authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Planer P20SF.
In the following table, look for the model of the Planer and theirs spare part.![]()
| Planer P20SF | ||
| # | Part Num. | Description |
| 1 | 334480 | CUTTER BLOCK ASS'Y (W/B.B) |
| 2 | 879418 | PLANER BLADES (1 PAIR) |
| 3 | 334478 | SET PLATE (B) (1 PAIR) |
| 4 | 314754 | SET PLATE (A) |
| 5 | 949423 | WASHER M4 |
| 6 | 949213 | MACHINE SCREW M4X5 |
| 7 | 316398 | BLADE HOLDER (1 PAIR) |
| 9A | 336574 | BOLT M6 |
| 10 | 314746 | PLANER BLADES 82MM (1 PAIR) EXCEPT FOR DOUBLE EDGE BLADE TYPE |
| 11 | 949216 | MACHINE SCREW M4X10 |
| 12 | 958731Z | HOLDER SPRING (B) |
| 13 | 958732Z | GUARD PLATE (A) |
| 14 | 958734Z | BLADE HOLDER (1 PAIR) |
| 15 | 958728 | PLANER BLADES 82MM (1 PAIR) |
| 16 | 958733Z | BACK METAL |
| 17 | 608VVM | BALL BEARING 608VVC2PS2L |
| 18 | 334481 | CUTTER BLOCK ASS'Y (W/B.B) |
| 19 | 6200VV | BALL BEARING 6200VVCMPS2L |
| 20 | 958945 | SCREW PLATE |
| 21 | 954004 | TAPPING SCREW D4X16 |
| 22 | 958709 | SPRING |
| 23 | 958708 | RUBBER PACKING |
| 24 | 334739 | FRONT BASE |
| 25 | 334494 | KNOB (A) |
| 26 | 334497 | LOCK NUT M10 |
| 27 | 334488 | KNOB (B) |
| 27 | 334489 | KNOB (B) |
| 28 | 301659 | WASHER (B) |
| 29 | 334492 | BEARING COVER |
| 30 | 309470 | TAPPING SCREW (W/FLANGE) D4X12 (BLACK) |
| 31 | 334501 | TIP COVER |
| 32 | 301653 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 33 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 35 | 957571 | BRUSH HOLDER |
| 36 | 999021 | CARBON BRUSH (1 PAIR) |
| 37 | 931266 | BRUSH CAP |
| 39 | 334487 | BELT COVER |
| 40 | 958718 | BELT |
| 41 | 334491 | PULLEY (B) |
| 42 | 334486 | END BRACKET |
| 43 | 6200VV | BALL BEARING 6200VVCMPS2L |
| 44 | 334713 | WASHER (A) |
| 45 | 360936E | ARMATURE 220V-230V |
| 46 | 334493 | FAN GUIDE |
| 47 | 340834E | STATOR ASS'Y 220V-230V |
| 48 | 931867 | BRUSH TERMINAL |
| 49 | 333163 | MACHINE SCREW (BLACK) M4X16 |
| 50 | 334490 | PULLEY (A) |
| 51 | 334485 | GRIP COVER |
| 52 | 334484 | HANDLE COVER |
| 53 | 960108 | HEX. HD. TAPPING SCREW D4X60 |
| 54 | 334474 | SWITCH |
| 54 | 322101 | SWITCH |
| 55 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 56 | 937631 | CORD CLIP |
| 57 | 608VVM | BALL BEARING 608VVC2PS2L |
| 58 | 331707 | FASTON |
| 59 | 334482 | HOUSING ASS'Y |
| 60 | 953327 | CORD ARMOR D8.8 |
| 65 | 994273 | NOISE SUPPRESSOR |
| 66 | 959140 | CONNECTOR 50091 |
| 68 | 334838 | REAR BASE |
| 69 | 307811 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 508 | 334502 | ADAPTER |
| 509 | 322955 | DUST BAG |
| 510 | HTA750470 | TWO MINI KNIVES 82MM |
