Makita Spare Parts for Brusch Cutter BBC4510
Fix Your Brusch Cutter BBC4510. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Brusch Cutter and the respective parts of the code.
| Brusch Cutter BBC4510 | ||
| A Pag.1 |
||
| # | Part Num. | Description |
| 1 | BB630070 | STARTING ROPE |
| 2 | BB510190 | STOP PLATE |
| 3 | BB724740 | STRARTING HANDLE |
| 4 | BB091640 | STOPPER |
| 5 | BB543600 | RUBBER |
| 6 | BB724300 | STARTER CARTER COVER |
| 7 | BB180240 | SPRING |
| 8 | BB541320 | STARTING PULLEY |
| 9 | BB090720 | FLAT WASHER D.4,3 X 16 |
| 10 | BB030800 | SCREW TCB M 4 X 10 |
| 11 | BB730050 | WHITE STARTER ASSY BBK5700 FROM 2017 |
| 12 | BB030410 | SCREW TCEI M 5 X 18 |
| 13 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 14 | BB541340 | TANK RUBBER |
| 15 | BB060370 | NUT M 9 X 1.25 |
| 16 | BB730080 | SUPPORT REEL (FROM 2017) |
| 17 | BB541330 | START PAWL |
| 18 | BB180200 | PAWL SPRING |
| 19 | BB120160 | STOP RING D4 |
| 20 | BB722460 | PAWL GROUP |
| 21 | BB240370 | SEALING RING 15X26X7 |
| 22 | BB721430 | ASSEMBLY ENGINE CRANKCASE |
| 23 | BB240260 | GASKET |
| 24 | BB420200 | PLUG D.8X10 |
| 25 | BB270070 | BEARING 6202 |
| 26 | BB751600 | CRANKSHAFT |
| 27 | BB090150 | GROWER WASHER 5.1 |
| 28 | BB030620 | SCREW TCEI M 5 X 35 |
| 29 | BB240030 | SEALING RING 15X26X7 |
| 30 | BB420030 | WOODRUFF 10X3,7X3 |
| 31 | BB270050 | NEEDL BEARING PB K10X14X13FKI-V1 |
| 32 | BB150040 | CIRCLIP D.10 |
| 33 | BB420040 | PISTON PIN D.10X30 |
| 34 | BB480710 | PISTON DIAM. 41 FOR N45E |
| 35 | BB150240 | PISTON RING D.41 |
| 36 | BB721350 | COMPLETE PISTON D.41 |
| 37 | BB240270 | CYLINDER GASKET |
| 38 | BB090620 | SCHNORR WASHER D6.4 |
| 39 | BB030630 | SCREW TCEI M 6 X 25 |
| 40 | BB752340 | DECOMPRESSOR X MOTORS N39 / 57E |
| 41 | BB480630 | CYLINDER DIAM.41 FOR N45E |
| 42 | BB240290 | MANIFOLD GASKET |
| 43 | BB541270 | CARBURATOR MANIFOLD |
| 44 | BB090800 | WASHER SCHNORR D.5,3 |
| 44A | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 45 | BB030070 | SCREW TE M 5 X 30 |
| 46 | BB240130 | CARBURETOR GASKET |
| 47A | BB331650A | CARBURETOR FOR BBK4500 |
| 48 | BB726390 | COMPLETE AIR FILTER SUPPORT |
| 49 | BB091630 | SLEEVE |
| 52 | BB120270 | RING |
| 53 | BB031140 | SCREW M 3 X 8 |
| 54A | BB726390 | COMPLETE AIR FILTER SUPPORT |
| 55 | BB090830 | WAVY WASHER D. 5.3 |
| 56 | BB030500 | SCREWS TCEI M 5 X 45 |
| 57 | BB332100 | AIR FILTER X CARBURAT.WALBRO |
| 57A | BB332250 | AIR FILTER DBC5700 |
| 58 | BB543180 | BLUE FILTER COVER |
| 59 | BB543090 | BLUE ENGINE CYLINDER COVER |
| 60 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 61 | BB030680 | SCREW TCEI M 5 X 14 |
| 62 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 63 | BB030620 | SCREW TCEI M 5 X 35 |
| 64 | BB451060 | SPARK PLUG RCJ4 |
| 65 | BB543200 | BLUE SPARK PLUG CAP |
| 66 | BB240500 | SEAL GASKET |
| 67 | BB752350 | MUFFLER |
| 68 | BB090830 | WAVY WASHER D. 5.3 |
| 69 | BB030410 | SCREW TCEI M 5 X 18 |
| 70 | BB090830 | WAVY WASHER D. 5.3 |
| 71 | BB030680 | SCREW TCEI M 5 X 14 |
| 73 | BB031150 | SCREW M 5 X 20 |
| 74 | BB450930 | CAPACITIVE COIL FOR N39 / 57 |
| 75 | BB450340 | COIL CABLE |
| 76 | BB541510 | CABLE GLAND |
| 77 | BB450280 | FLYWHEEL FOR N39 / 57 |
| 78 | BB091000 | WAVY WASHER D.10.5 |
| 79 | BB060300 | NUT M 10 X 8 |
| 80 | BB780080 | SUPPORT N31 / 52 |
| 81 | BB780020 | CLUTCH ARM N31 / 52 |
| 82 | BB180040 | SPRING |
| 83 | BB180030 | SPRING |
| 84 | BB510200 | DISK |
| 85 | BB721390 | COMPLETE CLUTCH |
| 86 | BB090830 | WAVY WASHER D. 5.3 |
| 87 | BB030620 | SCREW TCEI M 5 X 35 |
| 88 | BB751300 | DRUM CLUTCH |
| 89 | BB120070 | SEEGER RING 32I UNI 7437 |
| 90 | BB270240 | BEARING 6201-ZZ |
| 91 | BB120020 | SEEGER RING 12E UNI 7435-75 |
| 92 | BB480980 | HOUSING CLUTCH |
| 99 | BB724100 | HOLDER GROUP |
| 100 | BB726390 | COMPLETE AIR FILTER SUPPORT |
| 107 | BB030380 | SCREW TCEI M 5 X 16 |
| 108 | BB543220 | LOWER HALF CASING |
| 109 | BB543210 | UPPER HALF CASING |
| 110 | BB481000 | LOWER SPACER |
| 111 | BB480990 | UPPER SPACER |
| 112 | BB060100 | NUT M 5 X 4 |
| 113 | BB030410 | SCREW TCEI M 5 X 18 |
| 114 | BB724110 | FUEL TANK ASS'Y |
| 115 | BB542520 | FUEL RETURN PIPE |
| 116 | BB723740 | CPL TANK CAP |
| 117 | BB542460 | FUEL PIPE |
| 118 | BB330820 | FUEL FILTER |
| B Pag.2 | ||
| 1 | BB543490 | NEW TYPE HANDLEBAR KNOB |
| 2 | BB511030 | THICKNESS |
| 3 | BB750920 | HOOK |
| 4 | BB030630 | SCREW TCEI M 6 X 25 |
| 5 | BB090040 | FLAT WASHER D6.4 |
| 6 | BB542450 | SUPPORT |
| 8 | BB542440 | BODY SUPPORT |
| 9 | BB542430 | BODY SHELL CRUISE |
| 10 | BB030810 | SCREW TCEI M 6 X 40 |
| 11 | BB722620 | HANDLEBAR SUPPORT |
| 12 | BB751640 | BUSH |
| 13 | BB391030 | TRASMISSION SHAFT |
| 14 | BB540420 | ANTIVIBRATION BUSHING D.27 |
| 15 | BB750540 | RUBBER TUBE |
| 16 | BB540690 | GAS CONTROL CABLE SUPPORT |
| 17 | BB570530 | TUBE RUBBER |
| 18 | BB542420 | HANDLE |
| 19 | BB722830 | HANDLE |
| 20 | BB570670 | HANDLEBAR X EBC NBC |
| 21 | BB751620 | HARNESSES |
| 22 | BB751580 | HARNESS |
| C Pag.3 | ||
| 1 | BB090020 | BUSHING |
| 2 | BB030800 | SCREW TCB M 4 X 10 |
| 3 | BB120020 | SEEGER RING 12E UNI 7435-75 |
| 4 | BB120010 | SEEGER RING 28I UNI 7437 |
| 5 | BB270010 | BEARING 6001-ZZ |
| 6 | BB723380 | GEAR KIT |
| 7 | BB060060 | NUT M 6 X 5 |
| 8 | BB090010 | GROWER WASHER D. 6.1 |
| 9 | BB480470 | GEAR CASING D.27 |
| 10 | BB030010 | SCREW TE M 6 X 30 |
| 11 | BB031080 | GREASE CAP SCREW |
| 12 | BB270020 | BALL BEARING 6000 |
| 13 | BB390010 | SPINDLE X D.27 |
| 14 | BB420010 | LOCK PIN |
| 15 | BB270030 | BEARING 6202-2RS |
| 16 | BB120030 | SEEGER RING 35I UNI 7437 |
| 17 | BB091560 | DISK HOLDER RING D.50 |
| 18 | BB510180 | UPPER FLANGE |
| 19 | BB090070 | DISC FIXING FLANGE X D.27 |
| 20 | BB060470 | NUT M 10 X 1 X 12 |
| 21 | BB722760 | GEAR CASE ASSY BBC4500 |
| 22 | P-47400 | 8 TEETH KNIFE |
| 23 | P-47341 | BLADE 48 TEETH (255X1.4X25.4) MM |
| 24 | P-47391 | 4 TEETH KNIFE (255X1.4X25.4) MM |
| 25 | BB120050 | SEEGER RING 15E UNI 7435-75 |
| 26 | BB480060 | BEARING SUPPORT |
| 27 | BB270060 | BEARING 6002-ZZ |
| 28 | BB060160 | NUT M10X1 |
| 30 | BB090010 | GROWER WASHER D. 6.1 |
| 31 | BB030050 | SCREW TE M 6 X 12 |
| 33 | BB060100 | NUT M 5 X 4 |
| 34 | BB542410 | SAFETY GUARD |
| 35 | BB511020 | BLADE |
| 36 | BB030820 | SCREW 3,9 X 16 |
| 37 | BB729200 | COVER GUARD |
| 38 | BB091360 | WASHER 5.5 X 15 X 1.6 |
| 39 | BB090150 | GROWER WASHER 5.1 |
| 40 | BB030830 | SCREW M 5 X 12 |
| 41 | P-47335 | SONE GUARD D.27 |
| 42 | P-47282 | CUP |
| 43 | BB720330 | SERVICE KEY |
| D Pag.4 | ||
| 1 | BB543260 | LOWER CAP |
| 3 | BB180370 | SPRING |
| 4 | BB091350 | BUSHING GUIDE WIRE X HEAD |
| 5 | BB543280 | REEL FLASH LIGHT |
| 6 | BB543270 | FLASH LIGHT FLANGE |
| 7 | P-47313 | HEAD TAP AND GO M10X1.0F |
| 8 | BB542180 | LOWER CUP FLASH RAPID |
| 10 | BB180180 | SPRING X AUTOMATIC HEAD |
| 11 | BB091350 | BUSHING GUIDE WIRE X HEAD |
| 12 | P-47254 | REEL FOR HEAD P-47422 |
| 13 | BB542190 | FLANGE |
| 14 | P-47422 | HEAD TAP AND GO M10X1.0F |
| 15 | BB391510 | HEAD NUT FLASH QUICK |
| 16 | BB543460 | LOWER CAP HEAD QUICK |
| 17 | BB091350 | BUSHING GUIDE WIRE X HEAD |
| 18 | BB724140 | REEL FLASH QUICK |
| 19 | BB180110 | SPRING HEAD FLASH AND QUICK |
| 20 | BB543430 | QUICK HEAD BUTTON |
| 21 | BB091600 | LOWER NUT HEAD FLASH QUICK |
| 22 | P-47416 | MANUAL HEAD M10X1.0F |
| 23 | BB390540 | NUT X FLASH HEAD |
| 24 | BB541110 | TOP COVER FLASH HEAD |
| 25 | BB091350 | BUSHING GUIDE WIRE X HEAD |
| 26 | BB540340 | REEL FOR HEAD FLASH |
| 27 | BB180110 | SPRING X HEAD FLASH AND QUICK |
| 28 | BB541100 | LOWER FLASH COVER |
| 29 | BB090590 | WASHER X M16 17X30X3 |
| 30 | BB480310 | KNOB X HEAD SIN. |
| 31 | P-47307 | MANUAL HEAD M10X1.0F |
| E Pag.5 | ||
| 4 | BB751100 | CABLE GROUP |
| 5 | BB721450 | CPL HANDLE KNOB |
| 6 | BB722740 | CPL KNOB |
| F Pag.6 | ||
| 6 | BB96-166 | SCREW COVER PUMP WT |
| 7 | BB21-353 | WT PUMP COVER |
| 8 | BB96-647 | SCREW + SPRING X ADJUSTMENT MINIMUM |
| 9 | BB92-225 | MIXED PUMP GASKET |
| 10 | BB95-118 | PUMP WT MEMBRANE |
| 11 | BB88-131 | CAP |
| 13 | BB96-142 | VALVE SCREW WT |
| 14 | BB52-548 | WT101 PIN |
| 15 | BB30-1140 | SHAFT |
| 16 | BB34-158 | VALVE |
| 17 | BB98-234 | SPRING |
| 18 | BB140-70 | FUEL FILTER |
| 19 | BB16-71 | SAFETY RING |
| 20 | BB102-330 | SCREW ADJUSTMENT MINIMUM WT |
| 21 | BB98-404 | MINIMUM ADJUSTING SPRING |
| 22 | BB102-3066 | SCREW MAXIMUM ADJUSTMENT WT |
| 23 | BB98-405 | MAXIMUM ADJUSTING SPRING |
| 24 | BB140-69 | WASHER |
| 25 | BB16-42 | LOCK RING |
| 26 | BB88-119 | CAP |
| 27 | BB88-171 | MINIMUM CIRCUIT CAP |
| 28 | BB96-156 | BALANCED AXLE SCREW |
| 29 | BB84-613 | VALVE SEAT |
| 30 | BB82-75 | PIN VALVE |
| 31 | BB98-387 | SPRING VALVE |
| 32 | BB166-48 | LEVEL METERING |
| 33 | BB144-77 | BALANCE AXIS |
| 34 | BB92-251 | WT MEMBRANE GASKET |
| 35 | BB95-526 | DIAPHRAGM MEMBRANE |
| 36 | BB5-2694 | AIR FILTER BODY |
| 37 | BB176-64 | CONTROL VALVE |
| 38 | BB188-12 | GASKET |
| 39 | BB21-404 | PRIMER PUMP COVER |
| 40 | BB090190 | GROWER WASHER D.3,1 |
| 41 | BB96-578 | MEMBRANE COVER SCREW |
| 42A | BB331650A | CARBURETOR FOR BBK4500 |
| 43 | BBD10-WAT | MEMBRANE X WT KIT 362,364,397 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
