Hitachi Spare Parts for Electric Rotary Hammer DH22PG
Hitachi-HIKOKI Tanaka Genuine Parts and Accessories, repair and after-sales service with great professional skills necessary to follow you and advise you on the purchase of spare parts that are most suitable for solving your repair and maintenance problems for Rotary Hammer DH 22 PG.
In the following table, look for the model of the Rotary hammer and the respective parts code.
| Rotary Hammer DH 22 PG | ||
| # | Part Num. | Description |
| 1 | 306345 | Front cap |
| 2 | 306340 | Ring Latch |
| 3 | 325597 | ring Dh14/18dl |
| 4 | 327879 | Support Balls DH14-18DL |
| 5 | 324526 | Support Thrust Dh24dva |
| 6 | 322812 | Spring Gate Punta |
| 7 | 327873 | Input box. Dh22pg |
| 8 | 305490 | Tapp. Screw (W / Flange) D4x30 |
| 10 | 965469 | Ring Type C X D.25 Trees |
| 11 | 944274 | washer Dh22pg |
| 12 | 327875 | Without Clutch Lever Dh14/18dl |
| 13 | 872654 | O-Ring 1ap.10 |
| 14 | 325594 | Clutch Lever Dh14/18dl |
| 15 | 949213 | Machine Screw M4x5 |
| 16 | 306334 | Clutch spring Dh14/18dl |
| 17 | 306333 | According to Input. Dh14/18dl |
| 18 | 959156 | Steel Ball D.7, 0 |
| 19 | 327876 | cylinder Dh14/18dl |
| 20 | 327877 | According Knocker Dh14/18dl |
| 21 | 301672 | O-Ring |
| 22 | 311814 | O-Ring Dh14/18dl |
| 23a | 332673 | Support Swing Dh14/18dl |
| 24 | 306340 | Ring Latch |
| 25 | 325601 | swing Dh14/18dl |
| 26 | 306326 | O-Ring (A) Dh14/18dl |
| 27 | 327880 | washer Dh14/18dl |
| 28 | 325588 | Supp.Rondella Dh14/18dl |
| 29 | 306976 | Spring (B) Dh14/18dl |
| 30 | 306324 | piston Dh14/18dl |
| 31 | 328660 | washer Dh22pg |
| 32 | 327870 | O-Ring Dh22pg |
| 33 | 327869 | Supp.Interno Dh22pg |
| 34 | 306322 | Piston pin Dh14/18dl |
| 35 | 325587 | spacer Dh14/18dl |
| 36 | 327871 | tree Second.Dh14/18dl |
| 37 | 325584 | clutch Dh14/18dl |
| 38 | 325585 | Bearing Articulated Dh14/18dl |
| 39 | 306320 | Needle Bearing For Dh14/18dl |
| 40 | 327872 | gear Dh14/18dl |
| 41 | 995634 | Washer (B) D12.5 |
| 42 | 626vvm | Ball Bearing 626vvm |
| 43 | 324543 | In Dh24pb3 Felt Gasket-Pc3 |
| 44 | 324545 | Valve Dh24pb3-Pc3 |
| 45 | 324544 | Felt Dh24pb3-Pc3-Pd3 |
| 46 | 878609 | O-Ring S-24 |
| 47 | 306312 | flange Dh22pg |
| 48 | 609ddc | Ball Bearing 609ddc3ps2-L |
| 49 | 958915 | Washer A Dh22pg |
| 50 | 360798e | induced Dh22pg |
| 50 | 360798f | Armature 240v |
| 51 | 327868 | Guide Fan Dh22pg |
| 52 | 981824 | Hex. Hd. Tapping Screw D4x45 |
| 53 | 340701e | stator Dh22pg |
| 53 | 340701f | Stator 240v |
| 54 | 982631 | washer |
| 55 | 608vvm | Ball Bearing 608vvm |
| 57a | 331669 | Imp.Completa Dh22ph |
| 58 | 324537 | Internal Cable Brown Dh24pb3 |
| 63 | 955203 | brush holder |
| 64 | 999041 | Brushes (1 pair) |
| 65b | 335796 | switch |
| 66 | 953327 | Sleeve saver D8.8 |
| 66 | 938051 | Sleeve saver D10.1 |
| 68 | 937631 | terminal Wire Tie |
| 69 | 984750 | Tapp. Screw (W / Flange) D4x16 |
| 70 | 500390z | Cord |
| 72 | 301653 | Tapp.Screw (W / Flange) D4x20 |
| 501a | 331439 | houses |
| 502 | 324548 | Lateral grip |
| 503 | 303709 | delimiter Depth |
