Hitachi Spare Parts for Demolition Hammer H65SB2
€7.63
Tax included
Hitachi Spare Parts for Demolition Hammer H65SB2
Hitachi-HIKOKI original spare parts for to replace broken parts for to fix Demolition Hammer H65SB2.High demolition capacity, 1.340W motor and 42 Joule of energy per shot.
Equipped with 30 mm hexagonal connection, double anti-vibration isolation, grease lubrication.
Ideal for crushing reinforced concrete.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Demolition Hammer H65SB2
Hitachi-HIKOKI original spare parts for to replace broken parts for to fix Demolition Hammer H65SB2.In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
| Demolition Hammer Hitachi H65SB2 | ||
| # | Part Num. | Description |
| 2 | 323736 | DAMPER PLATE |
| 3 | 323737 | COLLAR |
| 4 | 323735 | FRONT DAMPER |
| 5 | 998424 | SPRING CASE |
| 6 | 956975 | LEVER SPRING |
| 7 | 998425 | DAMPER (B) |
| 8 | 323733 | FRONT COVER |
| 9 | 323732 | SECOND HAMMER |
| 10 | 323748 | STOP LEVER |
| 11 | 998426 | NEEDLE ROLLER |
| 12 | 998428 | O-RING (C) |
| 13 | 998427 | O-RING (B) |
| 14 | 998433 | DAMPER (A) |
| 15 | 323731 | O-RING (I.D 26.5) |
| 16 | 323730 | SHANK SLEEVE |
| 17 | 956963 | MOUTH |
| 18 | 956962 | MOUTH COVER |
| 19 | 323729 | MOUTH WASHER |
| 20 | 956960 | URETHANE RING |
| 21 | 320374 | HANDLE STAY (W/NUT) |
| 22 | 323728 | CYLINDER CASE |
| 23 | 956996 | O-RING (1AS-60) |
| 24 | 323724 | STRIKER |
| 25 | 998414 | O-RING (A) |
| 28 | 998415 | OIL SEAL (A) |
| 29 | 944928 | PISTON PIN |
| 30 | 998413 | PISTON |
| 31 | 998434 | CONNECTING ROD ASS'Y |
| 32 | 944921 | NEEDLE BEARING (NTN 8E-NK 18/20 RDO) |
| 33 | 956955 | CRANK WASHER |
| 37 | 306165 | SIDE HANDLE ASS'Y |
| 38 | 323723 | GEAR COVER |
| 39 | 6302VV | BALL BEARING 6302VVCMPS2L |
| 40 | 944916 | FINAL GEAR |
| 41 | 944915 | DISTANCE RING (B) |
| 42 | 323722 | INNER COVER |
| 43 | 323725 | SEAL RING |
| 44 | 6205DD | BALL BEARING 6205DDCMPS2L |
| 45 | 956949 | BEARING COVER |
| 47 | 998430 | CRANK SHAFT |
| 49 | 323721 | HOUSING ASS'Y |
| 50 | 944918 | PIN D5X15.8 |
| 52 | 980717 | O-RING (S-38) |
| 53 | 990945 | OIL CAP ASS'Y |
| 54 | 877838 | SEAL LOCK HEX. SOCKET HD. BOLT M4X8 |
| 55 | 323727 | CAP COVER |
| 56 | 944960 | CAP RUBBER |
| 57 | 940540 | BRUSH CAP |
| 59 | 956984 | BRUSH HOLDER |
| 61 | 980750 | GUIDE PLATE |
| 62 | 980727 | HANDLE RUBBER |
| 64 | 6201VV | BALL BEARING 6201VVCMPS2L |
| 65 | 956948 | COUNTER GEAR |
| 66 | 6001VV | BALL BEARING 6001VV |
| 67 | 944911 | BEARING COVER (A) |
| 68 | 6203DD | BALL BEARING 6203DDCMPS2L |
| 70 | 956764 | SPECIAL WASHER |
| 71 | 956850 | WOODRUFF KEY 4X16 |
| 72 | 994190 | INTERNAL WIRE |
| 73 | 944907 | DISTANCE RING (A) |
| 74 | 996370 | FAN |
| 75 | 360286E | ARMATURE ASS'Y 220V-230V |
| 76 | 306098 | FAN GUIDE |
| 77 | 945932 | BRUSH TERMINAL |
| 78 | 340259E | STATOR ASS'Y 220V-230V |
| 80 | 944954 | BEARING WASHER |
| 81 | 6201DD | BALL BEARING 6201DDCMPS2L |
| 82 | 323740 | BACK COVER |
| 83 | 323741 | HANDLE PACKING |
| 86 | 991711 | DISTANCE PIECE (B) |
| 89 | 994273 | NOISE SUPPRESSOR |
| 89 | 317491 | NOISE SUPPRESSOR |
| 90 | 930153 | SUPPORT (B) |
| 92 | 323726 | TAIL COVER |
| 98 | 960266 | CORD CLIP |
| 103 | 306143 | SWITCH (B) (1P SCREW TYPE) W/LOCK |
| 104 | 323742 | SUPPORT |
| 107 | 958049 | CORD ARMOR D8.2 |
| 107 | 940778 | CORD ARMOR D10.7 |
| 109 | 339262 | HANDLE (A).(B) SET |
| 606 | 981840 | GREASE (A) FOR HAMMER.HAMMER DRILL (30G) |
| 607 | 308471 | GREASE FOR HAMMER.HAMMER DRILL (70G) |
| 609 | 980927 | GREASE FOR HAMMER.HAMMER DRILL (500G) |
| 610 | 323745 | SERVICE KIT (H 65SB2) |
| 1000 | 944927 | O-RING |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
