059-1 | BALL BEARING 6000 HR2010 |
| 59 | 211062-5 | BALL BEARING 6000 X9524NB |
| 60 | 961006-2 | RETAINING RING S10 |
| 61 | 962105-3 | RETAINING RING R26 |
| 62 | 922353-6 | Cap Hd Screw M6X30 W. Captive Washers HM1202C |
| 63 | 265590-2 | Hex Bolt M8X10 Ebh253L/Ebh341U EBH341U |
| 64 | 210081-8 | BALL BEARING 629ZZ EBH341U |
| 65 | 453883-1 | Clutch Case Cover Em4350Uh EM435 |
| 66 | 125558-9 | Hanger Assy EBH341U |
| 67 | 266698-5 | Hex. Socket Head Bolt M5X20 |
| 68 | 210116-5 | BALL BEARING 6201LLU EBH341U |
| 69 | 962151-6 | RETAINING RING R32 |
| 70 | 332114-0 | Recieve Washer Ebh341U EM4350RH |
| 71 | 346355-2 | Clamp Washer |
| 72 | 168526-9 | Cup Ebh253L/Ebh341U |
| 73 | 264025-0 | NUT M10-17 EBH341U |
| Petrol Brushcutter EM4350LH 43CC 4T MAKITA pag.2 | ||
| 23 | 126164-3 | CONTROL LEVER ASSY EM4350LH |
| 24 | 266130-9 | SCREW 3X16 X 6203/13 / 6313DW |
| 25 | 451595-0 | SWITCH COVER MS335.4C |
| 26 | 451594-2 | SWITCH LEVER MS335.4C |
| 27 | 232251-9 | LEAF SPRING EBH341U |
| 28 | 187574-9 | LEVER CASE SET EM4350LH |
| 29 | 346249-1 | PIPE CLAMP 28 MS335.4C |
| 30 | 922218-2 | H.S.H.BOLT M5X14 WITH WR EBH341U |
| 31 | 451593-4 | LOCK LEVER MS335.4C |
| 32 | 233541-3 | TORSION SPRING 7 EBH341U |
| 33 | 168741-5 | CONTROL CABLE X EM4350LH |
| 34 | 233540-5 | TORSION SPRING 11 EBH341U |
| 35 | 451592-6 | THROTTLE LEVER MS335.4C |
| 36 | 638985-6 | WIRE EM4350LH |
| 37 | 638986-4 | WIRE EM4350LH |
| 38 | 453708-9 | HOSE EM4350LH |
| 39 | 266326-2 | TAPPING SCREW 4X18 MT601 |
| 41 | 325907-2 | LOCK PIN X EM4350LH |
| Petrol Brushcutter EM4350LH 43CC 4T MAKITA pag.3 | ||
| 101 | 922233-6 | HEX SOCKET HEAD BOLT M5X20 DCS230T |
| 102 | 424302-4 | PLUG CAP EH7500S |
| 103 | 455103-9 | CYLINER COVER BLUE EM4350/4351 - See the CT22-2 |
| 104 | 922233-6 | HEX SOCKET HEAD BOLT M5X20 DCS230T |
| 105 | 453536-2 | MUFFLER COVER X EM4351UH |
| 106 | 265995-6 | TAPPING SCREW 4X18 |
| 107 | 922332-4 | H S HD BOLT M6X20/1219&L SC161 |
| 108 | 168715-6 | MUFFLER X EM4351UH |
| 109 | 346574-0 | MUFFLER GASKET EM4351UH |
| 110 | 331987-8 | SPACER X EM4351UH |
| 111 | 922226-3 | HEX SOCKET HD BOLT M5X18 EBH2 4341FCT |
| 112 | 318850-2 | ROCKER COVER OUTER EM4350/435 EM4351UH |
| 113 | 422091-5 | TUBE 5-160 EM4351UH |
| 114 | 454424-6 | CORRUGATE TUBE EM4350/4351 EM4351UH |
| 115 | 453529-9 | ROCKER COVER INNER EM4350/435 EM4351UH |
| 116 | 162335-8 | ROCKER COVER GASKET EM4350/43 EM4351UH |
| 117 | 324891-8 | PLUG CAP SPRING ER2650LH/BHX2 EBH341 |
| 118 | 650109950 | SPARK PLUG CMR6A X MS251.A |
| 119 | 422090-7 | TUBE 3-85 X EM4351UH |
| 120 | 452049-0 | SPACER EM2651/ER2650/EN4951 EX2650LH |
| 121 | 135659-5 | CYLINDER X EM4351UH - SEE the CT25-2 |
| 122 | 424200-2 | SPACER EBH341U |
| 123 | 424201-0 | CHECK VALVE ER2650LH/EBH251L EBH341U |
| 124 | 922342-1 | CAP HD SCREW M6X25 CS246.4 EX2650LH |
| 125 | 422099-9 | PIPE ER2650LH/EY2650H/EN4951S EX2650LH |
| 126 | 282020-8 | HOSE CLAMP ER26/EM26/EA3601 EBH341U |
| 127 | 424301-6 | OIL TUBE EX2650LH |
| 128 | 325666-8 | OIL WEIGHT ER2650LH/EBH253L EBH341U |
| 129 | 162337-4 | OIL CASE GASKET EM4350/4351 EM4351U |
| 130 | 266760-6 | SOCKET HEAD BOLT M5X45 |
| 131 | 452047-4 | OIL CAP ER2650/EM2651/EN4951 BHX2501 |
| 132 | 424343-0 | GASKET ER2650LH/EM2651LH/BHX2 BHX2501 |
| 133 | 453538-8 | OIL PIPE EM4350/4351 EM4351UH |
| 134 | 162338-2 | OIL PIPE GASKET EM4350/4351 EM4351UH |
| 135 | 318854-4 | OIL CASE EM4350/4351 EM4351UH |
| 136 | 922226-3 | HEX SOCKET HD BOLT M5X18 EBH2 - 4341FCT |
| 137 | 346305-7 | GASKET EX2650LH |
| 138 | 266611-3 | HEX BOLT M6X8 EM2651LH/ER2650 EX2650LH |
| 139 | 346398-4 | LEAD BULB EK7650H EB5300TH EM4351UH |
| 140 | 318851-0 | RETAINER PLATE EM4350/4351 EM4351UH |
| 141 | 922226-3 | HEX SOCKET HD BOLT M5X18 EBH2 4341FCT |
| 142 | 325665-0 | JOINT PIPE ER2650LH/EM2651LH EX2650LH |
| 143 | 168724-5 | TUBE COMP EM4350/4351UH EM4351UH |
| 144 | 454426-2 | SPIRAL TUBE 6-80 EM4350/4351 EM4351UH |
| 145 | 163518-3 | FUEL FILTER EX2650LH |
| 146 | 282020-8 | HOSE CLAMP EBH341U |
| 150 | 126119-8 | STARTER COMP EM4350/4351UH EM4351UH |
| 151 | SG00000013 | SCREW M6x20 |
| 152 | 452288-2 | STARTER REEL EM4351UH |
| 153 | SG00000014 | STARTER SPRING EM4351UH |
| 154 | 424361-8 | STARTER KNOB EM4351UH |
| 155 | 424360-0 | ROPE STOPPER EM4351UH |
| 156 | 444027-4 | STARTER ROPE EM4351UH |
| 157 | 453534-6 | STARTER COMP EM4350/4351UH EM4351UH |
| 158 | 922233-6 | HEX SOCKET HD BOLT M5X20 EM43 DCS230T |
| 160 | 126116-4 | ROCKER ARM EM4350/4351UH EM4351UH |
| 161 | 331990-9 | COTTER EM4350/4351UH EM4351UH |
| 162 | 331991-7 | RETAINER EM4350/4351UH EM4351UH |
| 163 | 234238-7 | COMPRESSION SPRING 11 |
| 164 | 256200-2 | PIN 5 FOR 2704 |
| 165 | 256866-8 | PIN 2.5 EBH341U |
| 166 | 268238-5 | PIN 5 EBH341U |
| 167 | 313236-5 | CAM LIFTER EM4350/4351 EM4351UH |
| 168 | 256186-0 | PIN 5 MS43 ** / EM43 ** |
| 169 | 126571-0 | CAM GEAR |
| 170 | 261127-3 | TEFLON WASHER 10 X PW5000CH |
| 171 | 326575-4 | EXHAUST VALVE X EM4351UH - SEE CT25-2 |
| 172 | 326157-2 | INTAKE VALVE EM4351UH |
| 173 | 196667-1 | PISTON RINGS |
| 174 | 233983-1 | CIRCLIP EBH341 |
| 175 | 197455-9 | PISTON SET |
| 176 | 268285-6 | PISTON PIN EM4351UH |
| 177 | 213685-5 | OIL SEAL 12 X EM4351UH |
| 178 | 126121-1 | CRANKSHAFT X EM4351UH |
| 179 | 254040-2 | WOODRUFF KEY 3 EBH341U |
| 180 | 267425-3 | FLAT WASHER 26 EBH341U |
| 181 | 213537-0 | OIL SEAL 12 EBH341U |
| 182 | 266086-6 | HEX BOLT M5X16 JR3020/DA4031 JR3020 |
| 183 | 318856-0 | CAM GEAR COVER EM4350/4351 EM4351UH |
| 184 | 162334-0 | CAM GEAR GASKET EM4350/4351 EM4351UH |
| 185 | 638974-1 | LEAD UNIT EM4350/4351 EM4351UH |
| 186 | 638975-9 | LEAD UNIT EM4350/4351 EM4351UH |
| 187 | 444021-6 | TUBE EX2650LH |
| 188 | 168714-8 | IGNITION COIL EM4351UH |
| 189 | 266602-4 | HEX SOCKET HD BOLT M4X20 EX2650LH |
| 190 | 126122-9 | FLYWHEEL X EM4351UH |
| 191 | 264039-9 | FLANGED NUT EX2650LH |
| 192 | 127112-5 | FUEL TANK CAP |
| 195 | 424081-4 | BUFFER RUBBER DBC260U |
| 198 | 922233-6 | HEX SOCKET HD BOLT M5X20 EM43 DCS230T |
| 199 | 261152-4 | RUBBER WASHER 8 EM4350/4351 |
| 200 | 331988-6 | SPACER EM4351UH |
| 201 | 168875-4 | FUEL TANK EM4351UH |
| 202 | 922332-4 | H S HD BOLT M6X20/1219&L SC161 |
| 203 | 318852-8 | ENGINE BASE EM4350/4351 EM4351UH |
| 204 | 266597-1 | SHOULDER HEX. BOLT M8 |
| 205 | 267832-0 | WAVE WASHER 10 EBH341U |
| 206 | 313238-1 | CLUTCH SHOE EM4350/4351 EM4351UH |
| 207 | 232290-9 | TENSION SPRING 5 EM4351UH |
| 208 | 267428-7 | FLAT WASHER 8 EM4350/4351UH |
| 209 | 313239-9 | CLUTCH BASE EM4350/4351 EM4351UH |
| 210 | 346576-6 | FAN PLATE EM4350/4351 EM4351UH |
| 211 | 266461-6 | H.S.BUTTON HEAD SCREW M5X8 AT450H |
| 212 | 453530-4 | MUFFLER PLATE EM4350/4351 EM4351UH |
| 213 | 922233-6 | HEX SOCKET HD BOLT M5X20 EM43 DCS230T |
| 214 | 345918-1 | HOSE CLAMP ER2550/2650/EM2511 EBH341U |
| 300 | 455102-1 | PLATE - SEE CT22-2 |
| 301 | 266385-6 | SCREW 4X14 FOR GA9020 - SEE CT22-2 |
| Petrol Brushcutter EM4350LH 43CC 4T MAKITA pag.4 | ||
| 215 | 126523-1 | CLEANER COVER ASSEMBLY EM4350RH P13 - See the CT22-2 |
| 216 | 266743-6 | HEX.SOCKET HEAD BOLT M5X20 - SEE CT31-2 |
| 218 | 442181-8 | AIR CLEANER ELEMENT EM4351UH |
| 219 | 266601-6 | HEX. SOCKET HEAD BOLT M5X60 |
| 220 | 443196-8 | AIR CLEANER ELEMENT EM4350RH - SEE CT31-2 |
| 221 | 123994-3 | FILTER PLATE - Look at the CT31-2 |
| 222 | 162346-3 | SEPARATOR PLATE ER2650/EN4951 EX2650LH |
| 223 | 352020-3 | SEPARATOR MESH ER2650/EN4951 EX2650LH |
| 224 | 266007-8 | PT SCREW 3X10 TRILOBULAR/MS248 HP2030 |
| 225 | 453865-3 | SEPARATOR CASE ER2650/EN4951 EX2650LH |
| 226 | 424316-3 | CHECK VALVE ER2550/EBH251L EBH341U |
| 227 | 454425-4 | SPIRAL TUBE 6-100 EM4350/4351 EM4351UH |
| 228 | 422074-5 | TUBE 3-120 EK7650H EM4351UH |
| 229 | 168398-2 | PRIMER PUMP DCS230T/EA32/EA36 DCS230T |
| 230 | 442196-5 | CARBURETOR GASKET EM4351P01 |
| 231 | 123301-0 | CARBURETOR X EM4351UH |
| 232 | 345963-6 | CLAMP ER2550/EBH253L/EBH341U |
| 233 | 266388-0 | TAPPING SCREW 5X16 UC4020A/35 UC3020A |
| 234 | 442197-3 | CARBURETOR GASKET EM4351P01 |
| 235 | 922233-6 | HEX SOCKET HD BOLT M5X20 EM43 DCS230T |
| 236 | 424489-2 | GROMMET EM4350/4351 EM4351UH |
| 237 | 422080-0 | TUBE 3-35 X EM4351UH |
| 238 | 142736-6 | INSULATOR PLATE - SEE CT22-2 |
| 239 | 213642-3 | O RING 18 EM4350/4351 EM4351UH |
| 242 | 451825-9 | CLAMP ER2650/EM2651/EN4951 EX2650LH |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
