Makita Spare Parts for Lawn Mower ELM4120
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Lawn Mower ELM4120.In the following table, look for the model of Lawn Mower and the respective parts of the code.
| ELM4120 410MM ELECTRIC LAWN MOWER Spare Parts pag.1 | ||
| # | Part Num. | Description |
| 1 | YA00001157 | UPPER HANDLE BAR ASSY |
| 2 | YA00001182 | SPONGE GRIP |
| 3 | YA00001158 | SWITCH LEVER |
| 4 | YA00000765 | SWITCH BOX RIGHT |
| 5 | YA00000766 | SWITCH LINK BUTTON |
| 6 | YA00000767 | COMPRESSION SPRING 16.8 |
| 7 | YA00000768 | SWITCH LEVER END CAP RIGHT |
| 8 | 652024721 | SELF DRILLING SCREW 3.5X10 |
| 9 | YA00000769 | SWITCH TORSION SPRING 21 |
| 10 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 11 | YA00000780 | CORD CLAMP |
| 12 | YA00000914 | POWER SUPPLY CORD ASSY |
| 13 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 14 | YA00000780 | CORD CLAMP |
| 15 | YA00000773 | POWER SUPPLY CORD ASSY (EURO) |
| 16 | YA00000781 | INDICATOR LENZ |
| 17 | YA00000772 | SWITCH |
| 18 | 652023811 | CABLE HANGER |
| 19 | YA00000782 | SWITCH BOX LEFT |
| 20 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 21 | 652023795 | SPRING BOX RIGHT |
| 22 | 652024721 | SELF DRILLING SCREW 3.5X10 |
| 23 | 652023794 | SWITCH LEVER END LEFT |
| 24 | YA00000737 | TORSION SPRING |
| 25 | 652023793 | SPRING BOX LEFT |
| 26 | YA00000778 | SELF TAPPING SCREW ST4X16 |
| 27 | YA00000785 | SELF TAPPING SCREW ST4X25 |
| 28 | YA00000921 | CABLE CLIP |
| 29 | YA00000923 | TENSI0N LEVER ASSY |
| 30 | YA00000922 | LOWER HANDLE |
| 31 | YA00000802 | HEX.FRANGE CAP NUT M6 |
| 32 | YA00000803 | M8 KNOB |
| 33 | YA00000420 | WASHER |
| 34 | YA00000924 | ANGLE ADJUSTMENT JOINT UPPER |
| 35 | YA00000806 | SELF TAPPING SCREW ST5X20 |
| 36 | YA00000875 | ANGLE ADJUSTMENT JOINT LOWER R |
| 37 | YA00000807 | HEX BOLT M8X65 |
| 38 | YA00000876 | ANGLE ADJUSTMENT JOINT LOWER L |
| 40 | YA00000939 | REAR FLAP BULE |
| 41 | YA00000938 | REAR FLAP HINGE ROD |
| 42 | YA00000831 | REAR FLAP TORSION SPRING 7.7 |
| 43 | YA00000821 | SELF TAPPING SCREW ST4X16 |
| 44 | YA00000941 | TOP COVER |
| 45 | YA00000848 | HIGHT ADJUST GRIP |
| 46 | YA00000849 | PAN HEAD SCREW M4X10 |
| 47 | YA00000398 | SUNK SCREW 5*14 |
| 48 | YA00000942 | HEIGHT ADJUSTER STOP PLATE |
| 49 | YA00000943 | STOP PLATE RUBBER SHEET |
| 50 | YA00000837 | NYLON INSERT HEX LOCK NUT M5 |
| 51 | YA00000944 | HOUSING ASSY BULE |
| 52 | YA00000946 | SPONGE CUSHION |
| 53 | YA00000948 | SPONGE CUSHION |
| 54 | YA00000947 | SPONGE CUSHION |
| 55 | YA00000821 | SELF TAPPING SCREW ST4X16 |
| 56 | YA00000821 | SELF TAPPING SCREW ST4X16 |
| 57 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| ELM4120 410MM ELECTRIC LAWN MOWER Spare Parts pag.2 | ||
| 58 | YA00001176 | MOTOR ASSY (230V) |
| 59 | YA00000813 | SELF TAPPING SCREW ST4X10 |
| 60 | YA00000814 | CARBON BRUSH 2PICS SET |
| 61 | YA00001174 | CABLE TIE |
| 62 | YA00001173 | HEAT SHRINKABLE TUBE |
| 63 | YA00001181 | LEAD WIRE SET |
| 64 | YA00001178 | MOTOR FLAME & PULLEY ASSY |
| 65 | YA00000806 | SELF TAPPING SCREW ST5X20 |
| 66 | YA00001180 | BELT |
| 67 | YA00000806 | SELF TAPPING SCREW ST5X20 |
| 68 | YA00001179 | BELT COVER |
| 69 | YA00000806 | SELF TAPPING SCREW ST5X20 |
| 70 | YA00000821 | SELF TAPPING SCREW ST4X16 |
| 71 | YA00000780 | CORD CLAMP |
| 72 | YA00000930 | DECK |
| 73 | YA00000931 | SPONGE CUSHION |
| 74 | YA00000883 | SPONGE CUSHION |
| 75 | YA00000885 | SPONGE CUSHION |
| 76 | YA00000806 | SELF TAPPING SCREW ST5X20 |
| 77 | YA00000932 | GRASS INTAKE UNDER PLATE |
| 78 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 79 | YA00000933 | UNDER BRACE RIGHT |
| 80 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 81 | YA00000934 | AIR INTAKE BOARD RIGHT |
| 82 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 83 | YA00000950 | UNDER BRACE LEFT |
| 84 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 85 | YA00000951 | AIR INTAKE BOARD LEFT |
| 86 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 87 | YA00000910 | SPEASER RING 16 |
| 88 | YA00000935 | BLADE SUPPORT |
| 89 | YA00000747 | BLADE 41 |
| 90 | YA00000891 | CLAMP WASHER 8 |
| 91 | YA00000827 | HEX. BOLT M8X25 |
| ELM4120 410MM ELECTRIC LAWN MOWER Spare Parts pag.3 | ||
| 92 | YA00000925 | WHEEL CAP 7INCH |
| 93 | 652023843 | NYLON INSERT HEX. LOCK NUT M8 |
| 94 | YA00000420 | WASHER |
| 95 | YA00000926 | WHEEL 8INCH |
| 96 | YA00000927 | REAR AXLE |
| 97 | YA00000811 | AXLE RETAINER |
| 98 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 99 | YA00000843 | STEPPED HEX BOLT M6X16 |
| 100 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 101 | YA00000845 | WASHER 5 |
| 102 | YA00000903 | TENSION SPRING 11 |
| 103 | YA00000627 | SELF-LOCKING NUTS M6 |
| 104 | YA00000949 | CONNECTING ROD |
| 105 | YA00000906 | HIGHT ADJUST LEVER |
| 106 | YA00000907 | TORSION SPRING 8 |
| 107 | YA00000851 | RPIN7 |
| 108 | YA00000952 | WHEEL CAP 5INCH |
| 109 | 652023843 | NYLON INSERT HEX. LOCK NUT M8 |
| 110 | YA00000420 | WASHER |
| 111 | YA00000953 | WHEEL 6INCH |
| 112 | YA00000954 | FRONT AXLE |
| 113 | YA00000909 | AXLE RETAINER WASHER |
| 114 | YA00000820 | SELF TAPPING SCREW ST5X16 |
| 115 | YA00000627 | SELF-LOCKING NUTS M6 |
| 116 | YA00000843 | STEPPED HEX BOLT M6X16 |
| 117 | YA00000915 | GRASS BOX ASSY(MAKITA) |
| 118 | YA00000917 | GRASS CATCH SIDE CLOSS SET MAK |
| 119 | YA00000791 | GRASS CATCHER INDICATOR BLUE |
| 120 | YA00000919 | GRASS CATCHER UPPER BORAD |
| 121 | YA00000795 | GRIP |
| 122 | YA00000794 | SELF TAPPING SCREW ST4X14 |
| 123 | YA00000920 | GRASS CATCHER FRAME |
| 124 | YA00000796 | WASHER 4 |
| 125 | YA00000794 | SELF TAPPING SCREW ST4X14 |
| 126 | YA00000798 | SPANNER 10-13 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
