Makita Spare Parts for Lawn Mower ELM3800

€2.21
Tax included

Makita Spare Parts for Lawn Mower ELM3800

We have the original Spares Makita for Lawn Mower ELM3800, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Lawn Mower ELM3800. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 671001003
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Lawn Mower ELM3800

Fix Your Lawn Mower ELM3800. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of Lawn Mower and the respective parts of the code.
Makita ELM3800
Lawn Mower ELM3800
# Part Num. Description
1 671010049 COVER HUB 190MM
2 671005028 NUT M8 ELM4110
3 671946001 WHEEL BACK 190MM
4 671002424 AXIS BACK
5 671001203 PLATE ELM4110
6 671105502 SCREW M5X16
7 671011209 SPRING 72A
8 671001436 WASHER ELM4110
9 DA00000916 CUTTER BLADE 38CM
10 671007002 WASHER 8
11 671008002 WASHER ELM4110
12 671006017 SCREW M8X30 ELM4110
13 671960001 HOLDER BLADE
14 671978003 PROTECTION
15 671001005 SCREW M4X16 ELM3310-3710
16 671939003 BLACK FRAME
17 671010048 COVER HUB 138CM
18 671944001 FRONT WHEEL 138CM
19 671002421 FRONT AXIS
20 671001015 FRONT
21 671771001 CAP
22 671010230 CABLE CLAMP
23 671974002 BLOCKING HANDLE
24 671972002 LEFT HOLDER
25 671005023 NUT M8
26 671973002 RIGHT HOLDER
27 671011012 SPRING D11
28 671001006 PIN
29 671975004 BACK COVER
30 671949002 HEIGHT ADJUSTMENT PLATE
31 671951002 PIN
32 671941003 SIDE COVER
33 671002426 PRESSURE PLATE
34 671948004 HEIGHT ADJUSTMENT LEVER
35 671950002 HEIGHT ADJUSTMENT PLATE
36 671956001 COVER
37 671104901 CAPACITOR
38 671200202 COIL
39 671004048 BEARING 6003-2RS
40 671040130 BEARING 6002-2RS
41 671004007 BEARING 609ZZ
42 671009016 ELASTIC RING
43 671001003 SCREW 4X12 ELM3310-3710
44 671201101 CAP
45 671002058 BELT
46 671003072 SCREW M5x25
47 671959001 BIG PULLEY
48 671002360 DISC BRAKE
49 671010740 SCREW 4,8X16
50 671958001 INNER FRAME
51 671040290 PULLEY
52 671008011 WASHER 5.65
53 671030280 ENGINE 1400W
54 671001054 SCREW 5X12 ELM3310-3710
55 671124001 INTERIOR ENGINE COVER
56 671005005 NUT M6 ELM4110
57 671580020 BRAKE
58 671006041 SCREW M6X12
59 671011198 SPRING
60 671277001 CABLE HOLDER
61 671017380 LOWER HANDLE
62 671001198 CAP ELM3310-3710
63 671010270 SPONGE
64 671942002 ENGINE COVER
65 671943001 COVER HANDLING
66 671001016 4X20 SCREW
67 671010500 KNOB
68 671001085 WASHER ELM4110
69 671001253 BRAKE WIRE CPL
70 671006130 SCREW M8X47
71 671803001 PROTECTION
72 671010570 POWER CABLE
73 671001010 CABLE 1250MM ELM3310-3710
74 671283001 BUSH 1 ELM3310-3710
75 671006077 SCREW M6X35 PM5120-5120S
76 671336001 HOLDER PLM4110-4610-4611
77 671007008 WASHER PLM4110-4610-4611
78 671050160 NUT M6
79 671001999 ENGINE BRAKE LEVER
80 671955001 HOLDER HANDLE
81 671391001 WASHER
82 671001268 ENGINE BRAKE CABLE 168MM
83 671657001 ELM4611 CONNECTOR
84 671001939 TOP HANDLE
85 671952001 PRESSURE PLATE
86 671769001 SWITCHBOARD COVER SWITCH
87 671263001 PLATE
88 671776001 SWITCH LOCK
89 671010220 SWITCH 5E4 IP55 T85
90 671011005 MOLLA PLM4110-4610-4611
91 671011179 SPRING
92 DA00000925 SWITCH LEVER END CAP RIGHT
93 671002033 SCREW M4X8
94 671953001 TOP COVER
95 671774009 SAFETY BUTTON
96 671010860 ERROR LEVEL INDICATOR
97 671977001 HANDLE
98 671976001 COVER BAG
99 671157004 BAG
100 671001988 FRAME FOR BAG
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
