Hitachi Spare Parts for Angle Grinder G12SS
€4.18
Tax included
Hitachi Spare Parts for Angle Grinder G12SS
Hitachi-HIKOKI-Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G12SS.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Angle Grinder G12SS
Hitachi-HIKOKI-Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G12SS.
In the following table , look for the model of the Angle Grinder and their respective spare parts.
| Angle Grinder G12 SS | ||
| # | Part Num. | Description |
| 2 | 317807 | GUARD PLATE |
| 3 | 301944 | PUSHING BUTTON |
| 4 | 328181 | GEAR COVER ASS'Y |
| 7 | 608VVM | BALL BEARING 608VVC2PS2L |
| 8 | 328184 | BEARING HOLDER |
| 9 | 360802E | ARMATURE 230V-240V |
| 10 | 328177 | FAN GUIDE |
| 11 | 963712 | HEX. HD. TAPPING SCREW D4X65 |
| 12 | 340705E | STATOR 220V-230V |
| 13 | 321722 | DUST SEAL |
| 14 | 626VVM | BALL BEARING 626VVC2PS2L |
| 15 | 309929 | RUBBER BUSHING |
| 16 | 301943 | LOCK PIN |
| 17 | 316487 | RETAINING RING FOR SHAFT, D11 |
| 19 | 328182 | PACKING GLAND |
| 21 | 328185 | WASHER (A) |
| 22 | 328186 | SPINDLE |
| 24 | 301949 | SET PLATE |
| 25 | 315492 | WHEEL GUARD ASS'Y |
| 26 | 937817Z | WHEEL WASHER |
| 27 | 316821 | D. C. WHEELS 115MM A36Q (25 PCS.) |
| 28 | 994324 | WHEEL NUT M14 |
| 28A | 337329 | WHEEL NUT M14 |
| 29 | 328178 | GEAR AND PINION SET |
| 30 | 314427 | SLIDE BAR |
| 31 | 314429 | SPRING |
| 32 | 314428 | SLIDE KNOB |
| 33 | 328176 | HOUSING ASS'Y |
| 39 | 317491 | NOISE SUPPRESSOR |
| 42 | 936551 | BRUSH CAP |
| 43 | 999021 | CARBON BRUSH (1 PAIR) |
| 44 | 313777 | BRUSH HOLDER |
| 45 | 955509 | SWITCH (1P SCREW TYPE) |
| 46 | 305499 | MACHINE SCREW (W/WASHER) M3.5X6 |
| 49 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 50 | 937631 | CORD CLIP |
| 51 | 953327 | CORD ARMOR D8.8 |
| 52 | 328183 | TAIL COVER |
| 502 | 302142 | SIDE HANDLE |
| 502 | 318312 | SIDE HANDLE |
