Makita Spare Parts for Chainsaw DCS5200I
€356.63
Tax included
Makita Spare Parts for Chainsaw DCS5200I
MAKITA service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw DCS5200I.These are an authentic replacement parts sourced from the manufacturer.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Chainsaw DCS5200I
MAKITA service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw DCS5200I.
These are an authentic replacement parts sourced from the manufacturer.
In the following table, look for the model of Chainsaw and the respective parts of the code.
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.1 | ||
| # | Part Num. | Description |
| 1B | 027130034 | PISTON + CYLINDER CPL X 111/115 |
| 2B | 027132050 | PISTON DIAMETER 44MM |
| 3B | 027132020 | PISTON RING DIAM. 44MM |
| 4A | 027132030 | PISTON PIN |
| 4B | 001132010 | PIN X DCS430 |
| 5 | 020132050 | SPRING RING C10X0,8 430/4300I |
| 6 | 266476-3 | TORX HEAD SCREW M5X20 DCS4630 |
| 7 | 965525042 | GASKET OR32X4,5 |
| 10 | 001142012 | CLAMP |
| 11 | 965401011 | RUBBER BUSHING |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.2 | ||
| 1B | 027111680 | CRANKCASE CLUTCH SIDE |
| 1C | 020111660 | CRANKCASE CLUTCH SIDE |
| 2B | 027111640 | CRANKCASE X DCS430 |
| 3B | 027120010 | CRANKSHAFT ASS'Y |
| 4A | 211154-0 | BALL BEARING 6202 |
| 4B | 960102131 | BALL BEARING 6201 |
| 5 | 939620371 | KEY 2.0X3.7 |
| 6 | 962211030 | NEEDLE CAGE |
| 7 | 213814-0 | RADIAL RING 15 / 24X7 |
| 8 | 213141-5 | RADIAL RING 15 / 24X7 |
| 9 | 258038-1 | SPRING PIN |
| 10 | 965525002 | GASKET OR32X4,5 |
| 11 | 027213320 | LEAF SPRING |
| 12A | 027213230 | BOLT |
| 12B | 934950160 | CLAMPING SLEEVE 5 X 16 X DCS430 |
| 14 | 027213520 | HEX HEAD SCREW DCS430/520/4300 |
| 15 | 027213270 | SPRING |
| 16 | 027213510 | RING |
| 17 | 027213500 | SHOULDER NUT DCS430/520/4300I/ |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.3 | ||
| 11 | 266945-4 | SCREW M5X30 (TORX) |
| 12 | 908105204 | SCREW M5X20 (TORX) |
| 13 | 001111012 | SCREW M12X1 |
| 15 | 905808305 | GUDGEON M8X30 430/520/4300I/52 |
| 16 | 389213081 | TENSION SCREW |
| 17 | 001213020 | NUT WITH PIVOT |
| 22 | 020111082 | CHAIN CATCH 430/520/4300I/5200 |
| 23 | 266946-2 | SCREW M5X12 (TORX) |
| 24 | 020111172 | GUIDE PLATE |
| 25 | 915135100 | SCREW 3.5 X 9.5 |
| 26 | 020250020 | SPIKE BAR OUTSIDE,DCS |
| 27 | 266474-7 | SCREW M5X8 (TORX) |
| 28 | 020173011 | PRE FILTER |
| 29 | 020173612 | PREFILTER COVER, DCS4 |
| 30 | 266947-0 | TORX Socket Head Bolt M5x14 |
| 32 | 957605112 | INTERR. SHORT CIRCUIT. COMPL. |
| 33 | 980115888 | LABEL ON - OFF |
| 34 | 965401011 | RUBBER BUSHING |
| 35 | 010114032 | OIL TANK CAP ASS'Y |
| 36 | 963100051 | GASKET OR32X4,5 |
| 37 | 010245010 | AIR VENT VALVE X PS6000I-6800I |
| 38 | 921905004 | NUT |
| 39 | 020111070 | CLAMP DCS430/520/4300I/5200I |
| 40 | 020173061 | SNOW FILTER |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.4 | ||
| 1 | 957310027 | TUBULAR HANDLE ASSY DCS430/431 |
| 3 | 965403491 | RUBBER BUFFER |
| 4 | 021114051 | FIXING BUSH DCS430/431/4300I/5 |
| 5 | 266945-4 | FILLISTER (TORX) SCREW M5X30 D |
| 8 | 020310600 | COVER |
| 9 | 266478-9 | SCREW 5,5X16 (TORX) |
| 15 | 020114640 | TANK ASSY DCS430/520/4300I/520 |
| 16 | 965451901 | SCREW PLUG CPL PS9010 |
| 17 | 963232045 | PACKING RING 32X4,5 DCS430/520/4300I |
| 18 | 163532-9 | SUCTION HEAD DPC6410/7311/811 |
| 19 | 963601240 | FELT |
| 20 | 957114011 | TANK VENT VALVE |
| 21 | 965404460 | FUEL LINE |
| 22 | 965404521 | GASKET OR32X4,5 |
| 23 | 020117291 | THROTTLE LEVER & LINKAGE DCS43 |
| 24 | 020117273 | SPRING DCS430/520/4300I/5200I |
| 25 | 020117301 | CATCH LEVER DCS430/520/4300I |
| 26 | 020117160 | SPRING DCS430/520/4300I/5200I |
| 27 | 935932320 | CYLINDRICAL PIN DCS430/520/430 |
| 29 | 965403282 | RUBBER BUFFER |
| 30 | 913447134 | SELF-CUTTING SCREW 4,7X13 DCS4 |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.5 | ||
| 1 | 026160640 | STARTER ASSY DCS430/520/4300I/ |
| 2 | 020112631 | FAN HOUSING CPL DCS430/520/43 |
| 3 | 965402262 | STARTER HANDLE X DCS9000 |
| 4 | 108164020 | STARTER ROPE 3,5X980MM |
| 5 | 266605-8 | SCREW M5X16 PS32CTLC |
| 6 | 020163031 | REWIND SPRING IN HOU DCS430 |
| 7 | 915135100 | SCREW 3.5 X 9.5 |
| 8 | 027162070 | CABLE DRUM |
| 9 | 924108410 | WASHER 8.4 |
| 10 | 929108080 | SAFETY DISC 8X0,8 DCS430/520/4 |
| 11 | 020112010 | AIR DUCT DCS430/520/4300I/5200 |
| 13 | 168648-5 | SPARK PLUG NGK BPMR7A RBC350-RBC420-PB500R |
| 14 | 957604260 | PLUG CAP ASSY, DPC733 |
| 15 | 965604180 | SPRING |
| 17 | 027140001 | IGNITION ASS Y, DCS52 |
| 18 | 027141021 | FLYWHEEL ASSEMBLY |
| 19 | 181166050 | STARTER RATCHET ASS'Y |
| 20A | 122166020 | TORSION SPRING, DOLMAR, DCS52 |
| 20B | 108166021 | SPRING |
| 21 | 264022-6 | HEX NUT |
| 22 | 926208001 | SPRING WASHER 8 |
| 23 | 020143032 | IGNITION COIL (DUCATI) |
| 24 | 266607-4 | SCREW M5X20 PS32CTLC |
| 25 | 001147000 | SHORT CIRCUIT CABLE |
| 26 | 970310200 | IGNITION CABLE 1mt |
| 27 | 444042-8 | ISOLATING TUBE 6-80 PS32TCLC |
| 28 | 970502050 | INSULATING HOSE (M) |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.6 | ||
| 1 | 027213452 | HAND GUARD |
| 2 | 027213462 | HAND GUARD |
| 3 | 810449-4 | LABEL |
| 4 | 027213430 | BUSHING SET, DCS431 |
| 5 | 027213150 | RUBBER BUSH, DCS431 |
| 6 | 027213161 | BUSH, DCS520I |
| 7 | 266476-3 | SCREW M5X20 (TORX) |
| 8 | 027213221 | DISENGAGING LEVER,DCS |
| 20 | 027213652 | CHAIN BRAKE ASSEMBLY (BRAKE) |
| 21 | 027213280 | PROTECTION COVER |
| 22 | 027213050 | SPRING W/LEVER,DCS431 |
| 23 | 027213352 | BRAKE BAND HOLDER, DC |
| 24 | 913205125 | APPING SCREW M5X12,D DCS430 |
| 25 | 027213111 | COVER PLATE |
| 26 | 257934-0 | STOP RING E-4 X UH6580 |
| 27 | 027111042 | GUIDE PLATE |
| 28 | 915135100 | SCREW 3.5 X 9.5 |
| 29 | 027213120 | SPRING |
| 30 | 027213560 | RUBBER PLATE, DCS5200 |
| 31 | 027213130 | SHAFT FOR BRAKE LEVER |
| 32 | 027213140 | SHAFT FOR BRAKE LEVER |
| 34 | 924500049 | WASHER 5,2X12X1 |
| 35 | 264055-1 | NUT M8 |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.7 | ||
| 1 | 027245161 | OIL PUMP CPL., DCS431 |
| 2 | 030245070 | OIL PUMP REPAIR KIT |
| 3 | 027245010 | PUMP DRIVE, DCS431 |
| 4 | 234366-8 | STOP RING 16X1 |
| 5 | 346872-2 | STOP RING |
| 6 | 020245020 | OIL PRESSURE LINE, DCS430 |
| 7 | 020245041 | OIL SUCTION LINE |
| 8 | 266946-2 | SCREW M5X12 (TORX) |
| 10 | 027223101 | CLUTCH DRUM |
| 11A | 020224070 | RIM SPROCKET .325" ,DC |
| 11B | 026224010 | RIM SPROCKET 3/8" |
| 12 | 962210025 | NEEDLE CAGE, DCS431 |
| 13 | 027245021 | STOP DISC, DCS520 |
| 18 | 962900040 | RADIAL RING 15 / 23X3 |
| 21 | 020223101 | CLUTCH DRUM |
| 22 | 020224120 | STOP DISC, DCS520 |
| 33 | 957180030 | CLUTCH ASSEMBLY 109-115 |
| 34 | 122184011 | CLUTCH SPRING |
| 35 | 027182030 | STOP DISC, DCS520 |
| 36 | 957180030 | CLUTCH ASSEMBLY 109-115 |
| 37 | 181184020 | TENSION SPRING |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.8 | ||
| 1 | 027118155 | HOOD, DOLMAR, DCS5200 |
| 2 | 266605-8 | SCREW M5X16 PS32CTLC |
| 3 | 020118121 | FILTER COVER |
| 4 | 001118062 | NUT M5,DCS340 |
| 5A | 020173202 | AIR FILTER ASSEMBLY (NYLON) |
| 5B | 020173300 | AIR FILTER ASSEMBLY |
| 6 | 266947-0 | TORX SCREW |
| 8 | 027118010 | BOTTOM WITH HOOD |
| 9 | 266474-7 | SCREW M5X8 (TORX) |
| 10 | 965401024 | RUBBER BUSH, DCS5200I |
| 11 | 965404780 | GASKET, DCS431 |
| 12 | 965525032 | GASKET, DCS5200I |
| 13 | 965404230 | PLUG, DCS431 |
| 14 | 965404410 | RUBBER BUSH, DCS431 |
| 15 | 965404341 | GASKET, DCS520I |
| 17 | 965524023 | GASKET, DCS430 |
| 18 | 020171100 | CONNECTING MUFF, DOOL |
| 19 | 908205658 | TORX BOLT 5X65, DCS43 |
| 21 | 020117281 | Throttle Linkage Assembly |
| 22 | 020118030 | GUIDE PIECE, DCS431 |
| 30 | 027150010 | CARBURETOR INJECTION HU 83C CPL. |
| 31 | 027150880 | CHOKE LEVER, DOLMAR, |
| 32 | 027150900 | CLAMP, DCS520I |
| 35 | 020174160 | MUFFLER |
| 36 | 346304-9 | MUFFLER GASKET PS32CTLC |
| 37 | 266474-7 | SCREW M5X8 (TORX) |
| 38 | 908205625 | SCREW M5X62 |
| 39 | 267821-5 | SPRING WASHER |
| 40 | 020174171 | HEAT SHIELD, DCS520 |
| 48 | 915042130 | SCREW, DCS520I |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.9 | ||
| 1A | 027150010 | CARBURETOR INJECTION HU 83C COM. |
| 6 | 957150080 | GASKET SET, HU-64 DCS520I |
| 7A | 100150150 | PUMP DIAPHRAGM |
| 9 | 957150310 | T. SPRING W/BUSH, DCS |
| 11 | 001150321 | THROTTLE SHUTTER,DCS5 |
| 13 | 100150350 | SAFETY WASHER, DCS600 |
| 16 | 001150170 | CHOKE NEEDLE, DCS520I |
| 23 | 020150470 | IDLE ADJ.SCREW, DCS52 |
| 25 | 001150480 | SPRING H,DCS520I |
| 27 | 957150150 | CTRL PARTS SET , DCS |
| DCS5200I 38 - 45 - CHAINSAW KW.2,6 52CC pag.10 | ||
| 1 | 445038631 | SPROCKET NOSE BAR 38CM TH.1.5MM |
| 1A | 443038651 | SPROCKET NOSE BAR 38CM TH.1.5MM |
| 2A | 528099056 | SAW CHAIN 38CM (15") Full CHISEL 70 - LINKS 56 3/8" |
| 1 | 445045631 | SPROCKET NOSE BAR 45CM SP.1,5MM |
| 1A | 445045651 | SPROCKET NOSE BAR 45CM SP.1,5MM |
| 2 | 528086772 | SAW CHAIN .325" .058" 45CM-18" SUPERGUARD 72L |
| 2A | 528099764 | SAW CHAIN 3/8" .058( 45CM-18" SUPER 70 L. 64 |
| 3 | 558083010 | TIE STRAP WITH RIVETS 0.325 " |
| 3A | 558093010 | TIE STRAP WITH RIVETS 3/8" |
| 4 | 510086040 | TIE STRAP 0.325 " |
| 4A | 558093000 | TIE STRAP 3/8" |
| 6B | 415325710 | SPROCKET 0.325 " |
| 7 | 952010640 | CHAIN COVER 40CM |
| 11 | 957004002 | TOOL SET DCS430 |
| 12 | 941719133 | UNIVERSAL WRENCH 19/13 |
| 13 | 782025-3 | TORX WRENCH |
| 14 | 783012-5 | CARBURETOR SCREWDRIVER |
| 15 | 950004001 | PLASTIC CASE |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
