Hikoki CM5MA Wall Chaser Parts
€46.18
Tax included
Hikoki CM5MA Wall Chaser Parts
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Wall Chaser CM5MA.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hikoki CM5MA Wall Chaser Parts
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Wall Chaser CM5MA.In the following table, look for the model of the Miter Saw and theirs spare part.
| Hikoki CM5MA Wall Chaser Parts | ||
| # | Part Num. | Description |
| 1 | 377403 | Gear Cover Ass'Y 2.3.5.6.13 |
| 2 | 377411 | Pushing Button |
| 3 | 372944 | SPRING (A) |
| 5 | 377410 | O-RING |
| 6 | 372946 | Lock Pin |
| 7 | 377409 | Gear Flange Ass'Y INCLUDING 8-12.14-16.45-48.50.51 |
| 9 | 372931 | Friction Washer Ass'Y |
| 10 | 377413 | O-RING |
| 11 | 377357 | TORX SCREW |
| 12 | 377412 | GEAR FLANGE |
| 14 | 377358 | SECOND SHAFT |
| 15 | 377355 | NEEDLE SLEEVE |
| 16 | 377354 | NEEDLE ROLLER |
| 17 | 377405 | GEAR SET |
| 18 | 377336 | GASKET |
| 19 | 377337 | Flange and Spindle |
| 21 | 372908 | WASHER 7.05X19.5X0.2 |
| 22 | 372907 | BALL BEARING 8X22X7 |
| 23 | 372906 | WASHER 8.05X17X0.4 |
| 24 | 372942 | RETAINING RING |
| 25 | 377328 | ARMATURE ASS'Y INCLUDING 26 |
| 26 | 372938 | FAN |
| 27 | 372904 | BALL BEARING 6X19X6 |
| 28 | 372905 | Rubber Bushing |
| 29 | 372947 | MAGNET |
| 30 | 372901 | BAFFLE |
| 31 | 372900 | FAN GUIDE |
| 32 | 377329 | STATOR 230V - 240V |
| 33 | 377015 | HOUSING |
| 35 | 377363 | BRUSH HOLDER SET (2PCS) + BRUSHES INCLUDED 36.37 |
| 36 | 377404 | BRUSH HOLDER SET |
| 37 | 372939 | CARBON BRUSHE SET (1 PAIR) |
| 38 | 377333 | CONTROLLER |
| 39 | 377335 | D-Handle Set |
| 40 | 371271 | CORD CLIP |
| 42 | 377330 | SWITCH |
| 43 | 372894 | CORD ARMOR |
| 44 | 714500 | CORD 5M 2 X 1.0 WITH PLUG |
| 45 | 372925 | WASHER 10.2X14.8X0.1 |
| 46 | 372924 | WASHER 10.2X14.8X0.2 |
| 47 | 372926 | WASHER 10.2X14.8X0.5 |
| 48 | 372929 | Bevel Gear. Pinion Set |
| 49 | 372918 | GASKET |
| 50 | 377356 | WASHER |
| 51 | 377359 | BALL BEARING |
| 52 | 377338 | Saw Cover Ass'Y INCLUDED 53-57 |
| 53 | 377406 | Shaft Washer Set |
| 54 | 377362 | ROLLER |
| 55 | 377407 | MAIN HANDLE |
| 56 | 377361 | CLAMP LEVER M6X20 |
| 57 | 377360 | SUCTION NOZZLE |
| 58 | 377408 | Flat Hd. Screw |
| 60 | 377339 | CLAMP FLANGE |
| 61 | 377400 | SPACE WASHER |
| 62 | 377401 | CLAMP NUT |
| 501 | 377016 | BLOW CASE |
| 503 | 377098 | SPANNER |
| 504 | 377099 | CHISEL |
| 603 | 981840 | Grease (B) 30GR |
| 604 | 335782 | Grease (60 GR) |
| 605 | 308471 | Grease 70 GR |
| 606 | 980927 | Grease 500GR |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
