Makita Spare Parts for Cordless Chain Saw DUC122RFE

We supply original MAKITA spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Cordless Chain Saw DUC122RFE.

In the following table, look for the model of the Cordless Chain Saw and the respective parts of the code.
Makita DUC122RFE

Cordless Chain Saw DUC122RME
# Part Num. Description
1 158472-4 KNOB 60 X BUC121R
2 267004-7 FLAT WASHER 6 X4301SV
3 158471-6 CARTER PIGNONE X BUC121R
4 961014-3 RETAINING RING E-8
5 221527-9 PINION 9D X BUC121R
6 267732-4 WASHER 12
7 232238-1 SPRING PLATE X BUC121R
8 265995-6 SCREW M4X18 X 6408/6221DW
9 265995-6 SCREW M4X18 X 6408/6221DW
10 450213-7 BEARING CASE BUC121R
11 323806-2 SPINDLE X BUC121R
12 211051-0 BALL BEARING 609 2RS
13 226673-3 HELICAL GEAR 50 X BUC121R
14 450436-7 CAM FOR BUC121R
15 210033-9 BEARING 696ZZ X 2107FK
16 450435-9 OIL PUMP CRANK X BUC121R
17 213993-4 RING 1.5 X BUC121R
18 158571-2 OIL PUMP FOR BUC121R
19 421615-4 OIL PUMP CONNECTOR HOSE BUC121R
20 158810-0 TANK CAP ASSY
22 158634-4 OIL TANK X BUC121R
23 187237-7 HANDLE
24 231470-4 SPRING 6 X 6811DW
25 416178-3 RESET BUTTON X UC3020A
26 651956-6 SWITCH TG72BD X 5621RDW
27 450212-9 LEVER SWITCH. X BUC121R
28 644808-8 X-TERMINAL BLS713 BHP451
29 257264-9 RING 30 X BUC121R
30 265995-6 SCREW M4X18 X 6408/6221DW
31 619225-1 ARMATURE BUC122R
32 638138-7 STATOR PERMANENT MAGNET
33 638608-6 HOLDER BRUSHES BUC121R
34 188468-1 HOUSING MOTOR X BUC121R
37 266050-7 SCREW 4X30 PT
38 191971-3 CARBON BRUSH SET CB-430
39 643807-7 CARBON BRUSHE HOLDER CAP 6347D
41 265995-6 SCREW M4X18 X 6408/6221DW
42 158474-0 SAFE HANDES X BUC121R
43 266050-7 SCREW 4X30 PT
44 450217-9 FRONT HANDLE BUC121R
45 266050-7 SCREW 4X30 PT
46 265995-6 SCREW M4X18 X 6408 / 6221DW
47 259041-5 RING FOR 8 UC3020A
48 443125-1 FILTER UC3020A
49 620098-7 REGULATOR
501 158479-0 GUIDE BAR 115 mm 1/4 "
502 P-19928 CHAIN 25AP DRIVE LINK 42 .050" 1/4" - FILE SIZE 5/32"
