Makita Spare Parts for Brusch Cutter RBC261

Name: Makita Spare Parts for Brusch Cutter RBC261
Brand: Makita
SKU: Makita RBC261
Price: 6.06 EUR
Availability: InStock

€6.06

Tax included

Makita Spare Parts for String Trimmer RBC261

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for STRING TRIMMER RBC261.

ITEM CODE: 6211003000

6211003000
6254004000
6219500400
0032214000
6211502902
0022705000
6211004000
6207003000
6251505001
0031424000
0031508000
210049-4
0011706300
6213009002
266671-5
922213-2
0119059900
450653-9
6213004001
0600109980
0031426000
6213500500
6218500000
168797-8
0203089990
264018-7
266573-5
6215500100
6214500400
6215009000
442177-9
0119059730
0021705000
5243500301
5241500403
0230059990
5243004001
5245501502
054001-10
324891-8
5317500200
5243500101
5243001002
5243500203
0119059690
6251024001
0031432000
0600129950
6252010000
6252008001
6252500600
5247004020
233976-8-4
5242500100
0053203101
257979-8
5242500601
5241500500
5241003000
0610089990
0600129920
0440129991
5215003040
5245007020
5245007010
5105015110
5415003010
5415003020
5245006000
5305002110
5415001140
5415001120
5415003030
5246500301
5242001002
5247002011
267429-5
267817-6
266457-7
5245500702
0031512000
6255502002
6255502100
0851169971
0561080010
163447-0
452920-8
5246500202
5216008010
5316005450
5206008110
5236018040
5236018010
5316005120
5246001010
5236046030
5246001030
WJ00009599
5236046130
442154-1
168574-8
5236046060
424314-7
5236046050
266582-4
5016004010
5236018020
5213500400
454831-3
423376-2
0230059970
5013501400
0140059730
5213500501
0043605120
0717049990

Quantity

on 7/10 Business Days Approx

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Makita Spare Parts for String Trimmer RBC261

We are MAKITA original spare parts Worldwide Dealers

at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for STRING TRIMMER RBC261.

In the following table, look for the model of Brusch Cutter and the respective parts of the code.

RBC261 - STRING TRIMMER 25,4CC pag.1
8	6211003000	BUSH COMPL. X RBC230
10	6254004000	HANGER ASSY RBC RBC260 / 230/310
11	0043105140	SCREW M 5 X 14 X RBC230
12	6219500400	WASHER X RBC260 / 230
13	0032214000	WAVE WASHER RBC230/260
14	6211502902	DAMPER BOLT RBC260
15	0022705000	NUT M5 X RBC230 / 310 / RBK410
16	6211004000	SHAFT COMPL. PIPE X RBC260 / 230
17	6207003000	BAND ASS'Y X RBC260 / 230
19	6251505001	SHAFT
20	0031424000	INNER SNAP RING XRBC260-230-225-
21	0031508000	OUTER SNAP RING XRBC260-230-225-255
22	210049-4	BALL BEARING 609ZZ EBH252L
23	6418500302	PROTECTER CLAMP X RBK250-RBC225
24	0011706300	BOLT M6X30 X RBK250-RBC225-
25	6213009002	GEAR CASE ASS'Y RBC230 / 260
26	266671-5	HEX.SOCKET HEAD BOLT M10X9
27	922213-2	SOCKET HEAD BOLT M5X12 EBH341U
28	0119059900	BOLT M5X12 X RBC225-255
29	0119059890	SOCKET HEAD BOLT M5X25 XRBC225-
30	450653-9	GUARD RBC2510
31	6213004001	GEAR SET RBC230
32	0600109980	BALL BEARING 6000
33	0031426000	INNER SNAP RING DBC260L/U/RBC2 X RBC260 / 230/225/2
34	6213500500	OIL SEAL RBC230
35	6218500000	RECEIVE WASHER RBC230 / 60
36	168797-8	CLAMP WASHER COMPLETE
37	0203089990	SPRING WASHER X RBC260 / 230RBK410
38	264018-7	NUT M8 RBC2510
102	266573-5	SCREW M5X33 EBH341U
103	6215500100	CONTROL CABLE X RBC 260
105	6214500400	GRIP RBC230 (C.E) X RBC230 / RBK 410
106	6215009000	CONTROL LEVER RBC230 XRBC230
107	0022705000	NUT M5 RBC230/260/310/2810 - RBK410
RBC261 - SRING TRIMMER 25,4CC pag.2
39	442177-9	GASKET AIR CLEANER
40	0119059730	SOCKET HD BOLT M5X20 DBC260L - RBC 260/230/225/255
41	0021705000	NUT M5 EPH1000/RBL500/MH2556 - RBC415
42	5243500301	INSULATOR GASKET X RBC260
43	0119059730	SOCKET HD BOLT M5X20 DBC260L - RBC 260/230/225/255
44	5241500403	CYLINDER XRBC260
45	0119059730	SOCKET HD BOLT M5X20 DBC260L - RBC 260/230/225/255
46	0230059990	SPACER RBC260/420/PB250/ 410 / RBK 410
47	5243004001	INSULATOR COMPLETE X RBC260
48	5245501502	CYLINDER COVER RBC260
51	054001-10	SPARK PLUG NGK - BPM7A (10PZ)
52	324891-8	SPARK PLUG SPRING EBH341
53	5317500200	SPARK PLUG CAP X RBC260 310
54	5243500101	MUFFLER GASKET X RBC260
55	5243001002	EXHAUST MUFFLER RBC260/310
56	5243500203	MUFFLER COVER
57	0119059690	BOLT M6X30
60	0119059730	SOCKET HD BOLT M5X20 DBC260L /230/225/255
61	0119059730	SOCKET HD BOLT M5X20 DBC260L/230/225/255
62	6251024001	DAMPER ASSY RBC260
63	0031432000	INNER SNAP RING RBC260/EM4251 / 310/410
64	0600129950	BALL BEARING 6201DD RBC260/310
66	6252010000	CLUTCH DRUM COMPL. X RBC260
67	0119059730	SOCKET HD BOLT M5X20 DBC260L RBC 260/230/225/255
68	6252008001	CLUTCH ASS'Y X RBC260
69	6252500600	CLUTCH SPRING RBC260
71	5247004020	IGNITION COIL X RBC260
72	0119059730	SOCKET HEAD BOLT M5X20 X RBC 260/230/225/255
73	0119059730	SOCKET HEAD BOLT M5X20 X RBC 260/230/225/255
74	233976-8-4	CLIP EBH252L (4pcs)
75	5242500100	PISTON PIN X RBC260 / 230
76	0053203101	WOODRUFF KEY RBC / RBK 410
77	257979-8	PISTON RING RBC2510
78	5242500601	PISTON X RBC260
79	233976-8-4	CLIP EBH252L (4pcs)
80	5241500500	CYLINDER GASKET X RBC260
81	5241003000	CRANKCASE ASS'Y X RBC260
82	0610089990	NEEDLE ROLLER BEARING X RBC260 / 230/310 /
83	0600129920	BALL BEARING #6001 C3 MS5250
85	0440129991	OIL SEAL X RBC415
86	0119059730	SOCKET HEAD BOLT M5X20 X RBC 260/230/225/255
87	5215003040	E RING PB500R
88	5245007000	PULLEY STARTER
89	5245007020	RETURN SPRING X RBC260
90	5245007010	RATCHET X RBC260
91	5105015110	SCREW X RBC260 / 230/520
92	5415003010	REEL X RBC260
93	5415003020	SPIRAL SPRING X RBC260
94	5245006000	REWIND STARTER X RBC260
95	0119059730	SOCKET HEAD BOLT M5X20 X RBC 260/230/225/255
96	5305002110	STARTER KNOB X RBC260 / RBK41
97	5415001140	STARTER ROPE X RBC 260/410 / RBK 410
98	5415001120	ROPE GUIDE X RBC260
100	5415003030	WASHER X RBC 260
101	0119069841	SCREW M 6 X 15 X RBC260
102	5246500301	DAMPER X RBC 260
103	5242001002	CRANKSHAFT COMPL. X RBC 260
104	0600129920	BALL BEARING #6001 C3 MS5250
106	0440129991	OIL SEAL X RBC415
107	5247002011	MAGNETO FLYWHEEL X RBC 260
108	0119069841	SCREW M 6 X 15 X RBC260
109	267429-5	WASHER 6
110	267817-6	WASHER 8 EBH252L
111	266457-7	SCREW M6X25 EBH252L
112	5245500702	BAFFLE PLATE X RBC 260
114	0031512000	OUTER SNAP RING X RBC260 / 520RBK410
115	0119059730	SOCKET HEAD BOLT M5X20 X RBC 260/230/225/255
116	0119059730	SOCKET HEAD BOLT M5X20 X RBC 260/230/225/255
117	6255502002	STAND RBC 260
118	6255502100	STAND DAMPER X RBC 260
119	0851169971	TUBE X RBC260 / 310
120	0561080010	HOSE CLAMP EPH1000/EM4251/434 - RBC 260 / RBC520
121	163447-0	GASOLIN FILTER ER2550/DCS230T
122	452920-8	FUEL TANK CAP
123	5246500301	DAMPER RBC260
124	5246500301	DAMPER RBC260
126	5246500202	FUEL TANK PLATE RBC260
127	0119059730	SOCKET HD BOLT M5X20 X RBC 260/230/225/255
RBC261 - SRING TRIMMER 25,4CC pag.3
128	5216008010	CABLE ADJUST SCREW RBC230/260 - 310
129	5316005450	CABLE ADJUST NUT RBC230/RBC260 / 310
131	5206008110	PLUG RBC230/260/310/EM4251 RBC225
132	5236018040	SWIVEL EPH1000/EH7500/RBC230-260-310-225-
133	5236018010	THROTTLE VALVE ASS'Y RBC230 -310
134	5316005120	RING DBC260L/U/EH7500/RBC230/310/225/2
137	5246001010	O RING EH7500/EPH1000/RBC310 RBC 260/230
138	5236046030	CARBURETOR JET RBC260/PB250/RBL250
139	5246001030	PUMP GASKET RBC260-230-310-
140	WJ00009599	PUMP DIAPHRAGM X DCS230T
141	5236046130	PUMP BODY ASS'Y X RBC350-RBC42
142	442154-1	METERING DIAPHRAGM GASET EBH341U
143	168574-8	METERING DIAPHRAGM COMPL. EBH341U
144	5236046060	AIR PURGE BODY ASS'Y RBC350
145	424314-7	PRIMER PUMP EBH341
146	5236046050	PRIMER PUMP COVER X RBC350-RBC42
147	266582-4	SCREW 3X24 EBH341U
148	5016004010	INLET SCREEN X RBC 260/230/310/225
149	0022705000	NUT M5 X RBC230 / 310 / RBK410
150	5236018020	RING PACKING X RBC 260/230 / 310
151	5213500400	AIR CLEANER CASE X RBC 260/230/230
152	454831-3	LEVER CHOKE
153	423376-2	GASKET EBH341U
154	0230059970	SPACER X RBC 260/230/310
155	5013501400	AIR CLEANER PLATE X RBC 260/230/310
156	0140059730	SCREW M5X50 X RBC260 / 310
157	5213500700	AIR CLEANER ELEMENT RBC230 / 260/310
158	5213500501	AIR CLEANER CASE COVER RBC 260/230/310
159	0043605120	SCREW M5X12 X RBC 260/230/310
204	0717049990	HEX. WRENCH X RBC350-RBC420
