and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless with 14.4 V with Lithium Batteries DS14DBL.
Reversible drills and impact cordless drills with batteries from 1.5 Ah to 4, with torque clutch.
- DS14DBL
In the following table, look for the model of the Cordless driver drill and theirs spare part.![]()
| CORDLESS DRIVER DRILL DS14DBL | ||
| # | Part Num. | Description |
| 1 | 311959 | SPECIAL SCREW (LEFT HAND) M6X23 |
| 2 | 331914 | DRILL CHUCK 13VLRR-N (W/O CHUCK WRENCH) |
| 3 | 331709 | GEAR BOX ASS'Y |
| 4 | 331880 | FRONT CAP |
| 5 | 331881 | NUT |
| 9 | 331885 | STOPPER |
| 10 | 331886 | STOPPER SPRING |
| 11 | 331887 | FRONT CASE |
| 12 | 331905 | CLICK SPRING |
| 13 | 331909 | WASHER (A) |
| 14 | 331903 | LOCK RING (A) |
| 15 | 331904 | LOCK CAM |
| 16 | 331888 | NEEDLE ROLLER SET (6PCS.) |
| 17 | 331889 | RING GEAR |
| 18 | 331890 | CARRIER |
| 19 | 331891 | PLANET GEAR (C) SET (5 PCS.) |
| 20 | 331892 | WASHER (A) |
| 21 | 331893 | REAR CASE |
| 22 | 315817 | SCREW SET D3X12 (6 PCS.) |
| 23 | 331894 | SHIFT ARM |
| 24 | 331896 | SLIDE RING GEAR |
| 25 | 331897 | PINION (C) |
| 26 | 331898 | PLANET GEAR (B) SET (4 PCS.) |
| 27 | 330579 | SCREW SET D2X3.5 (2 PCS.) |
| 28 | 331899 | PINION (B) |
| 29 | 331926 | NEEDLE BEARING SET (4 PCS.) |
| 30 | 331900 | PLANET GEAR (A) SET (4 PCS.) |
| 31 | 331901 | FIRST RING GEAR |
| 32 | 322988 | WASHER (B) |
| 33 | 331902 | MOTOR SPACER |
| 34 | 331710 | ROTOR PINION SET |
| 35 | 331718 | HOUSING (A).(B) SET (GREEN) |
| 36 | 331907 | PUSHING BUTTON |
| 37 | 340766 | STATOR FET PCB |
| 38B | 334267 | SHIFT KNOB |
| 40 | 331715 | DC-SPEED CONTROL SWITCH |
| 41 | 994532 | MACHINE SCREW (W/SP. WASHER) M3X5 |
| 42 | 313687 | TAPPING SCREW (W/FLANGE) D3X16 (BLACK) |
| 44 | 329648 | HITACHI PLATE |
| 45 | 330662 | PANEL SHEET (B) |
| 46 | 332824 | HOOK |
| 47 | 327001 | TRUSS HD. SCREW M4 (BLACK) |
| 48 | 327002 | LOCK NUT M4 (BLACK) |
| 49 | 330854 | PACKING |
| *50 | 331722 | CONTROLLER |
| 50A | 333690 | CONTROLLER |
| 51 | 306952 | STRAP (BLACK) |
| *52 | 329083 | BATTERY BSL 1430 (EUROPE,AUS,NZL) |
| 55 | 332546 | CLUTCH PARTS SET |
