Hitachi Spare Parts for Dust collector RP35YE
€1.40
Tax included
Hitachi Spare Parts for Dust collector RP35YE
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Dust collector RP35YE.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Dust Collector RP35YE
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Dust collector RP35YE.In the following table, look for the model of the Dust Collector and their spare part.
| Dust Collector RP35EY | ||
| # | Part Num. | Description |
| 1 | 329359 | POWDER FILTER |
| 2 | 994810 | SCREW (PLASTIC TIE) D4X16 |
| 3 | 949555 | NUT M5 |
| 4 | 329360 | WATER GUARD |
| 5 | 949424 | WASHER M5 |
| 6 | 949454 | SPRING WASHER M5 |
| 7 | 949393 | WING BOLT M5X15 |
| 8 | 307811 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 9 | 311839 | HEX. CAP NUT M4 |
| 10 | 949453 | SPRING WASHER M4 |
| 11A | 325867 | CLAMP |
| 12 | 323211 | MACHINE SCREW M4X8 (BLACK) |
| 14 | 329361 | JOINT COVER (A) |
| 15 | 325862 | JOINT COVER PACKING |
| 16 | 325905 | TANK (SUS) |
| 17 | 321014 | HOSE STOPPER |
| 18 | 325864 | HOSE JOINT |
| 19 | 325904 | BASE (SUS) |
| 20 | 325906 | BUMPER (A) |
| 21 | 949433 | BOLT WASHER M8 |
| 22 | 325859 | CASTER D50 (W/STOPPER) |
| 23 | 325858 | CASTER D50 |
| 24 | 325901 | JOINT HANDLE |
| 25 | 320986 | SLEEVE (B) ID38 |
| 26 | 321065 | SCREW RING |
| 27 | 321066 | CLICK RING |
| 28 | 328684 | HOSE ASS'Y ID38 |
| 29 | 320985 | SLEEVE (A) ID38 |
| 30 | 326218 | FAN (A) |
| 31 | 326225 | CASING (A) |
| 32 | 326226 | SPACER |
| 33 | 326217 | FAN (B) |
| 34 | 326227 | CASING (B) |
| 35 | 326228 | SPECIAL WASHER |
| 36 | 949568 | LOCK NUT M8 |
| 37A | 334977 | SUPPORT RING (B) |
| 38 | 325875 | MOTOR BASE FILTER |
| 39 | 975144 | CABLE TIE |
| 40 | 325950 | RUBBER BUSH |
| 41 | 329363 | MOTOR BASE |
| 42 | 329362 | INTERNAL WIRE (J) |
| 43 | 325952 | JOINT |
| 44 | 307811 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 46A | 307028 | TAPPING SCREW (W/FLANGE) D4X25 (BLACK) |
| 47 | 329365 | INTERNAL WIRE (J) |
| 48 | 325874 | MOTOR FILTER |
| 49 | 325873 | MOTOR BASE PACKING |
| 50 | 328690 | DUST MOTOR BASE ASS'Y |
| 51 | 994806 | SCREW (PLASTIC TIE) D4X20 |
| 52 | 325947 | DUST HANDLE |
| 53 | 949455 | SPRING WASHER M6 |
| 54 | 949556 | NUT M6 |
| 55 | 325931 | SWITCH (B) |
| 56 | 325931 | SWITCH (B) |
| 57 | 329756 | SWITCH HOLDER (EU) |
| 58 | 313687 | TAPPING SCREW (W/FLANGE) D3X16 (BLACK) |
| 59 | 328685 | RECEPTACLE |
| 60 | 326107 | PUSHING SWITCH |
| 61 | 301653 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 62 | 321041 | TERMINAL PLATE |
| 63 | 328686 | INTERNAL WIRE (E) |
| 64 | 975144 | CABLE TIE |
| 65 | 305095 | TAPPING SCREW (W/FLANGE) D4X20 |
| 66 | 995063 | CORD CLIP |
| 67 | 959140 | CONNECTOR 50091 |
| 68 | 500479Z | CORD |
| 69 | 959141 | CONNECTOR 50092 |
| 70 | 975144 | CABLE TIE |
| 71 | 301295 | MACHINE SCREW (W/WASHERS) M4X20 |
| 72 | 328687 | TRANSFORMER 230V |
| 73 | 949568 | LOCK NUT M8 |
| 74 | 975144 | CABLE TIE |
| 75 | 328109 | RUBBER BUSH |
| 76 | 325929 | TAPPING SCREW (W/FLANGE) D4X10 (BLACK) |
| 77 | 329366 | PRINTED BOARD (A) (EU) |
| 78 | 949554 | NUT M4 |
| 79 | 325893 | HANDLE |
| 80 | 328688 | HEAD COVER ASS'Y |
| 81 | 325891 | HEAD COVER PACKING (C) |
| 82 | 325892 | HEAD COVER PACKING (D) |
| 83 | 325890 | HEAD COVER PACKING (B) |
| 84 | 325889 | HEAD COVER PACKING (A) |
| 85 | 325882 | MOTOR COVER PACKING (B) |
| 86A | 329367 | MOTOR COVER |
| 87 | 329755 | FERRITE CORE |
| 88 | 325876 | SUPPORT RING (A) |
| 89 | 325879 | MOTOR PACKING |
| 90 | 949218 | MACHINE SCREW M4X14 |
| 91 | 326221 | MOTOR FRAME |
| 92 | 326229 | BEARING HOLDER (A) |
| 93 | 360817 | ARMATURE 230V |
| 94 | 326222 | PRESS PLATE |
| 95 | 326223 | MOTOR BASE |
| 96 | 326224 | FLANGE WASHER |
| 97 | 326215 | FAN COVER |
| 98 | 326216 | COOLING FAN |
| 99 | 999102 | CARBON BRUSH (1 PAIR) |
| 100 | 326231 | BALL BEARING 607Z |
| 101 | 340710 | STATOR 230V |
| 102 | 326230 | BALL BEARING 608RS |
| 103 | 326219 | BOLT M5X70 |
| 104 | 326220 | RUBBER SPACER |
| 105 | 328689 | MOTOR ASS'Y |
| 106 | 334527 | BEARING HOLDER (B) |
| 107 | 334980 | MOTOR COVER SET |
| 108 | 325926 | EARTH PLATE |
| 502 | 320990 | EXTENSION PIPE |
| 505 | 321067 | PIPE HOLDER |
| 506 | 320994 | ADAPTER |
| 507 | 320993 | NOZZLE |
| 508 | 782261 | NOZZLE FOR FLUID |
| 509 | 782262 | WET NOZZLE |
| 510 | 782271 | BRUSH |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase.All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
