Kawasaki Spare Parts for Bruschcutter Top 35U - TJ035E - 73121
€1.27
Tax included
Kawasaki Spare Parts for Bruschcutter Top 35U - TJ035E - 73121
Kawasaki original spare parts for to replace broken parts or to fix Bruschcutter AMA Garden Powered Kawasaki Top 35U - TJ035E - AMA 73121.- Engine MODEL Top 35
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Kawasaki Spare Parts for Bruschcutter Top 35U - TJ035E - 73121
Kawasaki original spare parts for to replace broken parts or to fix Kawasaki original spare parts for to replace broken parts or to fix Bruschcutter AMA Garden Powered Kawasaki Top 35U - TJ035E - AMA 73121.
- Engine MODEL Top 35
In the following table, look for the model of the Bruschcutter and the respective parts of the code.
| Bruschcutter AMA Garden Powered Kawasaki Top 35U - TJ035E - AMA 73121 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 63729 | ENGINE 35cc |
| 2 | 55620 | CLUTHC DRUM ASS.BLY |
| 3 | 13586 | SCREW |
| 4 | 55440 | ANTI-VIBRATION BEARING |
| 5 | 55441 | BEARING |
| 6 | 13580 | DRIVE SHAFT |
| 7 | 55160 | HANDLE |
| 8 | 13639 | HANDLE PIPE |
| 9 | 13635 | LOWER HANDLE BRACKET |
| 10 | 13588 | SCREW |
| 11 | 13638 | PIPE ANTI-VIBRATION |
| 12 | 13636 | CENTRAL HANDLE BRACKET |
| 13 | 55617 | BAR ANTI-VIBRATION |
| 14 | 62031 | HOOK |
| 15 | 73826 | COMPLETE PIPE D.28 |
| 16 | 13923-06 | THROTTLE LEVER |
| 17 | 69501 | THROTTLE HANDLE COMPLETE |
| 18 | 13936 | SWITCH ON/OFF |
| 19 | 13924-06 | SAFETY LEVER |
| 20 | 13610 | GEAR BOX |
| 21 | 13571 | GUARD BRACKET |
| 22 | 37944 | COMPLETE GUARD |
| 23 | 13532 | UPPER FLANGE |
| 24 | 13533 | LOWER FLANGE |
| 25 | 10125 | NUT |
| 26 | 55608 | EASY CHARGE NYLON HEAD |
| 27 | 13933 | NUT |
| 28 | P07086 | HARNESS |
| 29 | 13637 | UPPER HANDLE BRACKET |
| 30 | 13931 | SCREW |
| 31 | 55353 | ENGINE FLANGE |
| Kawasaki Top 35U - Engine TJ035E Pag.2 | ||
| 11005 | 11005-2160 | CYLINDER-ENGINE |
| 11061 | 11061-2192 | GASKET |
| 11065 | 11065-2130 | CAP |
| 13272 | 13272-2009 | PLATE |
| 14080 | 14080-2064 | CRANKCASE |
| 14080A | 14080-2065 | CRANKCASE |
| 34001 | 34001-2090 | STAND |
| 92043 | 92043-1302 | PIN |
| 92045 | 92045-2058 | BEARING-BALL,6201C3 |
| 92049 | 92049-2253 | SEAL-OIL,ISCD12X22X4.5 |
| 92049A | 92049-2267 | SEAL-OIL,ISCD 12X22X4.5F |
| 120 | 120CB0520 | BOLT-SOCKET,5X20 |
| 214 | 214AA0408 | SCREW-PAN+-,4X8 |
| 221 | 221AA0408 | SCREW-CSK-CROSS,4X8 |
| 225 | 225AA0530 | SCREW-PAN-WSP-CROS,5X30 |
| 13001 | 13001-2170 | PISTON-ENGINE |
| 13002 | 13002-2101 | PIN-PISTON |
| 13008 | 13008-6045 | RING-SET-PISTON |
| 13033 | 13033-2065 | BEARING-SMALL END |
| 13033A | 13033-2067 | BEARING-SMALL END |
| 49119 | 49119-2243 | CRANKSHAFT-ASSY |
| 92026 | 92026-2355 | SPACER,9X15X1.8 |
| 92033 | 92033-2061 | RING-SNAP |
| 39156 | 39156-2089 | PAD,SHROUD |
| 49089 | 49089-2643 | SHROUD-ENGINE |
| 59066 | 59066-2800 | HOUSING-FAN |
| 92172 | 92172-2060 | SCREW,4X10 |
| 233 | 233AA0516 | SCREW-PAN-WP+-,5X16 |
| 16073 | 16073-2220 | INSULATOR |
| 21050 | 21050-2317 | FLYWHEEL |
| 21130 | 21130-2074 | CAP-SPARK PLUG |
| 21130A | 21130-2077 | CAP-SPARK PLUG |
| 21169 | 21169-2051 | TERMINAL |
| 21171 | 21171-2257 | COIL-ASSY-IGNITION |
| 26011 | 26011-2113 | WIRE-LEAD |
| 26011A | 26011-2361 | WIRE-LEAD,L=230 |
| 92070 | 92070-2107 | PLUG-SPARK,BPMR7A(NGK),SOLID |
| 92153 | 92153-2134 | BOLT,4X20 |
| 92170 | 92170-2041 | CLAMP |
| 92192 | 92192-2165 | TUBE,6X6.6X80 |
| 92210 | 92210-2094 | NUT,M8 |
| 510 | 510A3100 | KEY-WOODRUFF |
| 11049 | 11049-2006 | BRACKET |
| 11060 | 11060-2111 | GASKET |
| 11061 | 11061-2054 | GASKET |
| 11061A | 11061-2208 | GASKET,CARBURETOR/INSULATOR |
| 11061B | 11061-2209 | GASKET,CYLINDER/INSULATOR |
| 12021 | 12021-2055 | VALVE-ASSY-REED |
| 12022 | 12022-2060 | VALVE-REED |
| 14043 | 14043-2051 | FILTER |
| 14090 | 14090-2017 | COVER,PRIMER PUMP |
| 15004 | 15004-2049 | CARBURETOR-ASSY |
| 16030 | 16030-2078 | VALVE-FLOAT |
| 16055 | 16055-2051 | LEVER |
| 16160 | 16160-2089 | BODY |
| 16160A | 16160-2141 | BODY |
| 21083 | 21083-2073 | ARM |
| 32085 | 32085-2106 | STOPPER |
| 43028 | 43028-2067 | DIAPHRAGM |
| 43028A | 43028-2096 | DIAPHRAGM |
| 43049 | 43049-2062 | PACKING |
| 49043 | 49043-2067 | PUMP-PRIMING |
| 92009 | 92009-2249 | SCREW,5X20 |
| 92009A | 92009-2277 | SCREW |
| 92009B | 92009-2336 | SCREW |
| 92009C | 92009-2337 | SCREW |
| 92009D | 92009-2354 | SCREW |
| 92015 | 92015-2145 | NUT |
| 92033 | 92033-2078 | RING-SNAP |
| 92043 | 92043-2094 | PIN |
| 92055 | 92055-2147 | RING-O |
| 92063 | 92063-2393 | JET-MAIN,#37 |
| 92144 | 92144-2308 | SPRING |
| 92172 | 92172-2091 | SCREW,3X12 |
| 92200 | 92200-2074 | WASHER |
| 234 | 234AA0560 | SCREW-PAN-WSP+-,5X60 |
| 11011 | 11011-2366 | CASE-AIR FILTER |
| 11013 | 11013-2229 | ELEMENT-AIR FILTER |
| 11061 | 11061-2193 | GASKET,MUFFLER |
| 11065 | 11065-2125 | CAP |
| 18020 | 18020-2091 | BAFFLE |
| 18077 | 18077-2139 | ARRESTER-SPARK |
| 49069 | 49069-2435 | MUFFLER-ASSY |
| 92009 | 92009-2411 | SCREW |
| 92153 | 92153-2128 | BOLT |
| 120 | 120CB0516 | BOLT-SOCKET,5X16 |
| 242 | 242AA0512 | SCREW-PAN-WSP+-,5X12 |
| 14069 | 14069-2088 | BREATHER |
| 49019 | 49019-2114 | FILTER-FUEL |
| 51001 | 51001-2336 | TANK-COMP-FUEL |
| 51048 | 51048-2083 | CAP-ASSY-TANK |
| 92009 | 92009-2383 | SCREW,5X20 |
| 92071 | 92071-2142 | GROMMET,FUEL TANK |
| 92171 | 92171-2073 | CLAMP |
| 92191 | 92191-2102 | TUBE,3X5X182 |
| 92192 | 92192-2117 | TUBE,3X6X90 |
| 99996 | 99996-6089 | CAP-TANK & BREATHER,ASSY |
| 13165 | 13165-2103 | PAWL |
| 13169 | 13169-2386 | PLATE,RECOIL STARTER |
| 32099 | 32099-2419 | CASE,STARTER-RECOIL |
| 46075 | 46075-2161 | GRIP,STARTER-RECOIL |
| 49060 | 49060-2062 | CAM,STARTER-RECOIL |
| 49080 | 49080-2201 | PULLEY-STARTING |
| 49088 | 49088-2566 | STARTER-RECOIL |
| 59101 | 59101-2119 | REEL,STARTER-RECOIL |
| 59106 | 59106-2072 | ROPE,3.5X850 |
| 92033 | 92033-2010 | RING-SNAP |
| 92144 | 92144-2054 | SPRING |
| 92144A | 92144-2157 | SPRING |
| 92145 | 92145-2149 | SPRING |
| 92172 | 92172-2061 | SCREW,4X14 |
| 92172A | 92172-2065 | SCREW |
| 13081 | 13081-2220 | CLUTCH-ASSY |
| 13081A | 13081-2236 | CLUTCH-ASSY |
| 49049 | 49049-2075 | SHOE-CLUTCH |
| 49049A | 49049-2104 | SHOE-CLUTCH |
| 92026 | 92026-2125 | WASHER |
| 92043 | 92043-2210 | PIN,CLUTCH |
| 92144 | 92144-2390 | CLUTCH SPRING |
| 92145 | 92145-2178 | SPRING |
| 92200 | 92200-2064 | WASHER,SPRING,10.5X14.5X0.3 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
