Hitachi Spare Parts for Cordless Rotary Hammer DH36PDA

HIKOKI CORDLESS ROTARY HAMMER Model DH36DPA
#	Part Num.	Description
1	306345	FRONT CAP
2	306340	STOPPER RING
3	324527	GRIP
4	371326	BALL HOLDER (FW)
5	324526	HOLDER PLATE
6	322812	HOLDER SPRING
8	370306	GEAR COVER ASS'Y INCLUD.10,11,19
10	335259	OIL SEAL
11	335260	BALL BEARING 6805DD
12	878885	O-RING (S-18)
13	322789	PUSHING BUTTON
14	317223	PUSHING SPRING
15	334011	CHANGE LEVER
17	370308	BRAND PLATE
18	335800	SPRING (E)
19	608VVM	BALL BEARING 608VVC2PS2L
20	335300	STEEL BALL D7.0 (10 PCS.)
21	335261	CYLINDER
22	335264	PIN D2.5
23	335263	CYLINDER CLUTCH
24	335265	SECOND GEAR
25	335266	SPRING (A)
26	301679	WASHER (A)
27	948310	RETAINING RING FOR D30 SHAFT
28	335262	OIL SEAL (A)
29	335268	HAMMER HOLDER (C)
30	335795	SLEEVE (FW)
31	335269	SECOND HAMMER
32	335267	HAMMER HOLDER (A)
33	322805	DAMPER (A)
34	322808	O-RING (C)
35	324524	DAMPER HOLDER
36	322807	STOPPER RING
37	372815	STRIKER
38	372816	O-RING
39	301679	WASHER (A)
40	372817	PISTON
41	335794	PISTON WASHER
43	370309	INNER COVER (B) INCLUD.54,55,63-65
44	370310	O-RING
45	370311	INNER COVER (A)
47	335793	PISTON PIN
48	335249	RECIPROCATING BEARING
49	335250	BEARING WASHER
50	370312	BEARING HOLDER (B)
51	608VVM	BALL BEARING 608VVC2PS2L
52	370313	BEARING COVER (A)
53	370314	BEVEL GEAR (A)
54	334008	AIR CAP
55	324543	FELT PACKING (A)
56	335275	PINION SLEEVE
57	335276	LOCK PLATE
58	335278	SECOND PINION
59	323182	CLUTCH SPRING
60	335254	CLUTCH
61	331315	WASHER
62	335277	SECOND SHAFT
63	370315	FELT PACKING
64	370316	PACKING WASHER
65	872470	O-RING (S-26)
66	361072	ROTOR (B)
67	340981	STATOR
69	370321	DAMPER (A)
70	376794	HOUSING (A).(B) SET INCLUD.69
71	372867	SWITCH CONTROLLER ASS'Y INCLUD.76
72	370327	RUBBER CUSHION
73	370545	TERMINAL RUBBER BASE
74	371715	TERMINAL COVER
75	324225	PUSHING BUTTON (B)
76	370322	DC-SPEED CONTROL SWITCH
77	370328	BUTTERY RUBBER (B)
82	372867	WIRING ASS'Y INCLUD.67,71,72
503	335273	DEPTH GAUGE
504	373134	CASE
506	402541	CASE ASS'Y (STACKABLE 4) INCLUD.507-509
507	336472	LATCH
508	336473	HANDLE
509	336474	HINGE
510	376002	BOTTOM CUSHION
605	303623	CHUCK ADAPTER (G) (SDS PLUS)
608	987576	CHUCK WRENCH FOR 13VLB-D,13VLR-D
610	971787	DUST CUP
617	306885	DUST COLLECTOR (B) ASS'Y INCLUD.618
621	335782	GREASE FOR ROTARY HAMMER (60G)
622	335781	GREASE FOR ROTARY HAMMER (500G)
623	402933	DUST EXTRACTOR
