Hitachi Spare Parts for Rotary Hammers DH50MRY
€5.51
Tax included
Hitachi Spare Parts for Rotary Hammer DH50MRY
We supply original Hitachi-HIKOKI spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer DH50MRY.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Rotary Hammer DH50MRY
We supply original Hitachi-HIKOKI spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer DH50MRY.
In the following table, look for the model of the hammer and the respective parts of the code.
| Rotary Hammer 20 Joule - 10.5Kg - UVP DH50MRY | ||
| # | Part Num. | Description |
| 1 | 313415 | FRONT CAP |
| 2 | 328900 | GRIP |
| 3 | 318590 | STOPPER RING |
| 4 | 328899 | NEEDLE HOLDER |
| 5 | 313419 | RETAINER SPRING |
| 6 | 318589 | SPRING HOLDER |
| 7 | 985479 | SEAL LOCK HEX. SOCKET HD. BOLT M8X25 |
| 8 | 318587 | FRONT COVER |
| 9 | 878863 | O-RING (S-70) |
| 10 | 318588 | OIL SEAL (NBR710) |
| 11 | 318586 | URETHANE RING |
| 12 | 318585 | URETHANE RING HOLDER |
| 13 | 318582 | RETAINING RING D40 |
| 14 | 6008CM | BALL BEARING 6008CM |
| 15 | 318581 | SLEEVE |
| 16 | 328884 | THRUST WASHER (A) |
| 17 | 328883 | RETAINER DAMPER |
| 18 | 313421 | NEEDLE ROLLER D8X20 |
| 19 | 328882 | RETAINER SLEEVE |
| 20 | 986104 | O-RING |
| 21 | 328885 | SECOND HAMMER |
| 22 | 328886 | DAMPER WASHER |
| 23 | 328887 | DAMPER |
| 24 | 328888 | DAMPER HOLDER |
| 25 | 328891 | NEEDLE PIN D8X6 |
| 26 | 328889 | CYLINDER |
| 27 | 328895 | LOCK SPRING |
| 28 | 318562 | LOCK SLEEVE |
| 29 | 329330 | SPRING HOLDER (B) |
| 30 | 328893 | CLUTCH SPRING |
| 31 | 328890 | STRIKER |
| 32 | 328880 | O-RING |
| 33 | 328894 | CLUTCH |
| 34 | 328879 | PISTON PIN |
| 35 | 328877 | PISTON |
| 36 | 328878 | CONNECTING ROD |
| 37 | 328896 | CYLINDER CASE |
| 38 | 990083 | HEX. SOCKET HD. BOLT (W/FLANGE) M8X35 |
| 39 | 985779 | O-RING (D) |
| 40 | 328897 | THRUST WASHER (B) |
| 41 | 328898 | BEVEL GEAR |
| 43 | 983162 | SEAL LOCK HEX. SOCKET HD. BOLT M4X12 |
| 44A | 331545 | CHANGE LEVER |
| 45 | 328901 | LEVER HOLDER |
| 46 | 321310 | LEVER SPRING |
| 47 | 321311 | PUSHING BUTTON |
| 48 | 321312 | PIN D2X10 |
| 49 | 311229 | RETAINING RING FOR D20 HOLE |
| 50 | 324934 | LEVER SHAFT |
| 51 | 873095 | O-RING (P-16) |
| 52 | 318574 | SIDE HANDLE |
| 53 | 328910 | BACK COVER |
| 54 | 998485 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X14 |
| 55A | 331096 | HANDLE HOLDER |
| 56 | 328920 | HANDLE (A).(B) SET |
| 57 | 318576 | HANDLE BOLT |
| 58 | 971786 | STOPPER ROD |
| 59 | 328909 | HOOD |
| 61 | 998471 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X12 |
| 63 | 328707 | TAPPING SCREW (W/FLANGE) D5X30 (BLACK) |
| 64 | 980750 | GUIDE PLATE |
| 65 | 980727 | HANDLE RUBBER |
| 66 | 305558 | TAPPING SCREW (W/FLANGE) D5X25 (BLACK) |
| 67 | 990079 | SEAL LOCK HEX. SOCKET HD. BOLT M5X16 |
| 68 | 991711 | DISTANCE PIECE (B) |
| 69 | 307028 | TAPPING SCREW (W/FLANGE) D4X25 (BLACK) |
| 70 | 990941 | SWITCH (B) (1P SCREW TYPE) W/O LOCK |
| 71 | 938307 | PILLAR TERMINAL |
| 72 | 980063 | TERMINAL |
| 72 | 930804 | TERMINAL M4.0 |
| 73 | 953327 | CORD ARMOR D8.8 |
| 73 | 938051 | CORD ARMOR D10.1 |
| 74 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 75 | 960266 | CORD CLIP |
| 77 | 877314 | CYLINDER O-RING (I.D 69.3) |
| 78 | 939542 | RETAINING RING FOR D12 SHAFT |
| 79 | 328868 | CRANK SHAFT |
| 80 | 328869 | FEATHER KEY 3X3X25 |
| 81 | 948227 | RETAINING RING FOR D47 HOLE |
| 82 | 6204DD | BALL BEARING 6204DDCMPS2L |
| 83 | 985765 | O-RING (B) |
| 84 | 328867 | OIL SEAL |
| 85 | 994192 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 |
| 86 | 328908 | CRANK COVER |
| 87 | 878713 | CYLINDER O-RING (B) |
| 88 | 328902 | WEIGHT |
| 89 | 957585 | WASHER |
| 90 | 306061 | SEAL LOCK HEX. SOCKET HD. BOLT M5X30 |
| 91 | 328903 | BASE |
| 92 | 328904 | WEIGHT PIN |
| 93 | 328905 | LEAF SPRING |
| 94 | 328907 | WEIGHT BUMPER |
| 95 | 328906 | SPRING HOLDER |
| 96 | 990079 | SEAL LOCK HEX. SOCKET HD. BOLT M5X16 |
| 97 | 944109 | FEATHER KEY 3X3X8 |
| 98 | 328873 | BEVEL PINION |
| 99 | 328874 | COLLAR |
| 100 | 328867 | OIL SEAL |
| 101 | 6202DD | BALL BEARING 6202DDCMPS2L |
| 102 | 313058 | WASHER |
| 103 | 318552 | WASHER (A) |
| 104 | 318554 | GEAR HOLDER |
| 105 | 329095 | SPRING (C) |
| 106 | 313057 | NEEDLE PIN D6X6 |
| 107 | 328875 | SECOND GEAR |
| 108 | 328876 | SPACER |
| 109 | 629VVM | BALL BEARING 629VVC2PS2L |
| 110 | 944525 | BEARING WASHER (C) |
| 111 | 328872 | SLIP CLUTCH ASS'Y |
| 112 | 328881 | SEAL PACKING |
| 113 | 328916 | GEAR COVER |
| 114 | 986940 | SEAL LOCK HEX. SOCKET HD. BOLT M6X45 |
| 115 | 328866 | CRANK CASE |
| 116 | 328870 | FIRST GEAR |
| 117 | 328871 | SECOND PINION |
| 118 | 939299 | NEEDLE BEARING (M661) |
| 119 | 953121 | HEX. HD. TAPPING SCREW D5X50 |
| 120 | 340712E | STATOR ASS'Y 220V-230V |
| 121 | 958032 | BRUSH TERMINAL |
| 122 | 321313 | SEAL LOCK HEX. SOCKET HD. BOLT M6X22 |
| 123 | 980750 | GUIDE PLATE |
| 124 | 980727 | HANDLE RUBBER |
| 125 | 6202DD | BALL BEARING 6202DDCMPS2L |
| 126 | 980700 | DUST WASHER (B) |
| 127 | 318918 | FAN |
| 128 | 360819E | ARMATURE ASS'Y 220V-230V |
| 129 | 328917 | FAN GUIDE |
| 130 | 944954 | BEARING WASHER |
| 131 | 6201VV | BALL BEARING 6201VVCMPS2L |
| 132 | 301797 | MAGNET |
| 133 | 980487 | BRUSH HOLDER |
| 134 | 999044 | CARBON BRUSH (1 PAIR) |
| 135 | 940540 | BRUSH CAP |
| 136 | 328915 | HOUSING ASS'Y |
| 137 | 999074 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 138 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 139 | 328918 | BEARING HOLDER |
| 140 | 328919 | TAIL COVER |
| 141 | 328914 | CASE (B) |
| 142 | 328913 | CONTROLLER CIRCUIT 220V-240V |
| 143 | 317113 | INTERNAL WIRE |
| 144 | 326541 | VINYL TUBE (I.D.9.5XT0.56X85) |
