Hitachi Spare Parts for Angle Grinder G23UBY
€1.78
Tax included
Hitachi Spare Parts for Angle Grinder G23UBY
HItachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23UBY.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Angle Grinder G23UBY
HItachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G23UBY.
In the following table, look for the model of Brush Cutter and the respective parts of the code.
| Disc Grinder 230 mm S 23UBY | ||
| # | Part Num. | Description |
| 1 | 984509 | SEAL LOCK HEX. SOCKET HD. BOLT M5X14 |
| 2 | 323209 | TAPPING SCREW (W/FLANGE) D5X35 (BLACK) |
| 3 | 306888 | PUSHING BUTTON |
| 4 | 320219 | SPRING |
| 5 | 326717 | GEAR COVER ASS'Y |
| 6 | 320226 | SPECIAL NUT M10 |
| 7 | 320221 | SEAL WASHER |
| 8 | 320222 | FELT PACKING |
| 9 | 6301DD | BALL BEARING 6301DDCMPS2L |
| 10 | 994208 | RUBBER RING (B) |
| 11 | 320220 | BEARING COVER (A) |
| 12 | 360777E | ARMATURE 220V-230V |
| 13 | 320215 | FAN GUIDE |
| 14 | 984271 | HEX. HD. TAPPING SCREW D5X75 |
| 15 | 340682E | STATOR 220V-240V |
| 16 | 937033 | FELT WASHER |
| 17A | 336864 | SIDE HANDLE |
| 18 | 320218 | O-RING |
| 19 | 306890 | LOCK PIN |
| 20 | 326718 | GEAR AND PINION SET |
| 21 | 939540 | RETAINING RING FOR D10 SHAFT |
| 22 | 326722 | COUPLING COVER |
| 23 | 326721 | COUPLING DAMPER |
| 24A | 333147 | COUPLING |
| 25 | 949236 | MACHINE SCREW M5X10 (10 PCS.) |
| 26 | 326723 | BEARING COVER (B) |
| 27 | 6302VV | BALL BEARING 6302VVCMPS2L |
| 28 | 990852 | FELT PACKING (B) |
| 29 | 326727 | SPINDLE |
| 30 | 320228 | SEAL PLATE |
| 31 | 320227 | PACKING GLAND |
| 32 | 994192 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 |
| 33 | 311492 | LABEL |
| 34 | 321546 | SET PIN |
| 35 | 321545 | LEVER |
| 36 | 306887 | BOLT M8X22 |
| 37 | 949457 | SPRING WASHER M8 (10 PCS.) |
| 38 | 321544 | SET PIECE |
| 39 | 673489 | RETAINING RING (E-TYPE) FOR D5 SHAFT |
| 40 | 321547 | WHEEL GUARD ASS'Y |
| 40A | 337225 | WHEEL GUARD ASS'Y |
| 41 | 937908Z | WHEEL WASHER (B) |
| 41A | 937907Z | WHEEL WASHER (C) |
| 42 | 316825 | D. C. WHEELS 230MM A24R (25 PCS.) |
| 43 | 937909Z | WHEEL NUT M14X2 |
| 44 | 320216 | DUST SEAL |
| 45 | 6000VV | BALL BEARING 6000VVCMPS2L |
| 46 | 321536 | BEARING BUSHING |
| 47 | 326712 | HOUSING ASS'Y |
| 48 | 326715 | BRUSH COVER |
| 49 | 326726 | HANDLE DAMPER |
| 50 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 51 | 999061 | CARBON BRUSH 7X17X22.5 (1 PAIR) |
| 51 | 999089 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 52 | 322323 | BRUSH HOLDER SET |
| 53 | 326716 | BRUSH COVER |
| 56 | 326724 | O-RING |
| 57 | 326725 | O-RING |
| 58 | 320236 | RESISTOR |
| 59 | 320371 | SWITCH (2P PILLAR TYPE) W/SAFETY LOCK |
| 59 | 320235 | SWITCH (2P PILLAR TYPE) W/SAFETY LOCK |
| 60 | 326714 | HANDLE (B) |
| 61 | 960266 | CORD CLIP |
| 62 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 63 | 326713 | HANDLE (A) |
| 64 | 981373 | TUBE (D) |
| 65 | 940778 | CORD ARMOR D10.7 |
| 65 | 958049 | CORD ARMOR D8.2 |
| 70 | 328700 | INNER |
| 71 | 328694 | INNER SET (W/GEAR) |
| 72 | 328697 | GEAR AND PINION ASS'Y |
| 73 | 328698 | GEAR (A) ASS'Y |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
